Model A36R

Figure 9: BiSS timing diagram

Parameter
Permissible Clock Period
Permissible Clock Frequency
Processing Time with Start Bit Delay
Adaptive Timeout at DATA Line
* t measured as first 1.5 x T(CLCK) for each frame.
init

Table 9: BiSS timing and performance characteristics

8.4 Cable Length vs. Frequency

The maximum clock frequency supplied by the master is limited by cable length.
Cable Length
< 150 m (492 ft)
> 150 m
Note: This assumes shielded twisted pair cable and proper termination are used. Lower clock frequency may be required at
extreme cable lengths.

Table 10: Cable length vs. max clock frequency (BiSS C)

1-800-366-5412 | encoder.com | sales@encoder.com
Symbol
t
C
1 / t
C
t
busy
t
out
Max Clock Frequency
10 MHz
5 MHz
PAGE 21 OF 33
T E C H N I C A L R E F E R E N C E M A N U A L
Description
100 ns min
10 MHz
5 x t max
C
Min = 0.075 μs
Typ = t + 0.2 μs *
init
Max = 24 μs
