KAKA Industrial W-2416Z Operation Manual

Operation Manual
KAKA Industrial
SPECIFICATIONS
Stock No. .....................................173121
Model.........................................W-2416Z
Bend Length.........................24" (610mm)
Bend Thickness(mild stee*l).....................
........................................16ga. (1.52mm)
Bend Thickness(stainless steel**)............
......................................20ga. (0.912mm)
Bend Angle........................0-135 degrees
Box Depth............................1.18" (30mm)
Minimum Reverse Bend....0.625" (16mm)
Floor Stand...........................................No
Shipping Dimensions.........34" x 14" x 18"
Shipping Weight...............185 lbs. (85 kg)
(Based on a material tensile strength of
*64000 PSI – mild steel **100000 PSI –
stainless steel )
DESCRIPTION
The W-2416Z
operated and capable of bending up to
16ga. (1.52mm) mild steel and 20ga.
(864 x 356 x 457mm)
Pan Brake is
(.912mm) stainless x 24" (610mm) long.
The machine has 5 removable fingers and
a 1.18" (30mm) box depth allowing it to
fabricate pans, boxes, channels, angles,
and other
counterweights allow the operator to
balance the bending leaf to correspond to
material thickness.
Note
The photos illustrations using in this
manual are representative only and may
not depict the actual color, labeling or
accessories and may be intended to
illustrate technique only.
Note
The specifications
presented here are subject to change
without prior notice due to improvements
of our products.
SAVE THESE INSTRUCTIONS
(Refer to them often and use them to
instruct others.)
hand
PROTECT EYES
Wear safety glasses or suitable eye
- 1 -
®
shapes.
and
W-2416Z
Adjustable
dimensions
