Toto EGO II Installation Instructions

SPECIFICATIONS
121
Ø54
G½
TX 125 LES
"EGO II" Lavatory Faucet "EGO II" Extended Lavatory Faucet
(Height= 110 mm)
121
Ø54
G½
TX 125 LESV2
"EGO II" Extended Lavatory Faucet
(Height= 234 mm)
S06468RR
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean
( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such
as ammonia, chlorine, toilet cleaner etc. which could
adversely affect the finish and are not recommended
121
for cleaning
Ø54
INSTALLATION
G½
TX 125 LESV1
(Height= 150 mm)
"EGO II" LAVATORY FAUCET TX125LES
Faucet
Packing
Ø25 Hole
Wavy
Washer
Nut
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Flow rate unsatisfactory
Water leaks around the handle
Handle is loose
Handle swinging
1. AERATOR
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
As the product model is constantly updated, the actual
2.
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
SOLUTION
1
Remove and clean
2 Tighten
3 Tighten
4 Tighten
3. BOLT
2. CERAMIC
HEAD WORK
4. NUT
R7
