- Page 1 E1SL SDK EVO LK EVO KS EVO Instructions valid starting from the FW updates supplied with ZIPACK 4.5.0.
- Page 2 FAAC S.p.A. Soc. Unipersonale Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY Tel. +39 051 61724 - Fax +39 051 09 57 820 www.faac.it - www.faacgroup.com...
-
Page 3: Table Of Contents
1. ELECTRONIC MODULE E1SL ........ -
Page 4: Electronic Module E1Sl
1. ELECTRONIC MODULE E1SL The E1SL electronic module is designed to control FAAC automation risks that are not covered by the standard or by the manufacturers of models A1000, A1400 AIR, RKE 1400, SF1400, GBF1500. The instal- the components. FAAC S.p.A. recommends that you always comply lation instructions must be followed. -
Page 5: Status Leds On The Board
Removable terminal board configurable outputs O1, O2 Connector for main power supply 36 V, 4 A Connector for motor M1 Connectors for Simply Connect (accessory device) Connector for motor M1 encoder Connector for motor block and monitoring Jumper INTERCOM 4 E1SL 532258 04 - Rev. E... -
Page 6: Dm Board
(3). 2. Unscrew the 2 screws (4) and remove the plastic cap, pulling out the 2 pins (5). 3. Install the DM board Refer to 6, install the 4 posts (6) on the E1SL DL11 RESET/SETUP board and fasten them using the screws provided (7). Insert the 2 comb connectors into the connectors of the E1SL board as far as the connector (8). - Page 7 Installing the DM board 6 2 nd MOTOR connection black 7 E1SL 532258 04 - Rev. E...
-
Page 8: Operating Mode Modfun
TOTAL 100% NIGHT PARTIAL ( * ) TOTAL 100% INTERLOCK TWO-DIRECTIONAL PARTIAL ( * ) TOTAL 100% INTERLOCK EXIT ONLY PARTIAL ( * ) TOTAL 100% INTERLOCK ENTRY ONLY PARTIAL ( * ) E1SL 532258 04 - Rev. E... -
Page 9: Connections
- XV1 or XDT1 detectors, single or double, exit and entry, for opening and safety in closing - XBFA ON detectors for safety in opening - Configurable inputs - Configurable outputs - LK EVO, KS EVO, SDK EVO function selectors E1SL 532258 04 - Rev. E... -
Page 10: Configurable Inputs
…NO/NC (the contact logic must be programmed according to the type of contact DL11 of the device) …TEST (available for inputs configured as Safeties) BAT1 BAT2 SIC _ OP SIC _ CL EMERG OPEN E1SL 532258 04 - Rev. E... -
Page 11: Automatic Opening Inputs
EXTERNAL CLOSING SAFETY (24) As CLOSING SAFETY (20) but intended exclusively for the detector located outside the premises. INTERNAL CLOSING SAFETY (25) As CLOSING SAFETY (20) but intended ex- clusively for the detector located inside the premises. E1SL 532258 04 - Rev. E... -
Page 12: Configurable Outputs
LOW BATTERY (23) indicates that the charge level of the emergency BAT2 SIC _ OP SIC _ CL battery is too low for the movements to be carried out. EMERG OPEN NIGHT (24) indicates that the door is in NIGHT mode. E1SL 532258 04 - Rev. E... -
Page 13: Start Up
4.2 version (example) interrupted: NIGHT or MANUAL mode, operating on battery due to (example) lack of mains power, emergency Inputs active. (SDK EVO FW version) (E1SL FW version) ERROR 39 flashing flashing light (the board requires SETUP) (the board requires SETUP) SETUP from board 3. -
Page 14: Programming The Board
SDK EVO can disable programming from the board: /PROGRAMMING/MISCELLANEUS/BOARD'S DISPLAY BLOCKED or NOT BLOCKED PROGRAMMING FROM THE BOARD The E1SL has two Programming Menus: Basic and Advanced (relative Access ADVANCED programming Table). ■ BASIC programming 1. When the display indicates the status of the automation, press... -
Page 15: Basic Programming
Opening force level … Force time on obstacle for CF and OF … s Adjustment step = 0.1 s Deceleration ramp when OP and CL level … Acceleration ramp when OP and CL level … E1SL 532258 04 - Rev. E... - Page 16 Door ERROR (Press + and - simultaneously to display the in NIGHT PAUSE active ERROR) CLOSING LO-L2 SETUP in progress - phases OPEN or STOPPED or CLOSED in EMERGENCY in SLEEP mode (flashing dot) in MANUAL operating mode E1SL 532258 04 - Rev. E...
-
Page 17: Advanced Programming
= second motor kit enabled NIGHT-TIME MODE DELAY ( s … min) = not enabled … s Adjustment step = 1 s … min Adjustment step = 10 s (e.g. = 1 min and 20 s) E1SL 532258 04 - Rev. E... - Page 18 Press the F button to confirm. After exit, the display shows automation status (See in Basic programming) INPUTS status Shown on the Advanced Programming display, function segment lit = input active The central dot is always lit (OFF = segment always off) Manual Release Safeties TEST E1SL 532258 04 - Rev. E...
