Table 12: Biss Eds - Common Part - Encoder A36R Technical Reference Manual

Model A36R
Address Symbol
0x0E-0x0F PON_DLY
0x10 DC_NUM
0x11 SL_NUM
0x12 SL_OFF
0x13 --
0x14 BANK1
0x15 DLEN1
0x16 FORMAT1
0x17 CPOLY1
0x18-0x33 n/a
0x34 BC_OFF
0x35-0x3E --
0x3F CHKSUM
Table 12: BiSS EDS – Common Part
1-800-366-5412 | encoder.com | sales@encoder.com
Description
Maximum "power on
delay" until control
communication is
available
Number of data
channels in this device
(number of words)
Area of validity for this
EDS (number of slave
addresses)
Memory location for
this EDS (slave ID within
this device)
Reserved
Bank address for
content description
data channel 1 (profile
EDS)
Data length for channel
1
Data format data
channel 1
CRC polynome (8:1) for
data channel 1
Unused
Bus coupler control
location for this device
(slave ID within this
device)
Reserved
Checksum (additional
bytes within this bank)
PAGE 24 OF 33
T E C H N I C A L R E F E R E N C E M A N U A L
Group Data Format
Timing U16*
SCD U8
SCD U8
SCD U8
-- --
SCD U8
SCD U8
SCD U8
SCD U8
-- --
SCD U8
Prot U8
Orga U8
Unit Value
1 ms 50
-- 1
-- 1
-- 0
-- 0
-- 0x29
To match
ordered
bit
configura-
tion
bit bit
-- 0x21
-- --
-- 0
-- 0
-- xx
EPC Technical Reference Manual – Model A36R
© 2023 Encoder Products Company, REV 11/08/2023
Comments
(DL + err and
warn)
