Summary of Contents for Toto WASHLET S7 TCF47360 Series
- Page 1 Instruction Manual WASHLET S7 TCF47360*** Thank you for your recent purchase of this product. Please read the enclosed information to ensure the safe use of your product. Be sure to read this Instruction Manual before using your product and keep it in a safe place for future reference.
-
Page 2: Table Of Contents
Table of Contents Timer energy saver ........19 Introduction Auto open / close ON / OFF .......19 Setting confirmation ........19 Safety Precautions ........4 Auto flushing ON /OFF .......19 Operational Precautions ......8 Temperature Adjustment ......20 Parts Names ..........10 Warm water / Toilet seet / Drying ....20 Preparation ..........12 Changing Settings ........22 Using the Product for the First Time....12... - Page 3 Maintenance Reference Maintenance ..........40 What to Do? ..........47 If the water does not flow due to a water Before maintenance ........40 service interruption ........47 Main Unit ............40 If you cannot operate with Manual spray ..........41 Gap between the Main Unit and Bowl Unit ..42 the remote control .........47 Replacing the batteries ......47 Gap between the Main Unit and the Toilet Lid ...43...
-
Page 4: Introduction
Introduction Safety Precautions These precautions are important for safe usage. Be sure to follow them and use the product correctly. The following symbols are used to indicate important safety instructions for the use of the product. Symbols and Meanings WARNING May result in death or serious injury. - Page 5 Introduction WARNING Do not stick a finger or anything else into the warm This appliance is not intended for use by persons air outlet. (including children) with reduced physical, sensory or mental capabilities, or lack of experience and Do not place anything on the warm air outlet or knowledge, unless they have been given supervi- drape clothes over it.
- Page 6 Introduction Safety Precautions WARNING CAUTION Do not use a loose or faulty electrical outlet. Do not use the product if the main unit is unstable. Doing so may cause fire or short circuit. Doing so may cause the main unit to come loose and fall, resulting in injury.
- Page 7 Introduction CAUTION Do not fold or crush the water supply hose; do not When installing the drain plug with water supply damage by cutting with a sharp object. filter, make sure that it is securely tightened in its proper position. Doing so may cause water leaks.
-
Page 8: Operational Precautions
Introduction Operational Precautions About the built-in body sensor About the built-in seat sensor The body sensor detects human movement. When you sit on the toilet seat, the seat sensor turns ON, enabling you to use various features. The toilet lid opening or "Auto bowl CLEAN" operation (The deodorizer starts when the seat sensor makes a may be triggered by someone outside the bathroom as detection.) - Page 9 Introduction For prevention of damage Do not use the product with the toilet lid removed. Wipe plastic areas such as the main unit and re- Do not expose to direct sunlight. mote control with a soft cloth tightly wrung out with Doing so may cause changes in color, irregular heated water.
-
Page 10: Parts Names
Introduction Parts Names Toilet lid cushions Toilet lid Model No., etc Body sensor (Built-in) Wand cover Warm air outlet cover Wand Heated seat Seat sensor (Built-in) Power plug A: Main display CLEAN indicator Power cord Power LED Seat LED Energy saver LED Water supply hose Shutoff valve ( ... - Page 11 Introduction Toilet seat cushions B: Front side of the main unit D: Right side of the main unit Remote control Soft light receiver Cover Main unit removal button ( Page 42) Drain plug with water supply fi lter ( Page 46) Deodorizing fi lter ( ...
-
Page 12: Preparation
Introduction Preparation If the remote control is secured to prevent theft Using the Product for Hold the remote control and remove the hanger the First Time hooks (two locations, left and right) Remote control Insert the battery Hanger Remove the remote control from the hanger. Hook Remote control Flat-head screwdriver... - Page 13 Introduction Turn on the power Open the shutoff valve Switch the breaker on the distribution board to ON. Fully open the shutoff valve. X The wand extends and then retracts. Check the "Power" LED illuminates. Power Shutoff valve Flat-head screwdriver If the light is off...
