  • Page 1 S418 Electromechanical Swing Gate Operator UL325 - UL991 FAAC International Inc. FAAC International Inc. Headquarter & East Coast Operations West Coast Operations 3160 Murrell Rd 357 South Acacia Avenue Rockledge, FL 32955 Fullerton, CA 92831 Tel. 800 221 8278 www.faacusa.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION Important Safety Instructions Important Installation Instructions General Safety Precautions UL325 Gate Operator Classifications Installing the Warning Signs DESCRIPTION AND SPECIFICATIONS Dimensions Technical Specifications Electrical Setup INSTALLATION Preliminary Checks Installation Dimensions Installing The Operator Wiring The Operator Mechanical Stops MANUAL OPERATION RESTORING NORMAL OPERATION...
  • Page 3: Important Safety Information

    • Locate one or more non-contact sensors where the risk of entrapment or obstruction exists, such as at the reachable perimeter of a moving gate or barrier. • Use only FAAC “Photobeam” photoelectric eyes to comply with UL325.
  • Page 4: General Safety Precautions

    Install devices such as reversing edges and photo conditions. beams to provide better protection for personal • Use only FAAC MSE MO, CN60 or M60 edge sensors. property and pedestrians. Install reversing devices that are appropriate to the gate design and application.
  • Page 5: Ul325 Gate Operator Classifications

    Installing the Warning Signs This FAAC swing gate operator is supplied with two warning signs to alert people that a possible hazard exists and that appropriate actions should be taken to avoid the hazard or to reduce exposure to it.
  • Page 6: Description And Specifications

    1. DESCRIPTION AND SPECIFICATION The FAAC 418 is an automatic gate operator for swinging gate leafs. It is designed for residential applications and can accommo- date gate leafs up to 12 ft long. The self-contained S418 operator consists of an electric motor that drives a worm screw housed in an aluminum casing.
  • Page 7: Technical Specifications

    2. INSTALLATION Technical Specifications Preliminary Checks Power Supply 24 Vdc The structure of the gate directly influences the reliability Nominal Power 35 W and safety of the automated system. To ensure correct operation, the structure of the gate must have the following Absorbed Current 1.5 A characteristics:...
  • Page 8: Installing The Operator

    2.2.1 General Rules for Determining Installation Values • To obtain opening of the leaf to 90°: A+B=C. If pillar dimensions or hinge position do not allow the installa- tion of the operator, cut a niche into the pillar (as shown in Fig. •...
  • Page 9 Install the rear bracket as shown in Figure 10, so as to follow the A and B values determined previously. 2⅛ Fig. 12 1⅜ Fig. 13 Fig. 10 Dimensions in Inches Secure the rear fork of the operator as indicated in Figure Secure the front bracket to the operator as indicated in Figure 14 Fig.
  • Page 10: Wiring The Operator

    Secure the operator to the rear bracket using the supplied bolt, as indicated in Fig. 15. Fig. 17 Disengage the operator’s manual release (see Par. 3) and move the leaf manually, checking that it completes the entire swing, stopping at the mechanical stops. If during this test the operator hits the leaf of the gate, the value E may be increased, (see Fig.
  • Page 11: Manual Operation

    Move the mechanical stop until it is close to the front side of the bracket, as indicated in Fig. 22. Tighten the bolt. The mechanical stop is coupled to a toothed section on the operator's body, Fig. 21 Ref. 2. In case of difficulties moving the stop check that the coupling is free.
  • Page 12: Restoring Normal Operation

    For repairs, refer to FAAC authorized service centers. NOTE: During the first cycle, the operator might not slow down correctly. Wait for the end of the cycle and then give the...
  • Page 13: Spare Parts Diagram

