  • Page 1 PMI360DV-F130-3E2-V15 Inductive Angular Positioning System Manual...
  • Page 2 Phone: +49 621 776 - 0 E-mail: info@de.pepperl-fuchs.com North American Headquarters Pepperl+Fuchs Inc. 1600 Enterprise Parkway Twinsburg, Ohio 44087 Phone: +1 330 425-3555 E-mail: sales@us.pepperl-fuchs.com Asia Headquarters Pepperl+Fuchs Pte. Ltd. P+F Building 18 Ayer Rajah Crescent Singapore 139942 Phone: +65 6779-9091 E-mail: sales@sg.pepperl-fuchs.com https://www.pepperl-fuchs.com...
  • Page 3: Table Of Contents

    PMI360DV-F130-3E2-V15 Contents Introduction........................ 4 Declaration of Conformity..................5 Safety .......................... 6 Symbols Used ....................6 Intended use ....................6 General safety instructions ................6 Product Description ....................7 Use and Application ..................7 Displays and Operating Elements..............8 Accessories....................9 4.3.1...
  • Page 4: Introduction

    PMI360DV-F130-3E2-V15 Introduction Introduction Congratulations You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops, pro- duces and distributes electronic sensors and interface modules for the market of automation technology on a worldwide scale. Symbols used The following symbols are used in this manual: Note This symbol draws your attention to important information.
  • Page 5: Declaration Of Conformity

    This product was developed and manufactured in line with the applicable European standards and directives. Note A declaration of conformity can be requested from the manufacturer. The product manufacturer, Pepperl+Fuchs Group, 68307 Mannheim, Germany, has a certified quality assurance system that conforms to ISO 9001. ISO9001...
  • Page 6: Safety

    In the event of any serious errors, stop using the device. Secure the device against unintended operation. To have the device repaired, return it to your local Pepperl+Fuchs representative or your sales center. Note Disposal Electronic waste is hazardous.
  • Page 7: Product Description

    The actuator BT-F130-A (see chapter 4.3) is usually attached to the rotary system component to detect the position. This actuator rotates in the central hole on the PMI360DV-F130-3E2-V15 and contains the metal insert required for detecting the position. The component is optimally adapted to the mechanical requirements of valves and valve actuators.
  • Page 8: Displays And Operating Elements

    PMI360DV-F130-3E2-V15 Product Description Displays and Operating Elements LED indicators Programming buttons 4 LEDs and 3 programming buttons are located on top of the PMI360DV-F130-IU2E2-V15. The central, front "Power/Error" LED is a 2-color LED that lights up or flashes green (normal operation) or red (fault) depending on the current operating state of the device.
  • Page 9: Accessories

    PMI360DV-F130-3E2-V15 Product Description Accessories Various accessories are available. 4.3.1 Connection Cables You can use the following single-ended female cordsets to establish the electrical connection: M12 x 1 single-ended female cordsets, 5-pin Illustration Material Length Model number M12 x 1, straight, 5-pin...
  • Page 10: Installation

    PMI360DV-F130-3E2-V15 Installation Installation Note on safety Warning! Risk of short circuit Working on live parts can cause injuries and can compromise the function and the electrical safety of the device. • Before working on the device, always disconnect the supply voltage.
  • Page 11 PMI360DV-F130-3E2-V15 Installation Using a different actuating element The BT-F130-A actuator included can be replaced with a different actuator, provided that the new actuator fits in the sensor opening. When using a different actuator element, the element must fulfill all requirements relating to the material, dimensions and distance to the sensitive surface on the sensor (see table).
  • Page 12: Electrical Connection

    Check that the wires are connected correctly before connecting the cordset to the sensor. On Pepperl+Fuchs cordsets, the wire colors are assigned to the connecting pins in the connector according to DIN EN 60947-5-2. Attach the socket on the cordset to the connector on the sensor and tighten the union nut by hand.
  • Page 13 PMI360DV-F130-3E2-V15 Installation Connector pin Function Switching output Q2 (switching window S2) Switching output Q1 (switching window S1) Switching output Q3 (switching window S3) Wire colors are assigned to the connecting pins in the connector according to DIN EN60947-5-2. Connecting pin...
  • Page 14: Commissioning

    PMI360DV-F130-3E2-V15 Commissioning Commissioning Programming the Switching Outputs 2 switching windows with a window width of 5° (+/- 2.5°) are preset at the factory. The switching windows lie between the angle settings 117.5°... 122.5° (S1), and 237.5° ... 242.5° (S2). You can modify the position and width of these switching windows by programming them accord- ingly.
  • Page 15 PMI360DV-F130-3E2-V15 Commissioning Move the actuator to the position that you wish to define as the start point of the switching window. Press the S1 button again. The yellow S1 LED lights up for 2 seconds and then starts to flash again. This indicates that the device is ready for you to teach in the switching window end point.
  • Page 16 PMI360DV-F130-3E2-V15 Commissioning Programming switching output S3 Switching output 3 (S3) is programmed in the same way. Press the S3 button to do so. The S3 LED indicates the status. Programming switching output S2 Switching output 2 (S2) is programmed in the same way. Press the S2 button to do so. The S2 LED indicates the status.
  • Page 17: Output Logic During Normal Operation

    PMI360DV-F130-3E2-V15 Output Logic during Normal Operation Output Logic during Normal Operation Beispiel 0° 90° 180° 270° 360° 20° 60° Figure 7.1 Output function depends on the position of the actuator and the method used to program the outputs. 1. 0° angular position marking 2.
  • Page 18: Function Of Switching Outputs S1, S2, And S3

    PMI360DV-F130-3E2-V15 Function of Switching Outputs S1, S2, and S3 Function of Switching Outputs S1, S2, and S3 The position of the actuator determined by the angular positioning system is based on half of the actuator width (center of the actuator). The switch points are preset to the angle settings 0°...
  • Page 19: Maintenance And Repair

    S3 = 0° - 5° S2 = 240° - 245° S1 = 120° - 125° Factory setting PMI360DV-F130-3E2-V15 Reset process Press and hold the sensor button assigned to the output that you would like to reset. The associated yellow LED starts to flash slowly after 2 seconds.
  • Page 20 PMI360DV-F130-3E2-V15 Maintenance and Repair Note If a button is pressed and held for more than 15 seconds, the associated LED starts to flash slowly again. The "Power/Error" LED then flashes red at the same time. This fault signal indicates that a button is stuck. A reset to the factory setting does not occur in this case. As soon as the button is released, the "Power/Error"...
  • Page 21: Troubleshooting

    PMI360DV-F130-3E2-V15 Troubleshooting Troubleshooting 10.1 Faults when Programming the Outputs If unexpected statuses occur when programming the outputs of the inductive angular position- ing system, refer to the table below for possible causes and instructions for rectifying the prob- lem. Status...
  • Page 22: Faults During Operation

    PMI360DV-F130-3E2-V15 Troubleshooting 10.2 Faults during Operation If the inductive angular positioning system does not function correctly, refer to the table below for possible causes and instructions for rectifying the problem. Error Possible cause Action "Power/Error" LED does not The power supply is switched...
  • Page 23: Disposal

    PMI360DV-F130-3E2-V15 Disposal Disposal Electronic waste is hazardous waste. When disposing of the equipment, observe the current statutory requirements in the respective country of use, as well as local regulations. The device does not contain any batteries that require separate disposal.