-
Page 14: Operation
Operation Basic Operations Mechanism of As you stand up Auto Functions Auto power deodorizer Auto flushing "EWATER+" is used automatically to clean the Auto wand CLEAN wand, bowl unit and under the seat. As you approach Auto power deodorizer After about 10 seconds Auto open / close Starts the auto power deodorizer Auto bowl CLEAN... -
Page 15: Auto Underseat Clean
Operation Auto open / close As you move away The toilet lid closes When you move away Auto flushing Auto open / close Auto bowl CLEAN Auto underseat CLEAN When the toilet is used in standing position Operation under the default settings is described in "Mechanism of Auto Functions". -
Page 16: Soft Light
Operation Basic Operations Mechanism of Auto Functions Soft light CLEAN indicator Lighting up the inside of the bathroom with a soft Lights to show that the "Auto bowl CLEAN", light. "Auto underseat CLEAN", "Deodorizer", "Auto wand CLEAN", and "Manual spray" functions are It lights up as you approach the bowl unit and operating. -
Page 17: Using The Remote Control
Operation Using the Remote Control Operate the controls on the remote control; a beep sounds when the main unit receives the signal. Stop Water pressure adjustment Stops the B or C operation. You can adjust the water Rear washing pressure to one of five levels. [-] Softer, [+] Stronger Washes your rear. -
Page 18: Wand Clean
Operation Basic Operations Using the Remote Control (Continued) Wand CLEAN Opening and closing the toilet lid Cleans the wand with "EWATER+" Opens and closes the toilet lid. After wand cleaning, water comes out from Opening and closing around the wand. the toilet seat Note: This function will operate automatically after Opens and closes the toilet seat. -
Page 19: "Power On/Off" Button
Operation Remote control back side How to remove the remote control ( Page 12) Operate the controls on the remote control; a beep sounds when the main unit receives the signal. This section is an overview of the settings that can be configured with the remote control. See the corresponding pages for the detailed descriptions. -
Page 20: Temperature Adjustment
Operation Temperature Adjustment Warm Water, Press the button selected in step repeatedly until a desired temperature level illuminates. Toilet Seat, Drying X The setting changes each time the button is pressed once Five different temperature levels from high to low and "OFF"... - Page 21 Operation Settings complete Press the button selected in step repeatedly X When seat temperature is set, the SEAT LED until the temperature level is set to "OFF". illuminates. X The setting changes each time the button is pressed once Note: The "Drying" cannot be turned "OFF". If the button is not pressed for about 10 seconds, the "Tem- perature adjustment"...
-
Page 22: Changing Settings
Operation Changing Settings Setting List Available Settings Setting Types Bold: Initial settings ON/OFF Auto energy saver ( Page 26) Auto energy saver+ ( Page 26) ON/OFF Timer energy saver ( Page 27) 6H/9H/OFF ON/OFF Auto flushing ( Page 27) Auto flush delay 1/SET 2/SET 3... - Page 23 Operation X Setting buttons ( Pages 26–39) Setting with buttons on the front of the remote control Press the button indicated in step 1 for approxi- mately 10 seconds or longer to enter setting mode. Flash Check A Stop button B Rear washing button C Front washing button Press "Stop"...
-
Page 24: The Energy Saver Features
Operation Changing Settings The energy saver features "Auto energy saver", "Auto energy saver+" or "Timer energy Energy saver is on saver" can be selected. To save energy, the temperature of the toilet seat becomes Lit (Green) low (or "OFF"). Note: Even if the energy saver is activated (with the toilet seat heater set to Low or OFF), the toilet seat will be temporarily heated when you sit on it. - Page 25 Operation Timer energy saver and Timer energy saver Auto energy saver / You want to save energy only for a preset duration Auto energy saver+ of time. (6 hours, 9 hours) Once the time is set, the toilet seat heater turns off You want to save the maximum amount of energy automatically during the set time period every day.
