Toto EGO TX124LE Quick Start Manual

SPECIFICATIONS
62
+5
160 55
0
TX124LEN
"EGO" Wall Type Lavatory Faucet (Cold Only)
62
+5
160 55
0
TX124LES
"EGO II" Wall Type Lavatory Faucet (Cold Only)
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
Don t use abrasive cleaners or solvents on faucets and
1.
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S06200NN
"EGO" WALL TYPE LAVATORY FAUCET ( COLD ONLY ) TX124LE
INSTALLATION
1.
G½
0
-5
* Pipe supplied by owner
2.
G½
0
Cover *
-5
* Remove the cover & O-ring after the mortar
has dry
3.
Handle
* Tighten the handle base by hand
Minimum
Maxima l Completion
Completion
wall su rface
wall su rface
Body
Cold Water Supply *
Mortar
O-Ring *
Handle Base*
4.
Spout
Cover
O-Ring
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Flow rate unsatisfactory
Water leaks around the handle
1. AERATOR
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
Use Seal Tape
(Not Include)
SOLUTION
1
Remove & clean
2 Tighten
2. CERAMIC
HEAD WORK
R14
