ARTERY AT32A423 Series Reference Manual

Arm-based 32-bit cortex-m4f mcu, 64 to 256 kb flash, slib, 15 timers, 1 adc, 18 communication interfaces (can and otgfs)

page of 513

/ 513
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

ARM

-based 32-bit Cortex

1 ADC, 18 communication interfaces (CAN and OTGFS)



Core: ARM

32-bit Cortex

− 150 MHz maximum frequency, with a Memory

Protection Unit (MPU), single-cycle multiplication

and hardware division

− Floating Point Unit (FPU)

− DSP instructions



Memories

− 64 to 256 Kbytes of Flash memory

− 20 Kbytes of boot memory used as a Bootloader or

as a general instruction/data memory (one-time

configured)

− sLib: configurable part of main Flash as a library

area with code executable but secured, non-

readable

− Up to 48 Kbytes of SRAM

− External memory controller (XMC) with 16-bit data

bus supporting multiplexed PSRAM and NOR

memories



XMC as LCD parallel interface, 8080/6800 modes



Power control (PWC)

− 2.4 V to 3.6 V power supply

− Power-on reset (POR)/low voltage reset (LVR), and

power voltage monitor (PVM)

− Low-power modes: Sleep, Deepsleep and Standby

modes

− 20 x 32-bit battery powered registers (BPR)



Clock and reset management (CRM)

− 4 to 25 MHz crystal (HEXT)

− 48 MHz internal factory-trimmed HICK (± 1% at

=25 ° C, ± 2.5% at T

automatic clock calibration (ACC)

− 32 kHz crystal (LEXT)

− Low speed internal clock (LICK)



Analog

− 1 x 12-bit 5.33 MSPS A/D converter, up to 24

external input channels, 12/10/8/6-bit configurable

resolution; hardware over-sampling up to equivalent

16-bit resolution

− Temperature sensor (V

)

INTR

− 2 x 12-bit D/A converters



DMA: 14-channel DMA controller



Up to 87 fast GPIOs

− All mappable on 16 external interrupts (EXINT)

− Almost 5 V-tolerant



Up to 15 timers (TMR)

− 1 x 16-bit 7-channel advanced timer, including three

pairs of complementary channels for PWM output,

with dead-time generator and emergency brake

− Up to 8 x16-bit and 1x 32-bit general-purpose

2024.04.25

AT32A423 Series Reference Manual

-M4F MCU, 64 to 256 KB Flash, sLib, 15 timers,

-M4F CPU with FPU

=-40 to +105 ° C), with

), internal reference voltage

timers, each with up to 4 IC/OC/PWM or pulse

counter and incremental encoder input

− 2 x 16-bit basic timers

− 2 x watchdog timers (general WDT and windowed

WWDT)

− SysTick timer: a 24-bit downcounter



ERTC: enhanced RTC with auto wakeup, alarm,

subsecond accuracy, hardware calendar, with

calibration feature



Up to 18 communication interfaces

− Up to 3 x I

C interfaces (SMBus/PMBus)

− Up to 3 x SPIs (36 Mbit/s), all with multiplexed half-

duplex I

S; 2 x half-duplex I

duplex mode

− Up to 8 x USARTs support master synchronization

SPI and modem control, ISO7816 interface, LIN,

IrDA, and RS485 drive enable, TX/RX swap

− Up to 2 x CAN (2.0B Active), each with dedicated

256 KB buffer

− USB OTGFS controller with on-chip PHY, dedicated

1280 KB buffer, supporting crystal-less in device

mode

− Infrared transmitter (IRTMR)



CRC calculation unit



96-bit ID (UID)



Debug mode

− SWD and JTAG interfaces



Temperature range: -40 to +105℃



Packages

− LQFP100 14 x 14 mm LQFP64 10 x 10 mm

LQFP64 7 x 7 mm

QFN48 6 x 6 mm

QFN32 4 x 4 mm



List of models

Internal Flash

64 Kbytes

128 Kbytes

256 Kbytes

AT32A423 series: AEC-Q100 certified

Page 1

S combined for full-

LQFP48 7 x 7 mm

QFN36 6 x 6 mm

Part number

AT32A423K8U7-4 AT32A423T8U7

AT32A423C8U7 AT32A423C8T7

AT32A423R8T7-7 AT32A423R8T7

AT32A423V8T7

AT32A423KBU7-4 AT32A423TBU7

AT32A423CBU7 AT32A423CBT7

AT32A423RBT7-7 AT32A423RBT7

AT32A423VBT7

AT32A423KCU7-4 AT32A423TCU7

AT32A423CCU7 AT32A423CCT7

AT32A423RCT7-7 AT32A423RCT7

AT32A423VCT7

Rev 2.00
