DEMO MANUAL DC2085
PARTS LIST
ITEM QTY REFERENCE
37 6 L1, L2, L3, L4, L6, L7
38 1 L5
39 1 L8
40 1 L9
41 1 L10
42 2 MTG5, MTG6
43 2 Q1, Q2
44 6 R1, R2, R3, R13, R17,
R30
45 1 R4
46 4 R5, R14–R16
47 2 R6, R8
48 0 R7, R10, R23, R24, R25,
R27, R28, R36, R37,
R38, R39, R43, R62, R63
49 1 R9
50 1 R11
51 1 R12
52 1 R18
53 2 R19, R20
54 1 R21
55 1 R22
56 2 R26, R29
57 7 R31-R35, R41, R42
58 10 R40, R44, R46, R47,
R48, R57, R58, R59,
R60, R61
59 1 R45
60 1 R49
61 1 R50
62 1 R51
63 1 R52
64 1 R53
65 1 R54
66 2 R55, R56
67 1 T1
68 1 U2
69 1 U3
70 1 U4
71 1 U5
72 2 U6, U7
73 1 U8
74 1 U9
8
PART DESCRIPTION
FERRITE BEAD, 33Ω AT 100mHz, 1206
INDUCTOR, 2.2µH, 20% HIGH CURRENT, SMT
INDUCTOR, CERAMIC CHIP, 1nH, 5%, 0402
FERRITE BEAD, 30Ω AT 100mHz, 0805
INDUCTOR, 6.8µH, 20% HIGH CURRENT, SMT
STANDOFF, NYLON 0.5"
TRANSISTOR, N-CH. POWER MOSFET, SOIC 8L
RES., CHIP, 1k, 1/16W, 5% 0402
RES., CHIP, 4.7k, 1/16W, 5% 0402
RES., CHIP, 10k, 1/16W, 5% 0402
RES., CHIP, 2k, 1/16W, 5% 0402
RES., CHIP, OPT, 0402
RES., CHIP, 39Ω, 1/16W, 1% 0402
RES., CHIP, 0Ω JUMPER, 1/16W, 0402
RES., CHIP, 12k, 1/16W, 5% 0402
RES., CHIP, 2.2k, 1/16W, 5% 0402
RES., CHIP, 3.24k, 1/16W, 1% 0402
RES., CHIP, 1k, 1/16W, 1% 0402
RES., CHIP, 7.15k, 1/16W, 1% 0402
RES., CHIP, 49.9Ω, 1/6W, 1% 0201
RES., CHIP, 10Ω, 1/16W, 1% 0402
RES., CHIP, 50Ω, HIGH FREQ., 1/20W, 0.1% 0402
RES., CHIP, 499Ω, 1/16W, 1% 0402
RES., CHIP, 41.2k, 1/10W, 1% 0603
RES., CHIP, 309k, 1/10W, 1% 0603
RES., CHIP, 243k, 1/10W, 1% 0603
RES., CHIP, 50Ω, 1/8W, 5% 0603
RES., CHIP, 560Ω, 1/10W, 5% 0603
RES., CHIP, 10k, 1/10W, 1% 0603
RES., CHIP, 20Ω, 1/16W, 1% 0402
TRANSFORMER, BALUN
IC, USB TO MULTIPURPOSE UART/FIFO, TQFP
IC, QUAD MUX/DEMUX, TSSOP-16
IC, EEPROM 1kBIT 3MHZ, 8TSSOP
IC, MICROPOWER REGULATOR, SO-8
IC, MICROPOWER REGULATOR, SO-8
IC, BUCK REGULATOR, QFN
IC, VOLTAGE REFERENCE, MSOP
MANUFACTURER/PART NUMBER
MURATA, BLM31PG330SN1L
VISHAY, IHLP2020BZER2R2M11
COILCRAFT, 0402CS-1N0XJLU
TDK, MPZ2012S300A
VISHAY, IHLP2020BZER6R8M11
KEYSTONE, 8833 (SNAP ON)
FAIRCHILD, FDS8870
VISHAY, CRCW04021K00JNED
YAGEO, RC0402JR-074K7L
YAGEO, RC0402JR-0710KL
VISHAY, CRCW04022K00JNED
OPTION
VISHAY, CRCW040239R0FKED
VISHAY, CRCW04020000Z0ED
VISHAY, CRCW040212K0JNED
VISHAY, CRCW04022K20JNED
VISHAY, CRCW04023K24FKED
YAGEO, RC0402FR-071KL
VISHAY, CRCW04027K15FKED
VISHAY, CRCW020149R9FNED
VISHAY, CRCW040210R0FKED
VISHAY, FC0402E50R0BST1
VISHAY, CRCW0402499RFKED
VISHAY, CRCW060341K2FKEA
VISHAY, CRCW0603309KFKEA
VISHAY, CRCW0603243KFKEA
VISHAY, FC0603E50R0JST1
VISHAY, CRCW0603560RJNEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW040220R0FKED
ANAREN, B0430J50100AHF
FTDI, FT2232HL
FAIRCHILD, FST3257MTCX
MICROCHIP, 93LC46C-I/ST
LINEAR TECHNOLOGY, LT1763CS8-3#PBF
LINEAR TECHNOLOGY, LT1763CS8-3.3#PBF
LINEAR TECHNOLOGY, LT8614IUDC#PBF
LINEAR TECHNOLOGY, LTC6655CHMS8-2.048#PBF
dc2085afb