    5. SPARE PARTS DIAGRAM Part Part Number Description Part Part Number Description 713002 Manual Release Key 718367 Pin With C Clip 63001555 Manual Release Cover 60202355 Worm Gear Bushing 63001565 Manual Release Assembly 63001545 Screws ø4.8x13mm 63001575 Operator Body 63001535 Front Cap Bracket Kit (front and rear Cable Gland M16 x 1.5...
  • Page 14 1. E024U CONTROL BOARD DESCRIPTION & CHARACTERISTICS SETTING DL14 DL15 DL16 DL17 DL18 DL19 DL20 DL21 DL22 Fig. A1 1.1 TECHNICAL SPECIFICATIONS 1.2 LAYOUT AND COMPONENTS Main power supply RADIO 115 V~ 60 Hz Connector for the radio receiver Secondary power BATTERY 24 Vdc - 16 A max.
  • Page 15 2. INPUT / OUTPUT DESCRIPTION Encoder 24 VDC Maglock B STP CL OP OPEN Fig. A2 LABEL FUNCTION 2 EASY 2 EASY 2easy BUS input for encoders (S800H and S450H only), XIB and loop detector boards OPEN A N.O. Contact for total opening command OPEN B: N.O.
  • Page 16 3. SAFETY DEVICE CONNECTIONS Entrapment protection To comply with the UL325 standard for gate operators every Connection of One Pair of Monitored Closing Photocells entrapment zone, as defined in ASTMF2200, must be pro- tected by two independent entrapment protection devices. One of the devices is inherent in the E024U control boards design, the other can be external, like a photocell or an edge sensor.
  • Page 17 Only one monitored photocell can be connected to the Connection of One Pair of Closing Photocells Closing or Opening safety inputs. More than one photocell (monitored), One Pair of Opening Photocells or other device can be connected to the safety inputs, but (monitored) and One pair of Opening/Closing they will not be monitored.
  • Page 18 4. PROGRAMMING 4.1 DIP SWITCH DS1 SETTINGS FOR OPERATING LOGIC OPERATING LOGIC DS 1: SW 1 - SW 2 - SW 3 PAUSE LOGIC SW 1 SW 2 SW 3 DESCRIPTION TIME E (default) One command opens, the next one closes. A command during opening stops the gate Semiautomatic 0 - 4...
  • Page 19 4.2 ADJUSTING TRIMMERS – FORCE ADJUSTMENT MOTOR 1 Turn clockwise to increase the opening and closing force TR 2 – FORCE ADJUSTEMENT MOTOR 2 Turn clockwise to increase the opening and closing force TR 3 – SPEED ADJUSTMENT FOR MOTOR1 AND MOTOR 2 Turn clockwise to increase the opening and closing speed TR 4 –...
  • Page 20 4.3 DIP SWITCH DS1 SETTINGS FOR BOARD SETUP BOARD SETUP DS 1: SW 4 to SW 12 The opening of leaf 2 is delayed after the opening of leaf 1. This is to OPENING DELAY SW 4 avoid that the gate’s leafs interfere with each other during the initial part 0 sec (default) of the movement.
  • Page 21 4.4 DIP SWITCH DS2 SETTINGS FOR OPERATOR TYPE AND LOCK MODE SETTING DL 1 DL 2 DL 3 DL 4 DL 5 IMPORTANT DS 2 DS 2 OPERATOR SELECTION LOCK OUTPUT MODE OPERATOR TYPE SW 1 SW 2 SW 3 OUTPUT MODE SW 4 S450H, S800H...
  • Page 22 LED STATUS In BOLD the normal state with gate closed and working DESCRIPTION ON STEADY BLINKING Board working on AC Board working on LED BATTERY power battery power or ext Battery charging supply LED +24 Main power OFF Main power present SLOW BLINK (1 sec.
  • Page 23 The diagnostic LED shows only one error condition at a time, with the priority of the below table. In case there is more than one error once one is eliminated the LED will show the next LED ERROR DISPLAY NUMBER OF ERROR CONDITION SOLUTION FLASHES...
  • Page 24 At the point where you want the slowdown to start give an This is a more detailed description of what happens after an OPEN A command with the push button or the remote that obstacle detection: is already stored in memory. Leaf 2 starts to slow down and stops when it reaches the mechanical stop or FCA2.
  • Page 25 On the back panel there are: the control board, the power supply AC POWER CONNECTION and additional accessories. To connect AC power to the controller: 1. Turn the circuit breaker for the AC gate operator power OFF Power outlet before connecting the AC input wires. AC connection and switch 2.
  • Page 26 For the upgrade you need a USB Flash Drive, where you have BLACK 12VDC, 8 amp Battery to copy the file supplied by FAAC. Then follow these steps: JUMPER Disconnect the batteries if they are present. 12VDC, 8 amp Turn the AC power off and insert the Flash Drive into the...
  • Page 27 11. FUNCTION LOGICS LOGIC “E” PULSES SYSTEM STATUS OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP no effect no effect no effect CLOSED opens the leaves opens leaf 1 no effect (OPEN disabled) (OPEN disabled) (OPEN disabled) stops and opens at release immediately stops operation...
  • Page 28 LOGIC “EP” PULSES SYSTEM STATUS OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP no effect no effect no effect CLOSED opens the leaves opens leaf 1 no effect (OPEN disabled) (OPEN disabled) (OPEN disabled) stops and opens at release immediately OPENING stops operation (1) stops operation...
  • Page 29 LOGIC “B” PULSES SYSTEM STATUS OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP no effect no effect no effect CLOSED opens the leaves no effect no effect (OPEN disabled) (OPEN disabled) (OPEN disabled) stops and, at release, closes OPENING no effect closes leaves...
  • Page 30 FAAC S.p.A. or FAAC International, Inc. The warranty herein FAAC International, Inc.’s obligations under above set forth shall not be deemed to cover...
