Assembly and

operating instructions

DFCT40.01.03
Art.-No. DF-CT40
DARWIN
CT 40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF-CT40 and is the answer not in the manual?

Questions and answers

Related Manuals for Darwin Fitness DF-CT40

Summary of Contents for Darwin Fitness DF-CT40

  • Page 1: Operating Instructions

    Assembly and operating instructions DFCT40.01.03 Art.-No. DF-CT40 DARWIN CT 40...
  • Page 2 CT 40...
  • Page 3 Dear Customer, Thank you for deciding for a high-quality training equipment of the brand Darwin, the brand that makes athlete‘s hearts beat faster. Darwin offers a wide r ange of home fitness equipment like ellip- tical cross trainers, ergometers, treadmills and rowing machines. Darwin equipment is the optimal equipment for all those who want to train at home independent of goals and fitness level.

  • Page 4: Table Of Contents

    CONTENTS GENERAL INFORMATION 1.1 Technical data 1.2 Personal safety 1.3 Electrical safety 1.4 Set-up place ASSEMBLY INSTRUCTIONS; MAINTENANCE AND CARE 2.1 General instructions 2.2 Errors and error diagnosis 2.3 Maintenance and service calendar ASSEMBLY 3.1 Package contents 3.2 Assembly instructions OPERATING INSTRUCTIONS 4.1 Console display 4.2 Button functions...

  • Page 5: General Information

    GENERAL INFORMATION Technical data LCD display of: time speed distance calories performance heart rate Total number of training programmes: Pre-set programmes: Heart rate-controlled programmes: User-defined programmes: Weight and dimensons: Article weight (gross, including packaging): 59.5 kg Article weight (net, without packaging): 49 kg Packaging dimensions (L x W x H): 127 cm x 40 cm x 57 cm Set-up dimensions (L x W x H): 125 cm x 60 cm x 160 cm...

  • Page 6: Personal Safety

    Personal safety Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 7: Electrical Safety

    Electrical safety The equipment requires a 220 - 230V / 50 Hertz mains power supply. The equipment should be connected directly to a grounded plug socket only by means of the power cable supplied. The use of multi-socket adapters or similar is not recommended. Extension leads must comply with local electrical safety guidelines.

  • Page 8: Assembly Instructions; Maintenance And Care

    ASSEMBLY INSTRUCTIONS, MAINTENANCE AND CARE General instructions Please check if all parts and tools belonging to the equipment are included in the delivery and if there is any transport damage. If there are any complaints, please contact your contract partner directly.

  • Page 9: Errors And Error Diagnosis

    Errors and error diagnosis The equipment runs through regular quality controls during production. Nevertheless, errors or malfunctions on the equipment may occur. Individual parts are often the cause of faults and replacement is usually sufficient. Please use the following overview to see the most common errors and how to repair them.

  • Page 10: Maintenance And Service Calendar

    Maintenance and service calendar The cockpit, casing, handrails and entire frame must be cleaned after every training session with a moist towel (no solvent!) in order to avoid damage caused by sweat. We recommend you to give your treadmill a thorough cleaning every 150 operating hours and to check all the components. The following routine work must be done in the specified time intervals: Part Weekly...

  • Page 11: Assembly

    ASSEMBLY Package contents The package contains the parts represented in the illustration, including a power cable with mains plug. If one of the illustrated parts is missing or damaged, please contact your contract partner.

  • Page 12: Assembly Instructions

    Assembly instructions Before assembly, take an exact look at the individual illustrated assembly steps and execute the assembly following the specified order. Step 1 1. Assemble the front stabilizer (2) and the rear stabilizer (19) on the main frame (1), using four allen bolts, four curved washers (6), four spring washers (7) and four domed nuts (8).
  • Page 13 Step 2 1. We recommend the assistance of a second person for this step. 2. First lift the upper protective cover (49) of the handle bar post (10) - fig. a. Then connect the upper console cable (29) with the lower computer cable (30) - fig. b. Now place the handle bar post (10) on the main frame (1).
  • Page 14 Step 3 1. Assemble the left and the right moving handlebar (52L & 52R) on the handlebar post (10), using two bolts (40), two flat washers (66) and two wave washers (47). Now fix the two axle covers (23) - fig. a & b. CT 40...
  • Page 15 Step 4 1. Connect the left and the right moving handlebar (52L & 52R) with the movable support welding sets (12), using four curved washers (6), four spring washers (7) and four allen bolts (9) - fig. a. 2. Lift the upper protective cover (49) of the handlebar post (10) and fix the assembly, using the re- maining six curved washers (6), six spring washers (7) and six allen bolts (9) - fig.
  • Page 16 Step 5 1. Guide the handpulse cables (13) of the fixed handlebar (72) through the small hole on the side of the handlebar post (10) and then through the opening. - see detail drawing. 2. Assemble the fixed handlebar (72) to the handlebar post (10), using two curved washers (6), two spring washers (7) and two allen bolts (9).
  • Page 17 Step 6 1. Connect the handpulse cables (13) with the corresponding cables of the console (64). Plug the upper console cable (29) into the console (64). Now put any excess cable into the opening of the handlebar post (10) before you place the console (64) on top. Be careful not to pinch the cables. Now assemble the console (64) on the handlebar post (10), using four cross bolts (90).

  • Page 18: Operating Instructions

    OPERATING INSTRUCTIONS Console display CT 40...
  • Page 19 WATT Displays the current load in Watt, display range: 0 - 999 Displays your calorie consumption in kcal, display range: CALORIES 0 - 9999; adjustment range: 0 - 9990 DISTANCE Displays your covered distance in m, display range: 0 - 9999 m Displays your pulse beats per minute (BPM), display range: 30 - 230 PULSE SPEED...

