ARM
®
-based 32-bit Cortex
1 ADC, 18 communication interfaces (CAN and OTGFS)
Core: ARM®32-bit Cortex
− 150 MHz maximum frequency, with a Memory
Protection Unit (MPU), single-cycle multiplication
and hardware division
− Floating Point Unit (FPU)
− DSP instructions
Memories
− 64 to 256 Kbytes of Flash memory
− 20 Kbytes of boot memory used as a Bootloader or
as a general instruction/data memory (one-time
configured)
− sLib: configurable part of main Flash as a library
area with code executable but secured, non-
readable
− Up to 48 Kbytes of SRAM
− External memory controller (XMC) with 16-bit data
bus supporting multiplexed PSRAM and NOR
memories
XMC as LCD parallel interface, 8080/6800 modes
Power control (PWC)
− 2.4 V to 3.6 V power supply
− Power-on reset (POR)/low-voltage reset (LVR), and
power voltage monitor (PVM)
− Low-power modes: Sleep, Deepsleep and Standby
modes
− 20 x 32-bit battery powered registers (ERTC_BPR)
Clock and reset management (CRM)
− 4 to 25 MHz crystal (HEXT)
− 48 MHz internal factory-trimmed HICK (± 1% at
TA=25 ° C, ± 2.5% at TA=-40 to +105 ° C), with
automatic clock calibration (ACC)
− 32 kHz crystal (LEXT)
− Low speed internal clock (LICK)
Analog
− 1 x 12-bit 5.33 MSPS A/D converter, up to 24 input
channels, 12/10/8/6-bit configurable resolution;
hardware over-sampling up to equivalent 16-bit
resolution
− Temperature sensor (V
(V
)
INTR
− 2 x 12-bit D/A converters
DMA: 14-channel DMA controller
Up to 87 fast GPIOs
− All mappable on 16 external interrupts (EXINT)
− Almost 5 V-tolerant
Up to 15 timers (TMR)
− 1 x 16-bit 7-channel advanced timer with dead-time
generator and emergency break
− Up to 8 x16-bit and 1x 32-bit general-purpose
2023.04.25
AT32F423 Series Reference Manual
TM
-M4F MCU, 64 to 256 KB Flash, sLib, 15 timers,
TM
-M4F CPU with FPU
), internal reference voltage
TS
timers, each with up to 4 IC/OC/PWM or pulse
counter and quadrature (incremental) encoder input
− 2 x 16-bit basic timers
− 2 x watchdog timers (general WDT and windowed
WWDT)
− SysTick timer: a 24-bit downcounter
ERTC: enhanced RTC with auto wakeup, alarm,
subsecond accuracy, hardware calendar and
calibration feature
Up to 18 communication interfaces
− Up to 3 x I
2
C interfaces (SMBus/PMBus)
− Up to 3 x SPIs (36 Mbit/s), all with multiplexed half-
2
duplex I
S; 2 x half-duplex I
duplex support
− Up to 8 x USARTs support master synchronization
SPI and modem control, ISO7816 interface, LIN,
IrDA, and RS485 drive enable, TX/RX swap
− Up to 2 x CAN (2.0B Active), each with dedicated
256KB buffer
− USB OTG full speed controller with on-chip PHY,
dedicated 1280KB buffer, supporting crystal-less in
device mode
− Infrared transmitter (IRTMR)
CRC calculation unit
96-bit ID (UID)
Debug mode
− SWD and JTAG interfaces
Temperature range: -40 to +105℃
Packaging
− LQFP100 14 x 14 mm LQFP64 10 x 10 mm
LQFP64 7 x 7 mm
QFN48 6 x 6 mm
QFN32 4 x 4 mm
List of models
Internal Flash
64 Kbytes
128 Kbytes
256 Kbytes
Page 1
2
S combined for full-
LQFP48 7 x 7 mm
QFN36 6 x 6 mm
Model
AT32F423K8U7-4 AT32F423T8U7
AT32F423C8U7 AT32F423C8T7
AT32F423R8T7-7 AT32F423R8T7
AT32F423V8T7
AT32F423KBU7-4 AT32F423TBU7
AT32F423CBU7 AT32F423CBT7
AT32F423RBT7-7 AT32F423RBT7
AT32F423VBT7
AT32F423KCU7-4 AT32F423TCU7
AT32F423CCU7 AT32F423CCT7
AT32F423RCT7-7 AT32F423RCT7
AT32F423VCT7
Rev 2.01
