Toto EGO TX126LE Quick Start Manual

SPECIFICATIONS
Ø42
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
As the product model is constantly updated, the actual
2.
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
S06688SS
SPECIFICATIONS
Ø42
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
S06688SS
"EGO" SELF CLOSING LAVATORY FAUCET
INSTALLATION
Lavatory Hole
Ø25
ADJUSTMENT
Bolt
Maximum flow time 20 second at water pressure
0.05 Mpa. For your satisfaction, please adjust the
flow time.
- Turn the spindle left, to get the short flow time.
- Turn the spindle right, to get the long flow time.
"EGO" SELF CLOSING LAVATORY FAUCET
INSTALLATION
Lavatory Hole
Ø25
ADJUSTMENT
Bolt
Maximum flow time 20 second at water pressure
0.05 Mpa. For your satisfaction, please adjust the
flow time.
- Turn the spindle left, to get the short flow time.
- Turn the spindle right, to get the long flow time.
(COLD ONLY)
TROUBLESHOOTING
PROBLEM
Flo w rate unsatisfacto ry
Faucet
The Handle is lo o se
Packing
Washer
Lock Nut
Hex. Key
Cap
Spindle
1. AERATOR
(COLD ONLY)
TROUBLESHOOTING
PROBLEM
Flo w rate unsatisfacto ry
Faucet
The Handle is lo o se
Packing
Washer
Lock Nut
Hex. Key
Cap
Spindle
1. AERATOR
TX126LE
CHECK
SOLUTION
POINT
1 , 2
Remo ve and clean
3 Tighten
3. BOLT
2. STRAINER
TX126LE
CHECK
SOLUTION
POINT
1 , 2
Remo ve and clean
3 Tighten
3. BOLT
2. STRAINER
R9
R9
