CyberView RKP2417F User Manual

2u dual slide short depth lcd console drawer
Hide thumbs Also See for RKP2417F:
Table of Contents

Advertisement

Quick Links

Download this manual
dedicated KVM switch and rackmount screen technology
User Manual
2U Dual Slide Short Depth LCD Console Drawer
RKP2417F
17" FHD 1920 x 1080 LCD
Options :
- HDMI
- SDI
- Touchscreen
- DC power
RKP2417X
17" Ultra High Resolution 1920 x 1200 LCD
Options :
- HDMI
- SDI
- Touchscreen
- DC power
RKP2417 / RKP2419
17" / 19" 1280 x 1024 LCD
Options :
- AV / DVI-D / HDMI
- Touchscreen
- DC power
751
Designed and manufactured by Austin Hughes
UM-CV-751-RKP2417-Q317V5
www.austin-hughes.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RKP2417F and is the answer not in the manual?

Questions and answers

Related Manuals for CyberView RKP2417F

Summary of Contents for CyberView RKP2417F

  • Page 1 KVM switch and rackmount screen technology User Manual 2U Dual Slide Short Depth LCD Console Drawer RKP2417F 17" FHD 1920 x 1080 LCD Options : - HDMI - SDI - Touchscreen - DC power RKP2417X 17" Ultra High Resolution 1920 x 1200 LCD...
  • Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 4: Table Of Contents

    P.15 - 17 < Part. 3 > Options P.18 - 21 RKP2417F - 3G / HD / SD-SDI Broadcast-grade input - HDMI - F17" Touchscreen : Resistive ( 1-point touch ) - DC Power : 12V / 24V / 48V / 125V / 250V P.22 - 25...

  • Page 5: Before Installation

    Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.

  • Page 6: Package Content

    ( Alternative for PS/2 KB / MS : CE-6 6ft Combo KVM cable ) - Power cord X 1 - M6 screw, cage nut & cup washer X 8 RKP2417F or RKP2417X unit X 1 - CX-6 6ft DVI-D console cable X 1 ( Alternative : CB-6 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut &...
  • Page 7 < 1.2 > Dimension Front View Rear View RKP2417 / RKP2419 RKP2417F / RKP2417X DVI-D Power Power Side View UNIT : mm 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H)

  • Page 8: Installation

    < 1.3 > Installation - How to install Installation Slides Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. Step Complete the installation ■...
  • Page 9 < 1.3 > Installation - How to Use the Dual Slides Figure 1. ■ A black arrow release button is located on the front of each slide. (shown in Figure 1). ■ Pull and hold the black arrow button on either side Figure 2.

  • Page 10: Connection

    < 1.4 > Connection to USB Server via CB-6 cable RKP2417 / RKP2419 / RKP2417F / RKP2417X LCD Console Drawer DVI-D KVM CB-6 VGA console cable USB server < 1.4 > Connection to external KVM via CB-6 cable RKP2417 / RKP2419 / RKP2417F / RKP2417X...
  • Page 11 < 1.4 > Connection to PS/2 or USB Server via CE-6 cable RKP2417 / RKP2419 LCD console drawer LCD console drawer CE-6 Combo CE-6 Combo KVM cable KVM cable PS/2 server USB server < 1.4 > Connection to external KVM via CE-6 cable RKP2417 / RKP2419 LCD console drawer...
  • Page 12 < 1.4 > Connection to USB Server via CX-6 cable RKP2417F / RKP2417X LCD Console Drawer Power DVI-D CX-6 DVI-D console cable DVI-D USB server < 1.4 > Connection to external KVM via CX-6 cable RKP2417F / RKP2417X LCD Console Drawer...
  • Page 13 < Part 2 > < 2.1 > Product Specifi cations - RKP2417 / 2419 RKP2417 RKP2419 Panel Manufacturer Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD Display pixel ( dots x lines ) 1280 x 1024 1280 x 1024 Brightness ( typ.
  • Page 14 < 2.1 > Product Specifi cations - RKP2417 / 2419 Operating Temperature 0 to 55°C degree Environmental Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Physical...
  • Page 15 < 2.1 > Product Specifi cations - RKP2417F / 2417X RKP2417F RKP2417X Panel 17.3-inch Widescreen TFT 17.1-inch Widescreen TFT Panel Size ( diagonal ) color LCD color LCD Display pixel ( dots x lines ) 1920 x 1080 1920 x 1200 Brightness ( typ.
  • Page 16 < 2.1 > Product Specifi cations - RKP2417F / 2417X Operating Temperature 0 to 55°C degree Environmental Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration)

