KAKA Industrial TR-60 Operation Manual

Operation Manual
KAKA Industrial
Unpacking
T h e Tu b e R o l l e r i s s h i p p e d f r o m t h e
manufacturer in a carefully packed ply-wood
case. Thoroughly inspect the product upon
opening the package.
Thoroughly inspect the product upon opening
the package. After unpacking the unit,
carefully inspect for any damage that may
have occurred during transit. Check for loose,
missing, or damaged parts. Immediately report
missing parts to dealer.
If damage has occurred, shipping damage
claims must be filed with the carrier and are
the responsibility of the user.
Specifications
Material
Flats
C Channel
Pipe Tube
Round Tube
Square Tube
Rect. Tube
WARNING
The warnings, cautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions or situations
that could occur. It must be understood
by the operator that common sense and
caution are factors which cannot be built
into this product.
Size Minimum Radius
1
"
10 "
1
4
"
1X2" 60
1
" 20 "
1
2
1
To 2" 因材料不同而不同
ACCORDING TO MATERIAL
4
"
2" 70
60 "
1X2"
Important:
The tube roller is coated with a protectant.
To ensure proper fit and operation, remove
coating. Coating is easily removed with mild
solvents, such as mineral spirits, and a soft
cloth. Avoid getting cleaning solution on paint
or any of the rubber or plastic parts. Solvents
may deteriorate these finishes. Use soap and
water on paint, plastic or rubber components.
After cleaning, cover all exposed surfaces with
a light coating of oil.
Appearance of the machine
WARNING
Never use highly volatile solvents. Non-
flammable solvents are recommended to
avoid possible fire hazard.
SAVE THESE INSTRUCTIONS
Thank you for purchasing TR-60 Tube Roller
machine. Before attempting to operate your
— 1 —
®