-
Page 19: Movement Parameters
100% INT+EXT partial open increases automatically to 100% if the internal and EN 13849) is recommended, to monitor the full width of the door in external sensors are engaged at the same time (it reverts to the set percentage when E1SL 532258 04 - Rev. E... -
Page 20: Date And Time
Programming is carried out via the SDK EVO, it requires a clock bat- - from Board Advanced Programming: tery to be installed on board E1SL (2) and the date and time to - from SDK EVO: /PROGRAMMING/TIMING/NIGHT SENSOR DELAY be set correctly. -
Page 21: Enabling/Disabling The Timer
NIGHT mode) and output OUT2 indicates LOW BATTERY - the charge TEST via battery opening is enabled even if there is mains power and if the charge level is low, the door remains open until it has been restored. E1SL 532258 04 - Rev. E... -
Page 22: Xb Lock Motor Block And Monitoring Optional
(if present) before connecting or disconnecting the motor block. 1. Install the motor block following the installation instructions. 2. Connect the motor block to the E1SL board using the connector (A). 3. If installed, connect the monitoring device (B) to the terminal board of the motor block. -
Page 23: Xm Lock Motor Block And Monitoring
(if present) before connecting or disconnecting the motor block. 1. Install the motor block following the installation instructions. 2. Connect the motor block to the E1SL using the connector (A). 3. If installed, connect the monitoring device (B) to the terminal board of the motor block. -
Page 24: One Dual Technology Entry And Exit Detector
1. With the board switched off, connect the external detector and the internal detector. Follow the colour coding of the wiring shown in the figure. 2. Turn power on to the E1SL board. The detectors turn on. 3. Carry out the SETUP procedure for each detector (see the device internal 12... -
Page 25: Dual Technology Entry And Exit Detectors
SERIES connection of 2 external infrared detectors and 2 internal infrared detectors. External Internal pink pink DL11 XDT1 XDT1 grey grey pink pink BAT1 XDT1 XDT1 BAT2 grey grey SIC _ OP SIC _ CL EMERG OPEN 14 E1SL 532258 04 - Rev. E... -
Page 26: Infrared Detector For Safety In Opening
1. With the board switched off, connect the detectors. Follow the colour coding of the wiring shown in the figure. 2. Turn power on to the E1SL board. The detectors turn on. internal 3. Carry out the SETUP procedure for each detector (see the device instructions). -
Page 27: Xfa Button Photocells
+ RX1 + TX2 + TX1 blue grey blue grey grey grey 2nd pair receiver connection GND Receiver negative 1st pair receiver connection 2nd pair transmitter connection GND Transmitter negative 1st pair transmitter connection 18 E1SL 532258 04 - Rev. E... -
Page 28: Intercom
9. INTERCOM INTERCOM is the network of connected FAAC automatic doors that Cascade connection. JUMPER J26: ONLY on the first and last board can be programmed via SDK EVO or Simply Connect (specific instruc- of the cascade connection, remove it from intermediate boards (if tions). -
Page 29: Interlock
OPEN the access. If this condition is not met, the OPEN command is not executed and an "OPEN-request” is generated. The "OPEN- request” it is carried out as soon as both accesses are closed again. E1SL Use one-direction radar detectors (see relative section). INTERLOCK is not available on E1RD boards. -
Page 30: Airslide
2. With the mains power supply switched off and the emergency battery disconnected, make the network connection between the boards. 3. Turn power on to the boards. 4. With the SDK EVO connected to the E1SL, assign ID 1 to E1SL and then enable AIRSLIDE: E1AS (AIRSLIDE) - /PROGRAMMING/INTERCOM/ID: …... -
Page 31: Interleaves
MODFUN input The MODFUN is set on the MASTER (ID1). TIMER input The TIMER is set on the MASTER (ID1). INSTALLING INTERLEAVES With SDK EVO connected to the first E1SL: 1. With both boards switched off, connect the boards together - /PROGRAMMING/INTERCOM…... -
Page 32: Fw Updates And File Download Usb
SDK EVO allows the firmware versions (APP) of the SDK EVO, the appears on the display). E1SL board, the DM board, if the DM KIT is installed, and the installed It is not necessary to remove the USB storage device. -
Page 33: Diagnostics
input not active (sensors not engaged) ‘ (GREEN) mergency Input ■ EMERG ˜ input active (door opened in emergency) input not active ‘ (GREEN) ■ OPEN INPUT ˜ input active input not active ‘ E1SL 532258 04 - Rev. E... -
Page 34: Fw Versions
The FW version of the board appears on the display when you switch it CLOSED on. SDK EVO allows the FW versions of the SDK EVO, the E1SL board, OPENING the DM board, if the DM KIT is installed, and the installed devices to be displayed. -
Page 35: Errors, Alarms/Info Codes
Check the accessories protection fuse (on boards fitted with one). Perform the RESET. If the problem persists, replace the control board. Make sure that there are no sources of electromagnetic interference too close to the board. Update E1SL FW fault FW. - Page 36 SETUP IN PROGRESS The SETUP is in progress. The notification remains as long as the phase is in progress. E1SL is operating on battery, in SLEEP mode. To prevent the emergency battery from being discharged, power Battery saving operating to the accessories is switched off apart from to the SDK EVO.
