Kit Instructions
Mount for Integrated 2x20 Customer Display
7746-K456
Issue A

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7746-K456 and is the answer not in the manual?

Questions and answers

Related Manuals for NCR 7746-K456

Summary of Contents for NCR 7746-K456

  • Page 1 Kit Instructions Mount for Integrated 2x20 Customer Display 7746-K456 Issue A...

  • Page 2: Revision Record

    The product described in this document is a licensed product of NCR Corporation. NCR is a registered trademark of NCR Corporation. NCR POS is a trademark of NCR Corporation in the United States and/or other countries. Other product names mentioned in this publication may be trademarks or registered trademarks of their respective companies and are hereby acknowledged.

  • Page 3: Kit Contents

    Mount for Integrated 2x20 Customer Display This kit provides a mount to install a 2x20 Customer Display on the neck of the NCR PX10/PX15 POS (7746). Kit Contents...

  • Page 4: Installation Procedure

    Mount for Integrated 2x20 Customer Display Installation Procedure 1. Pivot the display toward the back. 2. Remove the screw (1) that secures the Front Neck Cover to the neck. Note: Use only a screwdriver with a #1 Philips bit to avoid stripping the screw head.
  • Page 5 Mount for Integrated 2x20 Customer Display 3. Pivot the Front Neck Cover away from the terminal. 4. Lay the terminal face down on a flat surface. Caution: Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down.
  • Page 6 Mount for Integrated 2x20 Customer Display 6. Remove the Rear Base Cap. 7. Set the terminal to stand upright, and then pivot the display toward the front. 8. Pivot the Back Neck Cover away from the terminal.
  • Page 7 Mount for Integrated 2x20 Customer Display 9. Lay the 2x20 display face down on a flat surface. Caution: Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down. 10. Connect the Interface Cable to the back of the 2x20 display. Ensure that the latch is properly engaged.
  • Page 8 Mount for Integrated 2x20 Customer Display 12. Secure the neck mount to the back of the 2x20 display using screws (2). 13. Set the terminal to stand upright, and then pivot the display toward the front.
  • Page 9 Mount for Integrated 2x20 Customer Display 14. Attach the neck mount with 2x20 display to the terminal. 15. Secure the neck mount and 2x20 display assembly on the neck of the PX10 terminal with a screw. 16. Lay the terminal face down on a flat surface. Caution: Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down.
  • Page 10 Mount for Integrated 2x20 Customer Display 17. Route the Interface Cable through the right side of the neck base and connect the cable to the COM Port of the terminal stand. 18. Attach the Rear Base Cap to the bottom of the neck, and secure with screws (2). 19.
