- Page 1 Assembly Instructions max. 150 kg ~ 30 Min. 13 kg L 129 | W 43 | H 36 FSDFFB50.01.01 Art. No. DF-FB50 DARWIN weight bench FB50...
- Page 2 FB50...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 FB50...
- Page 5 European VAT Number: DE813211547 Disclaimer © Darwin Fitness is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
- Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). FB50...
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
Set-up dimensions (L x W x H): 129 cm x 43 cm x 36 cm Folded dimensions (L x W x H): 120 cm x 43 cm x 18 cm Maximum load (user + weights): 150 kg Use class: FB50... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Set-Up Place
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. For Class S equipment, the exercise equipment may only be used in areas where access, supervision and control are specifi cally regulated by the owner. FB50... -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. - Page 12 3 - Base frame (2x) 4 - Foot tube (1x) 5 - Carriage (1x) 6 - Right backrest frame (1x) 7 - Left backrest frame (1x) 8 - Backrest support (1x) 9 - Backrest cushion (1x) 10 - Seat cushion (1x) FB50...
- Page 13 Hardware pack 11 - Knob (2x) 12 - Small cover (2x) 13 - Big cover (4x) 14 - Carriage sleeve 16 - M10*180mm 17 - M10*100mm 15 - Backrest frame cap (2x) hex bolt (2x) hex bolt (1x) (4x) 18 - M10*75mm 20 - M8*50mm 21 - M10 washer 19 - M8*20mm...
-
Page 14: Assembly
Attach the second base frame (3) to the main frame (1) with three bolts (19) and three washers (22). Attach the support frame (2) to the main frame (1) with one bolt (18), one washer (21), one locknut (23) and one knob (11). FB50... - Page 15 Step 3: Assembly of the Backrest Frames and Backrest Support NOTICE Two bushings (24) are pre-assembled to the main frame (1). Attach the right and left backrest frames (6 & 7) to the main frame (1) with one bolt (16), two washers (21) and one locknut (23).
-
Page 16: Storage And Transport
ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 10°C and 35°C. FB50... -
Page 17: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 18: Maintenance And Inspection Calendar
The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. FB50... -
Page 19: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. This could be a fl oor mat, for example, which makes your fi tness equipment stand more securely and also protects the fl oor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 20: Ordering Spare Parts
NOTICE The serial number of your equipment is unique. It's located on a white sticker. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Darwin / weight bench Model Name: FB50 Article Number: DF-FB50 FB50... -
Page 21: Parts List
Parts List Name Qty. Main Frame Support Frame Base Frame Foot Tube Carriage Right Backrest Frame Left Backrest Frame Backrest Support Backrest Cushion Seat Cushion Knob Small Cover Big Cover Carriage Sleeve Backrest Frame Cap M10*180mm Hex Bolt M10*100mm Hex Bolt M10*75 Bolt M8*20mm Hex Bolt M8*50mm Hex Bolt... -
Page 22: Exploded Drawing
Exploded Drawing FB50... -
Page 23: Warranty
WARRANTY Products from Darwin Fitness® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 24 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. FB50...
-
Page 25: Contact
CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��... - Page 26 Visit us also on our social media platforms or our blog! FB50...
- Page 28 DARWIN FB50...
