KAKA Industrial BP-1650 Operation Manual

Operation Manual
KAKA
Specifications
Model..........................................BP-1650
Stock No. ......................................173030
Max. bending length.......... 1270mm / 50"
Max. thickness................... 1.5mm / 16Ga
Max. box depth....................... 100mm /
4"
Max. lift of beam.................. 32mm / 1
1/4"
Beam adjustment.................... 16mm 5/8"
Finger nose angle............................... 45°
Packing size......................
cm
N.W./G.W. ........... 202/247 kg 444/543lbs
Unpacking
The ARBOR PRESS is shipped from the
manufacture in a carefully packed Carton
box. Thoroughly inspect the product upon
opening the package. After unpacking the
unit, carefully inspect for any damage that
may have occurred during transit.
®
Industrial
168x59x82
If damage
damage claims must be filed with the
carrier and are the responsibility of the
user.
Check for completeness. Immediately
report missing parts to dealer.
Carefully open crate and unbolt brake
from shipping pallet and remove from
crate using heavy duty lifting equipment
such as an overhead crane.
Warning
The warnings, cautions and instructions
discussed in this instructions or situations
that could occur. It must be understood by
the operator that common sense and
caution are factors which cannot be built
into this product, but must be supplied by
the operator.
SAVE THIS MANUAL
You will need this manual for the safety
instruction,assembly
operating procedures, parts list, and
diagram. Write your invoice number on
the inside front cover. Put both your
manual and invoice in a safe, dry place for
future reference.
- 1 -
has occurred,
instruction,
BP-1650
shipping