-
Page 37: Reset
RESET from configured input Input Terminal board Button ↑ + ( 5 s) After 5 s the corresponding LEDs ( ↑ and ) start to flash. RESET Release when the Error LEDs turn off. E1SL 532258 04 - Rev. E... -
Page 38: Restoring Factory Settings
Automation in NIGHT-TIME mode. Automation in MANUAL mode. The door does not perform SETUP Active internal or external release. The emergencies are active. Motor or encoder not connected, not powered or faulty. E1SL 532258 04 - Rev. E... -
Page 39: Lk Evo
LOCK / UNLOCK Press for approximately 5 s to Lock/Release •Ž + ( 5 s) SWITCHING ON Turn power on to the E1SL board. the keypad (the LEDs turn on and then off) - The LEDs turn on and off in sequence, then the LED corresponding RESET (the LEDs corresponding to the Error flash until the •... -
Page 40: Led Error Coding On Function Selectors
Ý Ý FW 2.6 FW 2.7 Ý Ý Ý Ý FW 2.8 Ý Ý Ý Ý Ý Ý Ý FW 2.9 Ý Ý Ý Ý FW 3.0 Ý Ý Ý Ý Ý FW 3.1 E1SL 532258 04 - Rev. E... -
Page 41: Ks Evo
Automatic partial two-direction SWITCHING ON Night Turn power on to the E1SL board. - The LEDs turn on and off in sequence, then the LED correspond- Manual ing to the active operating mode remains on (apart from manual mode). -
Page 42: Sdk Evo
6. Fasten the display using the screw (4) and insert the screw cover (5). 4x2xAWG24 SWITCHING ON Turn power on to the E1SL board. The device turns on and displays a series of screens: V RX TX G G K - power-on screen - Bootloader: displays the Bootloader version (x.x NOT updatable) -
Page 43: Home Page
- select ( ↑ ↓ ) and confirm (OK) the digits of the PSW one by one, then confirm the * the TECHNICIAN PSW is required to access the programming func- complete PSW tions in the MENU 34 E1SL 532258 04 - Rev. E... -
Page 44: Modfun
- ESC button to go back to the HOMEPAGE - OK button to access the function/confirm the programming and go back to the MENU MENU > 1 LANGUAGE PROGRAMMING ERRORS WARNINGS ↑ ↓ 35 E1SL 532258 04 - Rev. E... -
Page 45: Sdk Evo - Functions Menu
OK Ž see § Diagnostics JOLLY SLOTS ERRORS TECHNICIAN PSW OK Ž see § Diagnostics WARNINGS PASSWORD USER PSW CYCLES COUNT OK Ž OK Ž SDK EVO COUNTERS INFO E1SL SAFE FLOW ---- DM (*) Simply Connect E1SL 532258 04 - Rev. E... - Page 46 INPUTS S1- S2 CONSECUTIVE START SETUP OBST. INPUTS E1- E2 INPUTS STATUS TEST ERROR PHOTOCELLS XFA DOOR STATUS BACKLIGHT DISPLAY OK Ž MOTION OPENING OTHER BOARD DATA ELASTIC KIT CLOSING MOVEMENT DAMP. STOP MOV E1SL 532258 04 - Rev. E...
-
Page 47: Menu 1 Language
10 INTERCOM Allows you to bring the stop position forwards with respect to the opening stop: level 1…10 (0 = minimum distance) Program the NODE from the INTERCOM network if provided (relative § Section). E1SL 532258 04 - Rev. E... -
Page 48: Menu 3 Errors
BLOCK SDK EVO works with password when the contact is open and is locked when It allows the number of people in the premises (0 ... 1000) to be corrected manually the contact is closed. E1SL 532258 04 - Rev. E... -
Page 49: Menu 6 Date / Time
MENU 9 INFO IN SLAVE parameter, displayed only on the SLAVE boards. Allows the firmware versions (APP) of the SDK EVO, the E1SL board, the DM board, if the DM KIT is installed, and of the installed devices to be viewed. -
Page 50: Simply Connect
BAT1 BAT2 SIC _ OP SIC _ CL Simply Connect requires E1SL firmware version FW 4.0 or later. EMERG OPEN When programming is taking place via Simply Connect, programming via the board/SDK EVO is inhibited ( on the display). - Page 51 E1SL 532258 04 - Rev. E...
