- Page 1 Assembly and Operating Instructions max. 100 kg ~ 180 Min. 105 kg L 179 | W 116 | H 196 FSDFHG30.01.03 Art. No. DF-HG30 DARWIN HG30...
- Page 2 HG30...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 HG30...
- Page 5 European VAT Number: DE813211547 Disclaimer © Darwin Fitness is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
GENERAL INFORMATION Technical Data Weight and dimensions: Article weight (gross, incl. packaging): No. 1 56kg No. 2 11.9kg No. 3 24kg No. 4 24kg Article weight (net, without packaging): 105.2kg Packaging dimensions (L x B x H): No. 1 approx. 187cm x 75cm x 19cm No. -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠... -
Page 14: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so. - Page 15 Step 2: Assembling the upper frame and backrest Mount the upper frame (3) onto the main frame (1) with two screws (48), four washers (64) and two nuts (61). Mount the two upper weight block cover connectors (69) onto the upper frame (3), each with two screws (18) and two washers (65).
- Page 16 Step 3: Mounting the leg press Mount the seat connector frame (6) onto the base frame (2) with two screws (48), four washers (64) and two nuts (61). Mount the seat frame (4) along with the connection plate (29) onto the main frame (1) with two screws (48), four washers (64) and two nuts (61).
- Page 17 Step 4: Assembling the upper body frame Mount the connector frame (5) onto the upper frame (3) with one screw (68), two washers (63) and one nut (60). Mount the two arm frames (8L/R) on the connector frame (5), each with one screw (39), two washers (64) and one nut (61).
- Page 18 Step 5: Assembling the cable - Part 1 Fasten one end of the Cable (20) on the left arm frame (8L) with one screw (52), two washers (64) and one nut (61). String the cable (20) through the pulley (32) and fasten it along with the pulley covers (31) onto the left side of the pulley support (27) with one screw (51), two washers (64) and one nut (61) (see fi g.
- Page 19 Step 6: Assembling the cable - Part 2 String the cable (21) through the pulley (32) and fasten it onto upper frame (3) with one screw (50), two washers (64) and one nut (61). String the cable (21) through the pulley (32) and fasten it on the main frame (1) with one screw (49), two spacers (37), two washers (64) and one nut (61).
- Page 20 Step 7: Assembling the cable - Part 3 String the cable (22) through the pulley (32) and fasten it onto the leg press frame (7) with one screw (49), two washers (64), two spacers (37) and one nut (61). String the cable (22) through the pulley (32) and fasten it onto the main frame (1) with one screw (49), two washers (64), two spacers (37) and one nut (61).
- Page 21 Step 8: Mounting the pull down bar and rowing attachment Fasten the pull down bar (10) with the carabine (40) onto the end of the cable (23). Fasten the rowing attachment (1) with the carabine onto the end of the cable (22).
- Page 22 Step 9: Attaching the covers Attach the weight block covers (35) onto the upper weight block cover connectors (69), each with four screws (59) and four washers (65). Attache the weight block covers (35) onto the lower weight block cover connectors (70), each with four screws (59) and four washers (65).
- Page 23 Step 10: Final checks Check that all cables have been correctly strung. Tighten all screw connections.
- Page 24 Step 11: Weight label stickers Put one sticker on one weight plate each according to the fi gure below (from top to bottom). 28mm 5 KG 12mm 10 KG 15 KG 20 KG 25 KG 30 KG 35 KG 40 KG 45 KG 50 KG Load and Unload Weight Plates...
-
Page 25: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. -
Page 26: Faults And Fault Diagnosis
Faults and Fault Diagnosis The equipment undergoes regular quality controls during production. Nevertheless, faults or malfunctions may occur. Frequently, individual parts are responsible for these disturbances, an exchange is usually suffi cient. Please refer to the following overview for the most common errors and how to correct them. -
Page 27: Disposal
DISPOSAL At the end of its operational life, this equipment cannot be disposed of in normal household waste. Instead, it must be disposed of via an recycling centre. Further information can be obtained from your local authority‘s recycling service. The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. -
Page 28: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. For training equipment like smith machines, weight benches or racks this could for example be a fl oor mat, which makes your fi tness equipment stand more securely and also protects the fl oor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes. -
Page 29: Ordering Spare Parts
It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Darwin Fitness / multi-gym Model Name: HG30 Article Number: DF-HG30... -
Page 30: Parts List
Parts List Name Qty. Name Name Qty. Qty. Main frame Pulley Base frame Knob nut Oblique beam combination Plastic weight stack Seat combination Steel net Hanger combination Alloy sleeve Support frame combination Spacer Leg frame Alloy sleeve 8L/R Swing arm combination 1 pr Bolt Long bar... - Page 31 Flat washer D12 Flat washer D10 Flat washer D8 Flat washer D6 Spring washer M10 Long bolt M12X145 Fixed plate on the cover Fixed plate under cover...
-
Page 32: Exploded Drawing
Exploded Drawing HG30... -
Page 33: Warranty
WARRANTY Products from Darwin Fitness® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 34 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 35: Contact
CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��... - Page 36 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Fitshop is Europe’s largest specialist store for www.fi tshop.co.uk home fi tness equipment with currently over 70 www.fi tshop.de/blog stores and one of the world’s most renowned online mail order companies for fi tness equipment.
- Page 37 Notes...
- Page 38 Notes HG30...
- Page 40 DARWIN HG30...
