KAKA Industrial SBG-40 Operation Manual

Operation Manual
KAKA
Specifications
Model............................................SBG-40
Stock No. .....................................173203
Bending strength :
28-1/2 Tons per square inch(4.42T)Flat
Maximum
Capacities(Steel & iron) :
5/8"Round stock(16mm)
1/2"X 1/2"Squre stock(13X13mm)
1-3/16"X5/16"Strip stock(30X8mm)
Maximum capacities (Wrought iron) :
15/32"Round stock(12mm)
13/32"X 13/32"Squre stock(10X10mm)
1-3/16"X1/4"Strip stock(30X8mm)
Maximum capacities (Brass & Copper) :
5/8"Round stock(16mm)
15/32"X 15/32"Squre stock(12X12mm)
1-3/16"X5/16"Strip stock(30X8mm)
Maximum capacities (Aluminum) :
23/32"Round stock(18mm)
19/32"X 19/32"Squre stock(15X15mm)
1-3/16"X13/32"Strip stock(30X10mm)
®
Industrial
Unpacking
The UNIVERSAL BENDER is shipped
from the manufacture in a carefully
packed Carton box. Thoroughly inspect
the product upon opening the package.
After unpacking the unit, carefully inspect
for any damage that may have occurred
during transit.
If damage
damage claims must be filed with the
carrier and are the responsibility of the
user.
Check for completeness. Immediately
report missing parts to dealer.
Carefully open crate and unbolt brake
from shipping pallet and remove from
crate using heavy duty lifting equipment
such as an overhead crane.
Warning
The warnings, cautions and instructions
discussed in this instructions or situations
that could occur. It must be understood by
the operator that common sense and
caution are factors which cannot be built
into this product, but must be supplied by
the operator.
- 1 -
has occurred,
SBG-40
shipping