  • Page 17: Keyboard / Mouse Specifi Cations

    < 2.2 > Standard Keyboard / Mouse Specifi cations G keyboard integrated with touchpad G keyboard integrated with trackball 55 ± 5g Key force 3 ± 0.3mm Travelling distance > 10 million life cycle time Switch life Windows / Linux / Unix / Mac OS OS support Supporting layouts America...
  • Page 18 < 2.2 > MAC Keyboard / Mouse Options MAC keyboard integrated with touchpad MAC keyboard integrated with trackball Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts.
  • Page 19 < 2.2 > SUN Keyboard / Mouse Options S keyboard integrated with touchpad S keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...

  • Page 20: On-Screen Display Operation ( Osd )

    < 2.3 > On-screen Display Operation ( OSD ) Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control Exit the OSD screen Go back to the previous on-screen sub-menu or main menu...

  • Page 21: Rkp2417F

    < 2.2 > On-screen Display Operation ( OSD ) RKP2417 / RKP2419 RKP2417F OSD Confi guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock...
  • Page 22 < 2.2 > On-screen Display Operation ( OSD ) Auto adjust : Automatically adjust sizes, centers and fi ne tunes the video signal to eliminate waviness and distortion. Clock : Adjust the clock value Phase : Adjust the phase value H.
  • Page 23 < Part 3 > < 3.1 > RKP2417F Options : 3G / HD / SD-SDI input Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input...

  • Page 24: Hdmi

    < 3.1 > RKP2417F Options : HDMI ( HDMI 1.3, CEA-861-D - HDMI ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen. If so, please adjust the display card setting on display size to fi...
  • Page 25 < 3.1 > RKP2417F Options : Touchscreen & driver F17" USB Touchscreen Specifi cation e-Resistive Model 5-Wire Resistive Technology Single Touch Point Stylus or Finger Method ≤ 50g / Stylus=R0.8 Activation Force 10 million touches Durability 15 ms Response Time 80% ±...
  • Page 26 < 3.1 > RKP2417F Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load...
  • Page 27 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
  • Page 28 < 3.2 > RKP2417X Options : HDMI ( HDMI 1.3, CEA-861-D - HDMI ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen. If so, please adjust the display card setting on display size to fi...
  • Page 29 < 3.2 > RKP2417X Options : Touchscreen & driver X17" USB Touchscreen Specifi cation e-Resistive e-Capacitive Model 5-Wire Resistive Capacitive Technology Single Single Touch Point Stylus or Finger Finger Method ≤ 50g / Stylus=R0.8 ≤ 50g Activation Force 10 million touches 300 million touches Durability 15 ms...
  • Page 30 < 3.2 > RKP2417X Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load 50 mA 50 mA 50 mA...

  • Page 31: Rkp2417 / 2419

    < 3.3 > RKP2417 / 2419 Options : HDMI / DVI-D / S-Video + BNC ( HDMI 1.2, CEA-861-D - HDMI - DVI-D ( DVI-D TMDS single link ( S-Video + Composite, BNC ) - AV ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen.
  • Page 32 < 3.3 > RKP2417 / 2419 Options : Touchscreen & driver 17” / 19" USB Touchscreen Specifi cation 17’ 19” 17” 19” Model e-Resistive e-Capacitive 5-Wire Resistive Capacitive Technology Single Single Touch Point Stylus or Finger Finger Method ≤ 50g / Stylus=R0.8 ≤...
  • Page 33 < 3.3 > RKP2417 / 2419 Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load 50 mA 50 mA...

  • Page 34: Part. 4 > Kvm Integration

    (W x D x H) RKP2417 with KVM 441.6 x 480 x 88 mm 585 x 620 x 190 mm 21.1 kg 27 kg RKP2417F with KVM 17.4 x 18.9 x 3.5" 23 x 24.4 x 7.5” 46.4 lb 59.4 lb RKP2417X with KVM 441.6 x 480 x 88 mm...
  • Page 36 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2017 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-RKP2417-Q317V5 www.austin-hughes.com...