-
Page 26: How To Set
Operation Changing Settings How to Set Auto energy saver+ Auto energy saver Press "Auto energy saver" button. X The setting changes each time the button is pressed once. Press "Auto energy saver" button. When set to "Auto energy saver+" X The setting changes each time the button is pressed once. -
Page 27: Timer Energy Saver
Operation Timer energy saver Auto flushing Set the "Timer energy saver" at the time you Set whether or not to clean the bowl unit want to start it. automatically Example: To save energy from 1 am to 7 am (for 6 hours) Press "Auto flushing"... -
Page 28: Auto Flush Delay
Operation Changing Settings Auto flush delay Auto flush lid closed Change the amount of time before the toilet Set whether or not to close the toilet lid flushes automatically automatically before flushing the bowl unit Press "Stop" button until all Press "Stop"... - Page 29 Operation "Auto flush lid closed" does not work if "Auto flushing" About "Auto flush lid closed"… and "Auto open / close" are set as below: (Except when (If the "Flush" button is located on the top side using the Flush buttons on the remote control) of the remote control) Auto flushing Auto open / close...
-
Page 30: Auto Open / Close
Operation Changing Settings Auto open / close Auto close delay Set whether or not to open and close the toilet Change the amount of time before the lid/seat lid automatically closes automatically Press "Stop" button until all Check Press "Auto open / close" button. LEDs on the remote control are X The setting changes each time the button is lit or flashing. -
Page 31: Auto Open Delay
Operation Auto open delay Seat/lid Change the time period till automatic opening Automatically open and close the toilet lid/ (After closing by hand or remote control.) Automatically open and close the toilet seat and toilet lid Press "Stop" button until all Check LEDs on the remote control are Press "Stop"... -
Page 32: Auto Wand Clean
Operation Changing Settings Auto wand CLEAN Auto bowl CLEAN Set whether or not to clean the wand Set whether or not to spray mist in the bowl automatically unit automatically Press "Stop" button until all Press "Stop" button until all Check Check LEDs on the remote control are... -
Page 33: Auto Underseat Clean
Operation Auto underseat CLEAN Deodorizer Set whether or not to spray mist to the back of Set whether or not to deodorize automatically the toilet seat automatically after sitting on the toilet seat Press "Stop" button until all Press "Stop" button until all Check Check LEDs on the remote control are... -
Page 34: Auto Power Deodorizer
Operation Changing Settings Auto power deodorizer Night light Set whether or not to power deodorize Set whether or not to change "Soft light" and automatically after standing up "Bowl light" to "Night mode", a lighting mode suitable for night, as well as the time window. To set the time window (timer), set the desired Press "Stop"... -
Page 35: Soft Light
Operation About "Night light"… Soft light You can change "Soft light" and "Bowl light" to "Night Set whether or not to use the soft light mode", a lighting mode suitable for night. Note: The light does not turn on if "Soft light" and "Bowl light" are turned OFF. -
Page 36: Bowl Light
Operation Changing Settings Bowl light CLEAN indicator Set whether or not to use the light inside the Set whether or not to light up the CLEAN bowl unit indicator Press and hold both the "Stop" Press and hold both the "Stop" Check Check button and "Water pressure... -
Page 37: Beep Sound
Operation Beep sound Pressure / position setting Set whether or not to make a beep sound Set whether or not to keep your favorite pressure and position settings Press and hold both the "Stop" Check button and "Water pressure Press and hold both the "Stop" Check adjustment +"... -
Page 38: Personal Setting
Operation Changing Settings Personal setting Registering Personal Settings Set whether or not to use the personal setting Register your preferred wand position, etc. Press and hold both the "Stop" Check Press "Personal setting" button. button and "Water pressure Select the location to be set adjustment +"... -
Page 39: Sensor Detection Range
