Introducing the FTB-1v2 and FTB-1v2 Pro
Top panel
FTB module
(shown in grey)
Battery compartment
door (high-power
dual carrier only)
FTBx module
(shown in grey)
Headset/microphone port
(for any commercially available stereo
headset equipped with a microphone,
and having a 3.5 mm connector)
(for any commercially available microSD card
compatible with the Secure Digital eXtended
Capacity (SDXC) format)
4
MicroSD card slot
Ethernet (RJ-45) port
USB 3.0 host port
Built-in power meter and
VFL (optional)
Detector port of the
power meter
VFL port of the power meter;
laser radiation emitted at this
port when VFL is active
USB 2.0 host ports
FTB-1v2 and FTB-1v2 Pro
