INVERTER
FR-S
500
INSTRUCTION MANUAL (BASIC)
FR-S520E-0.1K to 3.7K(-C)
FR-S540E-0.4K to 3.7K
FR-S520SE-0.1K to 1.5K
FR-S510WE-0.1K to 0.75K
Thank you for choosing this Mitsubishi inverter.
If this is the first time for you to use the FR-S500 series, please read through this instruction manual (basic)
carefully and use the inverter safely.
If you are going to use the inverter for higher-level applications, the FR-S500 instruction manual (detailed)
[IB(NA)-0600152E] is separately available from where you purchased the inverter or a Mitsubishi sales
representative.
1
CONNECTION OF PERIPHERAL DEVICES ............................................. 3
1.1 Basic configuration ...................................................................................... 3
2
INSTALLATION METHOD.......................................................................... 6
2.1 Installation of the inverter............................................................................. 6
3
SPECIFICATIONS OF WIRING AND TERMINALS ................................... 7
3.1 Terminal connection diagram ...................................................................... 7
3.2 Main circuit................................................................................................... 8
3.3 Control circuit............................................................................................. 12
4
RUN AND OPERATION............................................................................ 17
(example: performing operation at 30Hz) ................................................. 19
4.3 Setting the parameters .............................................................................. 21
4.4 Clearing the parameters ............................................................................ 23
4.5 Monitoring the output current..................................................................... 24
performing operation at 30Hz) .................................................................. 25
5
POTENTIOMETER AND INDICATOR...................................................... 27
6
FUNCTION LIST ....................................................................................... 32
6.1 Basic function parameter list...................................................................... 32
6.2 Explanation of the basic function parameters............................................ 33
6.3 Extended function parameter list ............................................................... 35
7
ERRORS AND PROTECTIVE FUNCTIONS ............................................ 49
7.1 About errors (definitions) ........................................................................... 49
(only when FR-PU04 is used).................................................................. 52
7.4 Resetting the inverter................................................................................. 52
7.5 Troubleshooting ......................................................................................... 53
7.6 Precautions for maintenance and inspection............................................. 56
8
SPECIFICATIONS .................................................................................... 67
8.1 Ratings....................................................................................................... 67
8.2 Common specifications.............................................................................. 71
9
OUTLINE DRAWINGS.............................................................................. 73
Appendix 1 Instructions for compliance with the European Directive 76
Appendix 2 Instructions for UL and cUL.............................................. 78
CONTENTS
1
2
3
4
5
6
7
8
9
