Unpacking

The manual bead bending machine is shipped
from the manufacturer in a carefully packed
ply-wood case. Thoroughly inspect the product
upon opening the package. After unpacking
the unit, carefully inspect for any damage that
may have occurred during transit. Check for
loose, missing, or damaged parts.
Shipping damage claims must be filed with the
carrier and are the responsibility of the user.

Specifications

Max. thickness......................1.2 mm (18 Ga)
Cylinder length........................140 mm (5-1/2")
Throat depth..........................200 mm (8" )
Center distance between the rollers....56 mm (2.2" )
Overall dimension....631.83 mm x 269.88 mm
x 498.48 mm (24-7/8" x 10-5/8" x 19-5/8")
Weight ...................................46 kg(106 lbs)

Important:

The manual bead bending machine is supplied
with a protective coating which should be
removed before operation. Remove this
coating with a mild solvent, such a s mineral
spirits using a soft cloth. Avoid getting cleaning
solution on paint or any of the rubber or plastic
parts. Solvents may deteriorate these finishes.
Use soap and water on paint, plastic or rubber
components. After cleaning, cover all exposed
surfaces with a light coating of oil.
WARNING
Never use highly volatile solvents.
Non-flammable solvents are recommended
to avoid possible fire hazard.
SAVE THESE INSTRUCTIONS
Thank you for purchasing The Manual
Bead Bending Machine. Before attempting
to operate your new tool please read
these instructions thoroughly. You will
need these instructions for the safety
warnings, precautions, assembly, operation,
Maintenance procedures, parts list and
diagrams. Keep your invoice number with
these instructions. Write the invoice number
on the inside of front cover. Keep the
instructions and invoice in a safe, dry place for
future reference.

General Safety Information

CAUTION
Always follow proper operating procedures
as defined in this manual even if you are
familiar with use of this or similar tools.
Remember that being careless for even a
fraction of a second can result in severe
personal injury.