Operation Sensor detection range Use the "Water pressure adjustment -" and "Water You can change when to open the toilet lid pressure adjustment +" buttons to select "SET 1", upon entering the bathroom "SET 2", "SET 3", "SET 4", or "SET 5". X The setting changes each time the button is pressed once. -
Page 40: Maintenance
Maintenance Maintenance Before maintenance Main Unit WARNING y Soft cloth soaked in water Always turn off the power before maintenance or inspection. y Toilet paper y Dry cloth Failure to do so may cause electric shock or mal- y Nylon scrubbing brush function, resulting in a breakdown. -
Page 41: Manual Spray
Maintenance Manual spray EWATER+ mist can be sprayed to separate dirt from the surface for maintenance. Approximately daily <Manual spray> Remote control back side How to remove the remote control ( Page 12) Press "Manual spray" button. X EWATER+ mist is sprayed on the bowl unit and underneath the front of the toilet seat. -
Page 42: Gap Between The Main Unit And Bowl Unit
Maintenance Maintenance Gap between the Main Unit Mount the main unit. and Bowl Unit You can remove the main unit to clean the top of With hole No hole Base plate Base plate the bowl unit and the bottom of the main unit. y Soft cloth soaked in water y Toilet paper y Dry cloth... -
Page 43: Gap Between The Main Unit And The Toilet Lid
Maintenance Gap between the Main Unit Wipe with a soft cloth that has been soaked in and the Toilet Lid water and wrung-out thoroughly. The toilet lid can be removed for thorough cleaning. Reinstall the toilet lid. y Soft cloth soaked in water D Align the right side pin and hinge parts. -
Page 44: Wand
Maintenance Maintenance Wand Wipe with a soft cloth that has been soaked in water and wrung out thoroughly. y Soft cloth soaked in water y Toilet paper y Dry cloth y Nylon scrubbing brush May cause damage. Attention Do not pull, push or press the wand with excessive Approximately once a month force. -
Page 45: Deodorizing Filter
Maintenance Deodorizing Filter Approximately once a month Turn the power "OFF". ( Page 40) Remove the deodorizing filter. Hold the tab and pull outward. Deodorizing filter Attention Do not pull the unit with undue force. Doing so may cause damage or malfunction. Clean with a tool such as a toothbrush. -
Page 46: Drain Plug With Water Supply Filter
Maintenance Maintenance Drain plug with water supply Clean the filter with a tool such as a toothbrush. filter X Also, remove any dust from inside the hole of the drain plug with water supply filter. Approximately once every 6 months If you think the water pressure has weakened Reinstall the drain plug with water supply filter and close the cover. -
Page 47: Reference
Reference What to Do? If the water does not If you cannot operate flow due to a water with the remote control service interruption If the low battery warning mark " " on the surface of the remote control is flashing, please Make sure to also check the instruction manual of replace the batteries. -
Page 48: Freeze Damage Prevention
Reference What to Do? 4) Only if the water supply hose is exposed on the Freeze Damage side of the main unit. Drain the water from the water supply hose. Prevention Water supply hose Horizontally When the ambient temperature is likely to drop to 0 °C or lower, take measures to prevent freezing. -
Page 49: Long Periods Of Disuse
Reference Long Periods of Disuse Drain the pipe. 1) Open the toilet seat and lid. If the toilet is in a location you will not visit for a 2) Insert a flat-head screwdriver in the hook of the cover to open it. long time, drain the water. -
Page 50: Resupplying The Water
Reference What to Do? Resupplying the Water Long Periods of Disuse Open the shutoff valve. ( Page 13) (Continued) X Check that water is not leaking from a pipe or the main unit. Reinstall the drain plug with water supply filter and If the power is not on, turn the power ON. -
Page 51: How To Remove The Operation Guide
Reference How to remove the operation guide To remove, follow the procedure below. Turn the power "OFF". ( Page 40) Remove the remote control from the hanger. ( Page 12) Remove the hanger and operation guide. Phillips screwdriver Screw Hanger Operation guide... -
