ARTERY AT32F402 Series Reference Manual

Arm-based 32-bit cortex -m4f mcu+fpu, with 128 to 256 kb flash, slib, usbfs/hs-otg, 12 timers, 1 adc, 20 communication interfaces

Hide thumbs Also See for AT32F402 Series:

Getting started (27 pages)

Table Of Contents

page of 516

/ 516
Contents
Table of Contents
Bookmarks

Table of Contents

Advertisement

Quick Links

Download this manual

®

ARM

-based 32-bit Cortex

USBFS/HS-OTG, 12 timers, 1 ADC, 20 communication interfaces



®

Core: ARM

32-bit Cortex

− 216 MHz maximum frequency, with a Memory

Protection Unit (MPU), single-cycle multiplication

and hardware division

− Floating Point Unit (FPU)

− DSP instructions



Memories

− 128 to 256 Kbytes of Flash memory

− 20 Kbytes of boot memory used as a Bootloader or

as a general instruction/data memory (one-time

configured)

− sLib: configurable part of main Flash as a library

area with code executable but secured, non-

readable

− 70 to 102 Kbytes of SRAM



Power control (PWC)

− 2.4 V to 3.6 V power supply

− Power-on reset (POR)/low voltage reset (LVR), and

power voltage monitor (PVM)

− Low-power modes: Sleep, Deepsleep and Standby

modes

− 20 x 32-bit RTC data registers (BPR)



Clock and reset management (CRM)

− 4 to 25 MHz crystal (HEXT)

− 48 MHz internal factory-trimmed HICK (1% at

TA=25 ° C, 2% at TA=-40 ° C to +105 ° C), with

automatic clock calibration (ACC)

− PLL with configurable frequency multiplication and

division factors

− 32.768 kHz crystal (LEXT)

− Low speed internal clock (LICK)



Analog

− 1 x 12-bit 2 MSPS A/D converter, up to 16 input

channels, hardware over-sampling up to equivalent

16-bit resolution

− Temperature sensor (V

(V

)

INTR



DMA

− 2 x 7-channel DMA controllers



Up to 56 fast GPIOs

− All mappable on 16 external interrupts

− Almost 5 V-tolerant



Up to 14 timers (TMR)

− 1 x 16-bit 4-channel advanced timer, each channel

PWM output with dead-time generator and

emergency break

− Up to 1 x 32-bit and 7 x 16-bit general-purpose

timers, each with 4 IC/OC/PWM or pulse counter

and incremental encoder input; including 5 timers

supporting complementary output with dead-time

2023.08.31

AT32F402/405 Series Reference Manual

®

-M4F MCU+FPU, with 128 to 256 KB Flash, sLib,

®

-M4F CPU with FPU

), internal reference voltage

TS

generator and emergency brake

− 2 x 16-bit basic timers

− 2 x watchdog timers (WDT and WWDT)

− SysTick timer: 24-bit downcounter



ERTC: Enhanced RTC, with auto wakeup, alarm,

subsecond accuracy, hardware calendar, and

calibration feature



Up to 19 communication interfaces

− Up to 3 x I

2

C interfaces (SMBus/PMBus)

− Up to 8 x USARTs/UARTs (ISO7816 interface, LIN,

IrDA capability, modem control and RS485 drive

enable, TX/RX swap)

− 3 x SPIs, all with I

combination of two interfaces support full-duplex,

with 1 full-duplex I

− 1 x CAN interface (2.0B Active)

− USB2.0 FS/host/OTG device interface, supporting

crystal-less in device mode

− USB2.0 HS/host/OTG device interface

− 1 x QSPI

− Infrared transmitter (IRTMR)



CRC calculation unit



96-bit unique ID (UID)



Debug mode

− SWD interface



Operating temperature: -40 to +105 ° C



Packages

− LQFP64 10 x 10 mm

− LQFP64 7 x 7 mm

− LQFP48 7 x 7 mm

− QFN48 6 x 6 mm

− QFN32 4 x 4 mm



List of models

Internal Flash

Model

128 Kbytes

AT32F405RBT7 AT32F405RBT7-7

AT32F405CBT7 AT32F405CBU7

AT32F405KBU7-4

AT32F402RBT7 AT32F402RBT7-7

AT32F402CBT7 AT32F402CBU7

AT32F402KBU7-4

256 Kbytes

AT32F405RCT7 AT32F405RCT7-7

AT32F405CCT7 AT32F405CCU7

AT32F405KCU7-4

AT32F402RCT7 AT32F402RCT7-7

AT32F402CCT7 AT32F402CCU7

AT32F402KCU7-45RCT7-7

AT32F405RCT7

Page 1

2

S interface multiplexed, any

2

SF interface

Ver 2.00
