- Page 1 Assembly Instructions max. 300 kg ~ 90 Min. 45 kg L 166 | W 77 | H 122 DFFB90.01.03 14.4 kg L 116 | W 61 | H 82 Art. No. DF-FB90 DARWIN FB90...
- Page 2 FB90...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Part A Scope of Delivery Part C Scope of Delivery Part D Scope of Delivery Part E Assembly Part A Assembly Part C Assembly Part D Assembly Part E 2.10 Assembly of the Parts A, D and C STORAGE AND TRANSPORT... - Page 4 WARRANTY CONTACT FB90...
- Page 5 Dear customer, Thank you for choosing Darwin fitness equipment. With Darwin fitness equipment we offer first-class home sports equipment at a great price point. Darwin exercise bikes and strength machines are easy to use, have a spacesaving design and look really great. With our equipment we want to support you in reaching your athletic goals, no matter if you want to lose weight or train for the national triathlon.
- Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. FB90...
-
Page 7: General Information
GENERAL INFORMATION Technical Data Article weight (gross, incl. packaging) approx.: Box 1: 20 kg Box 2: 7 kg Box 3: 8 kg Box 4: 10 kg Article weight (net, excl. packaging) approx.: 45 kg Package dimensions (L x W x H) approx.: Box 1: 142 cm x 55 cm x 18 cm Box 2: 57 cm x 45 cm x 12 cm Box 3: 70 cm x 41 cm x 13,5 cm... -
Page 8: Personal Safety
CAUTION Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. Do not insert any objects of any kind into the openings of the device. FB90... -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
To prevent damage to the equipment and the floor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. FB90... -
Page 11: Scope Of Delivery Part A
Scope of Delivery Part A The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 12: Scope Of Delivery Part C
In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠ If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. FB90... -
Page 13: Scope Of Delivery Part D
Scope of Delivery Part D The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 14: Scope Of Delivery Part E
In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠ If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. FB90... -
Page 15: Assembly Part A
Assembly Part A Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. - Page 16 Step 2: Assembly of the Main Tube and Front Bottom Frame Fix the main tube (1) to the front bottom frame (3) by using hexagon two M10*80 bolts (10), four φ10 washers (11) and two M10 nuts (12). FB90...
- Page 17 Step 3: Assembly of the Adjustable Plate Fix the adjustable plate (4) to the main tube (1) by using three M10*90 bolts (13), six φ10 washers (11) and three M10 nuts (12).
- Page 18 Step 4: Assembly of the Back Support Tube Fix the back support tube (6) to the main tube (1) by using one M12*100 bolt (14), two φ12 washers (15) and one M12 nut (16). FB90...
- Page 19 Step 5: Assembly of the Adjustable Tube Fix the adjustable tube (7) to the back support tube (6) by using one M12*180 bolt (17), two φ12 washers (15) and one M12 nut (16).
- Page 20 Step 6: Assembly of the Seat Support Tube Fix the seat support tube (5) to the main tube (1) by using one M12*100 bolt (14), two φ12 washers (15) and one M12 nut (16). FB90...
- Page 21 Step 7: Assembly of the Seat Cushion Fix the seat cushion (8) to the seat support tube (5) by using two M10*80 bolts (10) and two φ10 washers (11). Fix the M10*20 bolt (18), φ10 washers (11) and the M10 nut (12) tightly on the seat support tube (5).
- Page 22 Step 8: Assembly of the Back Cushion Fix the back cushion (9) to the back support tube (6) by using two M10*80 bolts (10) and two φ10 washers (11). FB90...
-
Page 23: Assembly Part C
Assembly Part C Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. - Page 24 Assembly of the Foam Bars and Foams Slide the foam bars (3) through the L frame (2). Slide one foam (4) on to each end of the foam bars (3). Fix the end caps (5) to the foams (4) using one bolt (13) each. FB90...
- Page 25 Step 3: Assembly of the Barbell Plate Sleeve Attach the barbell plate sleeve (8) to the L frame (2) and fix it by tightening the setting screw on the side. Attach the spring collar (9) to the plate sleeve (8). Step 4: Assembly of the Bicep Curl Bar Attach one end of the snap hooks on the chain (7) to the bicep curl bar (6) and the other snap hook...
-
Page 26: Assembly Part D
Step 1: Assembly of the Catcher and Main Frame Fix the bar catcher (1) to the main frame (2) by using two M10*75 bolts (4), four φ10 washers (5) and two M10 nuts (6). FB90... - Page 27 Step 2: Assembly of the Cushion Fix the cushion (3) to the main frame (2) by using four M10*25 bolts (7) and four φ10 washers (5).
-
Page 28: Assembly Part E
Step 1: Assembly of the Holder Frame and Main Frame Fix the holder frame (1) to the main frame (2) by using two M10*80 bolts (3), four φ10 washers (5) and two M10 nuts (5). FB90... -
Page 29: Assembly Of The Parts A, D And C
2.10 Assembly of the Parts A, D and C Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. Step 1: Insert part C into part A. Insert part D into part C. - Page 30 NOTICE For storage purposes please use part E. For further information regarding storage and transport please refer to chapter 3. Step 1: Insert part C into part E. Insert part D into part E. FB90...
-
Page 31: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 32: Maintenance And Inspection Calendar
The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. FB90... -
Page 33: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 34: Ordering Spare Parts
It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Darwin / Weight bench Model Name: FB90 Article Number: DF-FB90 FB90... -
Page 35: Parts List Part A
Parts List Part A Name Qty. Specification main tube back bottom frame front bottom frame adjustable plate seat support tube back support tube adjustable tube seat cushion back cushion hexagon bolt M10*80 washer φ10 lock nut hexagon bolt M10*90 hexagon bolt M12*100 washer φ12... -
Page 36: Parts List Part C
Parts List Part C Name Qty. Specification main frame L frame foam bar foam end cap bicep curl bar chain barbell plate sleeve spring collar hexagon bolt M12*80 washer φ12 locknut hexagon bolt M10*25 magnetic pin FB90... -
Page 37: Parts List Part D
Parts List Part D Name Qty. Specification bar catcher main frame cushion hexagon bolt M10*75 washer φ10 locknut hexagon bolt M10*25... -
Page 38: Parts List Part E
Parts List Part E Name Qty. Specification holder frame main frame hexagon bolt M10*80 washer φ10 locknut FB90... -
Page 39: Exploded Drawing Part A
Exploded Drawing Part A... -
Page 40: Exploded Drawing Part C
Exploded Drawing Part C FB90... -
Page 41: Exploded Drawing Part D
Exploded Drawing Part D... -
Page 42: Exploded Drawing Part E
Exploded Drawing Part E FB90... - Page 43 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error Descriptions Your fitness equipment is developed for long-term, high-quality training.
