- Page 1 VPH-F200-T Climate Control Housing Manual...
- Page 2 Phone: +49 621 776 - 0 E-mail: info@de.pepperl-fuchs.com North American Headquarters Pepperl+Fuchs Inc. 1600 Enterprise Parkway Twinsburg, Ohio 44087 Phone: +1 330 425-3555 E-mail: sales@us.pepperl-fuchs.com Asia Headquarters Pepperl+Fuchs Pte. Ltd. P+F Building 18 Ayer Rajah Crescent Singapore 139942 Phone: +65 6779-9091 E-mail: sales@sg.pepperl-fuchs.com https://www.pepperl-fuchs.com...
-
Page 3: Table Of Contents
VPH-F200-T Contents Introduction........................ 4 Content of this Document ................4 About This Documentation ................4 Symbols Used ....................5 Safety Information ..................... 6 Product Description ....................7 Transport and Storage ....................9 Mounting........................10 Commissioning......................25 Servicing........................26... -
Page 4: Introduction
VPH-F200-T Introduction Introduction Content of this Document This document contains safety-relevant information for using the device. This information is required to use the product in the relevant phases of the product life cycle. This may include information on the following: •... -
Page 5: Symbols Used
VPH-F200-T Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid prop- erty damage. -
Page 6: Safety Information
VPH-F200-T Safety Information Safety Information Read the information in this document carefully and observe this information when working with the device. Failure to observe the safety information and warning messages in this docu- mentation can lead to malfunctions of the safety devices of the machines or plants in which they are fitted. -
Page 7: Product Description
Product Description Product Description The "VPH-F200-T" climate control housing (hereinafter referred to as the VPH housing) extends the range of applications for the chosen sensor modules, allowing them to be used at an ambient temperature of up to +80 °C. The sensor fixture is designed for the Data Matrix positioning system (PXV) with the "F200"... - Page 8 VPH-F200-T Product Description Front View The key feature on the front of the VPH housing is the central protective panel. The protective panel is embedded in the front of the upper shell. The protective panel provides an opening to allow the chosen sensor module to capture positioning information and other data. The protec- tive panel must be cleaned regularly to prevent the sensor from generating incorrect measure- ments and error messages.
-
Page 9: Transport And Storage
VPH-F200-T Transport and Storage Transport and Storage Retain the original packaging. Always store or transport the device in the original packaging to protect it from electrostatic discharge (ESD) and mechanical damage. -
Page 10: Mounting
VPH-F200-T Mounting Mounting Caution! Malfunctions caused by condensation Severe fluctuations in the ambient temperature can impair the sensor functionality. • Avoid excessive temperature fluctuations to prevent condensation forming on the protec- tive panel at the front of the VPH housing. - Page 11 VPH-F200-T Mounting Figure 5.1 Mounting the sensor Carefully lift the sensor fixture away from the connection board (1). Be careful with the cabling connected to the sensor fixture. Insert the sensor into the designated recess (2). Using two screws (3), secure the sensor in place from underneath the sensor fixture.
- Page 12 VPH-F200-T Mounting Figure 5.2 Securing the sensor fixture Tighten the four screws (1) in the sensor fixture.
- Page 13 VPH-F200-T Mounting Cabling Danger! Danger to life due to electrical current Making contact with live parts causes electric shocks, which pose an immedi- ate danger to life. • Allow only qualified electricians to carry out work on the electrical compo- nents.
- Page 14 VPH-F200-T Mounting Figure 5.4 Removal...
- Page 15 VPH-F200-T Mounting Electrical Connection Caution! Damage to the device Connecting an alternating current or excessive supply voltage can damage the device or cause the device to malfunction. Electrical connections with reversed polarity can damage the device or cause the device to malfunction.
- Page 16 VPH-F200-T Mounting Fault Monitoring The climate control housing has an integrated monitoring system for the fan function and the excess temperature shut-off function. The respective fault is indicated via a potential-free switching contact on terminal strip X2. There are also two red control LEDs on the inside of the board to indicate the status.
- Page 17 VPH-F200-T Mounting Solid State Relay Connections The figure below shows how the solid state relay (SSR) is connected. The LED on the SSR indicates the operating state of the SSR. If the LED is illuminated, this indicates that the SSR output is connected and the VPH housing is in cooling mode.
- Page 18 VPH-F200-T Mounting Cable Length We recommend a maximum cable length of 25 m. The power supply must be readjusted as shown in the figure below. 30,00 28,00 26,00 24,00 Distance [s] = m Figure 5.9 Voltage drop with a 1.5 mm...
- Page 19 VPH-F200-T Mounting Setting the Read Distance Note The optimal read distance between the sensor and the Data Matrix code tape is set out in the documentation provided with the chosen sensor. To find the relevant documentation, visit our website at www.pepperl-fuchs.com. Simply enter the product name or model number in the product/keyword field and click the search button.
- Page 20 VPH-F200-T Mounting Note Note that the read distance of the sensor shifts by approx. 47 mm because the first clearance hole in the mounting foot sits 47 mm behind the sensor (see the figure above). We recommend that you measure the distances within the device before mounting.
- Page 21 VPH-F200-T Mounting Mounting the Upper Shell Note Before mounting the upper shell, remove the protective film on the inside and outside of the protective panel. Figure 5.11 Preparing for mounting Distribute the 11 sealing rings (1) among the screws (2) for mounting the upper shell.
- Page 22 VPH-F200-T Mounting Figure 5.12 Mounting the upper shell First tighten the screws, spring washers, and washers in the upper shell manually and then to a tightening torque of 1 Nm. This is the only way to guarantee the relevant degree of protection.
- Page 23 VPH-F200-T Mounting Securing the Mounting Foot Using Threaded Holes Figure 5.13 Mounting foot Drill three Ø 8.5 mm holes as shown in the figure above. Cut M10 threads into the three holes. Insert and lightly tighten the screws, washers, and spring washers (not included in the scope of delivery) as shown in figure above.
- Page 24 VPH-F200-T Mounting Securing the Mounting Foot Using Clearance Holes Figure 5.14 Clearance hole Drill three Ø 10.5 mm holes as shown in the "Mounting foot" figure. Insert and lightly tighten the screw (1), washer (4), spring washer (5), and nut (6) as shown in figure above (2 = mounting surface, 3 = mounting foot).
-
Page 25: Commissioning
VPH-F200-T Commissioning Commissioning Once the VPH housing has been fully mounted, it is ready for commissioning. Commissioning may be carried out only by trained and qualified personnel and by personnel specially trained in handling the device to ensure that it functions properly. -
Page 26: Servicing
VPH-F200-T Servicing Servicing Danger! Danger to life due to electrical current Making contact with live parts causes electric shocks, which pose an immediate danger to life. • Allow only qualified electricians to carry out work on the electrical components. •... - Page 27 Pepperl+Fuchs Quality Download our latest policy here: www.pepperl-fuchs.com/quality www.pepperl-fuchs.com © Pepperl+Fuchs · Subject to modifications / DOCT-6468...
