Some tapes will interfere with replacing the gripper jaws and need to be temporarily removed from the library.
Use the host backup software or the library front panel interface to remove the following tapes from the
library.
Tape slots to be
emptied
1. Perform a complete system shut down. Exit all programs running on the host computer and switch
OFF power to the host computer, the library, and any other attached equipment.
Warning:
Warning:
2. Disconnect all cables from the library.
• Disconnect the AC power cord from the wall outlet and the rear of the library.
• Disconnect the SCSI cables from the rear of the library.
• If applicable, disconnect the serial cable(s) from the RS–232 port(s) on the rear of the library.
3. If necessary, move the library to a location where you have access to all sides of the library.
Warning: The library is heavy, about 56 pounds. Get help when moving the library.
Page 4
Spectra 4000, 5000 and 5100
20 slot carousel
4 and 5
20 slot carousel
Tape slots to be
5 through 8
emptied
Gripper Jaws Replacement Guide for Spectra Logic Libraries
4mm Tape Libraries
40 slot carousel 60 slot carousel
6 through 10
Spectra 9000 and 10000
8mm Tape Libraries
40 slot carousel
9 through 14
8 through 15
