PARTS LIST
ITEM QTY REFERENCE
75 2 U10, U11
76 1 U12
77 2 XJP1, XJP2
78 1 Y1
DC2085A-A Required Circuit Components
1 1
2 1 U1
DC2085A-B Required Circuit Components
1 1
2 1 U1
DC2085A-C Required Circuit Components
1 1
2 1 U1
DC2085A-D Required Circuit Components
1 1
2 1 U1
DC2085A-E Required Circuit Components
1 1
2 1 U1
DC2085A-F Required Circuit Components
1 1
2 1 U1
PART DESCRIPTION
I.C., LOW DROPOUT REGULATOR, 3×3mm, DFN
I.C., 80V IDEAL DIODE, DFN-6L
SHUNT, 2mm
CRYSTAL, 12.0 MHz, SMT
GENERAL BOM
IC, 16-BIT 2.5Gsps DAC
GENERAL BOM
IC, 14-BIT 2.5Gsps DAC
GENERAL BOM
IC, 11-BIT 2.5Gsps DAC
GENERAL BOM
IC, 16-BIT 2.7Gsps DAC
GENERAL BOM
IC, 14-BIT 2.7Gsps DAC
GENERAL BOM
IC, 11-BIT 2.7Gsps DAC
DEMO MANUAL DC2085
MANUFACTURER/PART NUMBER
LINEAR TECHNOLOGY, LT3080EDD#PBF
LINEAR TECHNOLOGY, LTC4359HDCB-#TRPBF
SAMTEC, 2SN-BK-G
ABRACON, ABMM2-12.000MHZ-E2-T
DC2085A
LINEAR TECHNOLOGY, LTC2000IY-16
DC2085A
LINEAR TECHNOLOGY, LTC2000IY-14
DC2085A
LINEAR TECHNOLOGY, LTC2000IY-11
DC2085A
LINEAR TECHNOLOGY, LTC2000AIY-16
DC2085A
LINEAR TECHNOLOGY, LTC2000AIY-14
DC2085A
LINEAR TECHNOLOGY, LTC2000AIY-11
