  • Page 1 Plasma cutter SPARTUS® EasyCUT 40sL User’s manual...
  • Page 2 Therefore, our offer covers such a wide assortment of products. Thank you very much for your trust in our company. We would like to invite you to familiarize yourself with the remaining products and offer at www.spartus. info or directly at a local distributor of SPARTUS® products.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. SAFE USE – HAZARDS ASSOCIATED WITH ARC WELDING AND PLASMA CUTTING ..... 2 1.1 General safety rules ..............................2 1.2 Electric shock can kill ..............................2 1.3 Welding arc radiation can be dangerous ......................3 1.4 Vapours and gases can be dangerous ......................... 3 1.5 Noise can be harmful ..............................
  • Page 4: Safe Use - Hazards Associated With Arc Welding And Plasma Cutting

    USER’S MANUAL 1. SAFE USE – HAZARDS ASSOCIATED WITH ARC WELDING AND PLASMA CUTTING Arc welding and plasma cutting are processes feeder fitted with spool and harness). Care that can pose hazards for the operator and per- shall be taken during manual handling. sons in his vicinity.
  • Page 5: Welding Arc Radiation Can Be Dangerous

    USER’S MANUAL • Power supply must never be connected Such radiation can be direct or reflected from before the accessories of SK sockets/con- surfaces such as bright metals and light colo- nectors are properly installed in the device. ured objects. •...
  • Page 6: Noise Can Be Harmful

    USER’S MANUAL Arc welding and allied processes produce wel- in case of an emergency, are in the imme- ding fume which may pollute the atmosphere diate vicinity. surrounding the work. Welding fume is a vary- • In closed rooms or in certain circumstances ing mixture of airborne gases and fine particles during outdoor operations, it may be re- which, if inhaled or swallowed, constitute a...
  • Page 7: Fire Or Explosion Hazard

    USER’S MANUAL source, observed for an adequate period after its c) effective maintenance of sound protection termination. devices, • „Hot spots” and immediate surroundings d) indication as „ear protection areas” where should be observed until their temperature applicable, has dropped to normal. e) restriction of entry to these „ear protection 1.6.2 Explosion hazard areas”...
  • Page 8: Other Hazards

    USER’S MANUAL 1.7.4 Moving elements can be dangerous cylinder valve socket when the valve is being opened. • Special valve shield should always be in- stalled during cylinder transportation or when the cylinder is not used. OTHER HAZARDS Arc welding and allied processes carrying other All protective elements and device housing hazards not listed before.
  • Page 9: Extra Precautions

    USER’S MANUAL 1.9 EXTRA PRECAUTIONS 1.9.1 Potential risk during plasma cutting • during the plasma cutting – plasma arc temperature exceeds a few thousands °C, • large light radiation is accompanied when plasma cutting as a result of burning gases and the igniting of a plasma arc, •...
  • Page 10: Electromagnetic Compatibility (Emc)

    Methods of reducing electromagnetic interference are listed in detail in the standard EN 60974-9 – „Arc welding equipment – Part 9: Installation and use”. 4. CONFORMITY WITH STANDARDS SPARTUS® EasyCUT 40sL are in conformity with the relevant Union harmonization legislation: LVD 2014/35/UE Low Voltage Directive...
  • Page 11: Ce Marking

    20 – 40 amps. Device’s front panel is equipped with a SK so- cket and the plasma torch socket. SPARTUS® EasyCUT 40sL device has a lot of modern solutions to support the process of plasma cutting and functioning of the device. Built-in system of contactless pilot arc ignition without HF –...
  • Page 12: Technical Parameters Of Device

    Dimensions [mm] 415 × 145 × 245 7. INSTALLATION AND USE WARNING! SPARTUS® EasyCUT machines are intended for professional and industrial applications. Installation and use of the device may only be carried out appropriately trained professionals. It is forbidden to shorten the length of the condensate drain pipe. The hose should always reach a little above the ground - below the lower edge of the devices rear panel.
  • Page 13: Proper Cooling

    USER’S MANUAL 7.1 PROPER COOLING The unit should be placed stable on a dry and flat surface. Avoid too much slope and slippery surfaces. Check regularly that the vents (inlet, outlet) are not covered. The minimum distance between the machine vents and walls should be 50 [cm]. 7.2 MOVEMENT AND HANDLING Please take special care when moving the machine.
  • Page 14: Connection Of The Device

    USER’S MANUAL Before connecting the unit to the power source: • Check whether the parameters comply with the requirements for unit. • Check: mechanical condition of the power cord and plug. The connection status of the power cord with plug and unit (loose not allowed). If the power cord or plug is damaged or loose connection is between them, it is forbidden to connect the cutter until fault has been rectified.
  • Page 15: Control Panel - Using

    Function Select Button (gas check, 2T/4T switch) 7.7 THE PROCESS OF CUTTING SPARTUS® EasyCUT 40sL are equipped in standard with system of contactless arc ignition wit- hout HF – high-frequency generator. There is no need for the nozzle tip to contact the surface to ignite the plasma arc.
  • Page 16: Central Connector - Setup Of Pins

    USER’S MANUAL 7.8 CENTRAL CONNECTOR – SETUP OF PINS The device and plasma torch are equipped with central connector. Start – Stop Pilot Arc 7.9 RECOMMENDED PLASMA TORCH SPARTUS® SP45H (standard TRAFIMET® S45) plasma torch SPARE PARTS CODE DESCRIPTION 09600...
  • Page 17: Maintenance

    USER’S MANUAL 8. MAINTENANCE WARNING! Before performing any maintenance or repairing of device, it should be disconnect from the power source and wait at least 5 minutes. The voltage accumulated in capacitors should be discharged at this time to a safe level. But even after that operation you should be careful. Maintenance and repair work may be performed only by qualified personnel with the appropriate per- missions.
  • Page 18: Troubleshooting

    10. TROUBLESHOOTING Not all problems with functioning of the device, are the evidence of failure. You can independently carry out an analysis in search of probable failure. In case of doubt, please contact to SPARTUS® dealer or authorized service center.
  • Page 19 A masterly combination of high quality production, excellent parameters and ergonomics – these are fea- tures of the SPARTUS® Master series of devices, which were created with demanding welding jobs in mind. Precision, functionality, excellent parameters and resistance to high workloads –...
