Toto EGO II TX128LELBR Quick Start Manual

SPECIFICATIONS
183
67
Ø95
Floor
G½
Ø6
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning.
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and fittings.
2. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the
basic installation principles are the same.
S06726BN
INSTALLATION
1
Floor
Water Pass
Make sure floor is flat
3
Hot Water
Supply *
HOT
Cold Water
G½
Supply *
* Pipe supplied by owner
5
* Plastic
Cover
* Cut the cover after the
mortar dry
EGO II LEVER HANDLE FLOOR STANDING
SINGLE LEVER LAVATORY FAUCET
2
a
Base
Sleeve
Anchor
6 X Ø6
Holes
b
Screw
4
Cover
Maxi m um
Mortar Level
COLD
Minimum
Mortar
Mortar Level
6
Hex. Key
Bolt*
Washer*
Base
Cover
* Remove the Base Cover
, keep the Bolt & Washer
TX128LELBR
7
Body
Cover
Hex. Key
Bolt & Washer
(from step 6)
Swivel
Ring
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Flow rate unsatisfactory 1
Water leaks around the handle 2
Handle is loose 3
1. AERATOR
SOLUTION
Remove and clean
Tighten
Tighten
2. CONNECTING
NUT
3. BOLT
R10