Page 52: Troubleshooting
B: Is the Energy saver LED lit? If the problem persists, consult the installer, seller or TOTO customer service ( see contact information X While the LED is lit, energy saver ( Pages 24, 25) is on the back cover). -
Page 53: Rear Washing, Front Washing And Wand
If the above symptom reappears There may be a malfunction. XConsult the installer, seller, or TOTO customer service ( see contact information on the back cover). When sitting on the toilet seat, is there a toilet seat cover or clothing on the seat... -
Page 54: Warm Air Drying
Reference Troubleshooting Rear Washing, Front Washing and Wand (Continued) Trouble Please check Water comes out unexpectedly When you sit on the toilet seat, water comes out for several seconds while water is from the wand warmed up. Has the CLEAN indicator lit up in a cycle? X "Auto wand CLEAN"... -
Page 55: Toilet Seat And Toilet Lid (Auto Open/Close)
Reference The bowl unit does not clean When sitting on the toilet seat, is there a toilet seat cover or clothing on the seat sensor? Or are you sitting without touching the seat sensor? automatically or timing is delayed X Check the location of the seat sensor and sit down so that it touches your skin (Auto flushing) directly. - Page 56 Reference Troubleshooting Toilet Seat and Toilet Lid (Auto open/close) (Continued) Trouble Please check The toilet lid opens on its own Because the body sensor can detect movement through the wall or door in front of the toilet, the "Auto open/close" function may cause the toilet lid to open automatical- ly even when you are outside of the bathroom.
-
Page 57: Toilet Seat And Toilet Lid
Reference Toilet Seat and Toilet Lid Trouble Please check The toilet seat is cold Is the toilet seat temperature set to "OFF" or a low level? ( Pages 20, 21) Is energy saver in operation? The energy saver feature is on when the "Energy saver" LED is on and the "Power" LED is off on the main display. -
Page 58: Energy Saver
Reference Troubleshooting Energy Saver Trouble Please check The Energy saver LED does not Has the power to the product been turned "OFF" or was there a power outage? light up The Energy saver LED on the main display may go off when the power is turned ON even if the energy saver feature is ON. -
Page 59: Auto Bowl Clean, Auto Underseat Clean, Manual Spray
If any nuts in a connection are loose, firmly tighten them with a tool such as a monkey wrench. ing connections X If the water leak does not stop, close the shutoff valve and consult with TOTO customer service. ( see contact information on the back cover) The main unit is unstable Are the bolts that anchor the main unit loose? X Remove the main unit and then firmly tighten the base plate bolts. - Page 60 Reference Troubleshooting Others (Continued) Trouble Please check The main unit makes a sound When entering the bathroom If "Auto bowl CLEAN" is "ON", you may hear that pre-mist is spraying mist in the bowl unit to make it more difficult for dirt to adhere. X You can turn it "OFF".
-
Page 61: Specifications
W 383 x D 530 x H 103 mm Weight About 5 kg When disposing of this product, please follow your local or state guidelines for proper disposal. *1 At 0.20 MPa (Dynamic) water pressure. *2 Temperature around the warm air outlet measured by TOTO. -
Page 62: Safety Guidelines
Reference Safety Guidelines A warm-water cleaning toilet seat is an electric appliance. Continued use after malfunction occurs or use when its life-time is expired may deteriorate the electric components, producing smoke or resulting in a fire. For safe use of the warm-water cleaning toilet seat Periodical inspection If any abnormality of the product... -
Page 63: Limited Warranty
COSTS DUE TO INSTALLATION OR REMOVAL, OR COSTS cause of the defect. TOTO will not charge for labor or parts OF REPAIRS BY OTHERS, OR FOR ANY OTHER EXPENSE in connection with warranty repairs or replacements. - Page 64 TOTO ASIA OCEANIA 10, Eunos Road 8, #12-07, Singapore Post Centre. Singapore 408600. PTE. LTD. Phone : +65-6744-6955 Fax : +65-6841-0819 http://asia.toto.com/ TOTO ASIA OCEANIA Middle East Branch LOB19-1701,02, Jebel Ali Free Zone, P.O. box 261804, Dubai U.A.E. PTE. LTD.
