KAKA Industrial TR-40 Operation Manual

Operation Manual
KAKA Industrial
Unpacking
T h e Tu b e R o l l e r i s s h i p p e d f r o m t h e
manufacturer in a carefully packed Carton
box. Thoroughly inspect the product upon
opening the package.
After unpacking the unit, carefully inspect for
any damage that may have occurred during
transit. Check for loose, missing, or damaged
parts. Shipping damage claims must be filed
with the carrier and are the responsibility of
the user.
Specifications
Dia. Of Upper roller ...........Φ90mm / 3-1/2 In
Thickness of Upper roller.............50mm / 2 In
Dia. Of Lower roller...........Φ40mm / 3-9/16 In
Thickness of Lower roller.............78mm / 3 In
Vertical travel of Upper roller.......150mm / 6 In
Min. Center distance of Lower roller ................
................................................. 320mm / 13 In
Max. Center distance of Lower roller..............
...............................................480mm / 19 In
Overall dimension........ 20-3/4"x9-3/4"x29-1/2"
Weight.............................................. 43 lbs
Can process material of mild steel, cuprum,
aluminum, etc.
20mmx20mmx1.2mm
Mild steel
M a x .
Copper
capacity
20mmx20mmx1.75mm 25mmx25mmx1.75mm
Aluminum
Min. R
Min. Ø
25mmx25mmx1.2mm
3/4"x3/4"x3/64"
20x20x1.5
3/4"x3/4"x1/16"
3/4"x3/4"x9/128"
180mm
7-3/32"
450mm
17-23/32"
Important:
The tube roller is coated with a protectant.
To ensure proper fit and operation, remove
coating. Coating is easily removed with mild
solvents, such as mineral spirits, and a soft
cloth. Avoid getting cleaning solution on paint
or any of the rubber or plastic parts. Solvents
may deteriorate these finishes. Use soap and
water on paint, plastic or rubber components.
After cleaning, cover all exposed surfaces with
a light coating of oil.
Appearance of the machine
30mmx30mmx1.5mm
1"x1"x3/64" 1-1/4"x1-1/4"x1/16"
25x25x1.5
1"x1"x1/16" 1-1/4"x1-1/4"x9/128"
30mmx30mmx2mm
1"x1"x9/128" 1-1/4"x1-1/4"x5/64"
170mm
6-45/64"
500mm
19-11/16"
— 1 —
®
40mmx40mmx1.5mm
1-1/2"x1-1/2"x1/16"
30x30x1.75 40x40x1.75
1-1/2"x1-1/2"x9/128"
40mmx40mmx1.75mm
1-1/2"X1-1/2"X5/64"
200mm
7-7/8"
550mm
21-21/32"
TR-40
220mm
8-43/64"
600mm
23-5/8"