  • Page 20: Button Functions

    Button functions START/STOP Use this button to start, to stop or to pause your training. Use this function to increase values or use this function to choose Rotary knob (UP) between settings. Rotary knob Use this function to decrease values or use this function to choose (DOWN) between settings.

  • Page 21: How To Turn On The Elliptical Cross Trainer And First Settings

    How to turn on the elliptical cross trainer and first settings As soon as you connect the power cable to the power supply, the computer will turn on and the LCD display will show all the segments for 2 seconds. Use the rotary knob (UP/DOWN) to choose a user (U1 - U4) and confirm your choice with the MODE button.

  • Page 22: Pre-Set Programmes

    4.4.2 Pre-set programmes (PROGRAM) 1. Select the pre-set programme mode (PROGRAM) by turning the rotary knob (UP/DOWN) and confirm your choice with the MODE button. 2. Choose one of the twelve programmes (P1 - P12) and confirm your choice with the MODE button. 3.

  • Page 23: Heart Rate-Controlled Programme

    4.4.4 Heart rate-oriented programme mode (H.R.C.) 1. Select the heart rate-oriented programme mode (H.R.C.) by turning the rotary knob (UP/DOWN) and confirm your choice with the MODE button. 2. Choose one of the heart rate-oriented programmes: H.R.C. 55%, H.R.C. 75%, H.R.C. 90% or H.R.C. Target (Target heart rate, standard value = 100) and confirm your choice with the MODE button.

  • Page 24: Body Fat Test

    4.4.6 Body fat test (BODY FAT) 1. Im STOP Modus drücken Sie BODY FAT, um die Messung des Körperfetts zu starten. 2. Put your hands firmly around the hand pulse sensors during the measurement. After 8 seconds the LCD display will show you the body fat percentage and BMI. The body fat percentage will be displayed as different symbols.

  • Page 25: General Notes

    General notes 1. When the pedals are not used for 4 minutes, the computer will go intro sleep mode. All settings and training data will be saved until you return to your training. 2. In case the computer functions abnormally, disconnect the elliptical crosstrainer from its power supply and reconnect it again.

  • Page 26: Heart Rate Measuring

    Heart rate measuring Pulse measurement through hand sensors The hand sensors integrated in the handles allow you to determine your heart rate. You can measure your heart rate by lightly grasping the sensors with both hands at the same time. Blood pressure changes occur due to the heartbeat.
  • Page 27 Anaerobic (maximum) load training: The main goal of maximum load training is to improve recovery after short, intense loads in order to be able to quickly return to the aerobic zone. In order to achieve this training goal, a high intensity (approximately 90% of the maximum heart rate) with short, intense load is required, which is followed by a recovery phase in order to prevent muscle fatigue.

  • Page 28: Warranty Information

    WARRANTY INFORMATION Darwins‘s fitness equipment is subject to strict quality controls. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. Error descriptions Your fitness equipment is developed for long-term, high-quality training.
  • Page 29 Warranty service Within the warranty period, equipment which develops faults as a result of material or manufac- turing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.

  • Page 30: Disposal

    DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an electricals recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols.

  • Page 31: Ordering Spare Parts

    ORDERING SPARE PARTS Service hotline So that we can give you the best possible service, please have your model name, part number, serial number, exploded drawing and parts list ready. SERVICE HOTLINE 80 90 16 50 +49 4621 4210-0 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-699 +49 4621 4210-933...

  • Page 32: Parts List

    Parts list Description Drawing No. Qty. Main frame 829E2-3-1000-J0 Front stabilizer 16100-6-2101-J1 Allen bolt 50508-5-0075-F3 Adjustable foot cap 55450-5-0060-B1 Front foot cap 55443-1-0060-B3 Curved washer 55108-3-2215-FA Spring washer 55108-2-1520-FA Domed nut 55208-6-2015-FA Allen bolt 50308-5-0020-F0 Handlebar post 829D2-3-2000-J0 Pedal supporting tube 829D2-3-3800-J0 Movable support welding set 829D2-3-3700-J0...
  • Page 33 Description Drawing No. Qty. pulley D240x21 pedal axle D19*118.5L crank welding set cross screw ST4.2x1.4x20L belt 390 PJ5 left chaincover 1096.4*527.5*65.9 right chaincover 1096.4*527.5*61.6 flywheel D260*69.5L*7KG protective cover 114*76*43 side cover D36*14 bolt M8x1.25x20 Allen bolt M8*1.25*55L round cover D377x20.5T bearing #6003ZZ Flat washer...
  • Page 34 Description Drawing No. Qty. round magnet M02 with base square cap 30*60*15 console SM-3730-67 handpulse PE18 Flat washer D25xD8.5x2T bushing D22.2*33.3L bolt M8x1.25x20L front pedal axle D15.83*62.7L idle wheel fixing plate bolt M6x1.0x15L fixed handlebar Flat washer D14xD6.5x0.8T bolt cover D30*17(M12) bolt cover D28*17(M10)
  • Page 35 Description Drawing No. Qty. nylon flat washer 55106-1-1915-B1 plastic flat washer 55110-1-2404-BF adaptor 804C2-6-2584-01 sensor cable 829E2-6-2576-00 cross screw 52804-2-0012-F0 electrical cable 73102-6-2596-00 motor 180B2-6-2571-00 pedal axle cover 71801-6-2905-B1 cross bolt 52605-2-0012-N0 allen spanner 58030-6-1031-N1 opening spanner 58030-6-1035-N1...

  • Page 36: Exploded Drawing

    Exploded drawing CT 40...
  • Page 37 DISCLAIMER ©2015 Darwin Fitness is a registered brand of the company Sport- Tiedje GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Sport-Tiedje is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
  • Page 38 Notes CT 40...
  • Page 40 DARWIN CT 40...
