Ordering Codes

Codes Description
DA-020S024PX 20 Nm, Modulating, adjustable setpoint
DA-020S024P2 20 Nm, Modulating, adjustable setpoint, 2 auxiliary switches
Technical Specifications
Product Codes
Power Requirements:
Transformer Sizing Requirements
- Minimum per Actuator 20 VA
Input Signal/Adjustments
Control Input Impedance
Feedback Signal
Auxiliary Switch Rating
Spring Return
Running and Spring Return Torque
Rotation Range
Rotation Time
- Power On (Running) 150 Seconds for 0 to 20 Nm at All Operating Conditions; Independent of Load
- Power Off (Spring Returning) 20 Seconds for 0 to 20 Nm at Room Temperature
Cycles
Audible Noise Rating
- Power On (Running) <40 dBA at 1 m
- Power On (Holding) <20 dBA at 1 m
- Power Off (Spring Returning) <55 dBA at 1 m
Electrical Connections (Actuator Auxiliary Switches)
Conduit Connections
Mechanical Connections
- Standard Shaft Clamp Included with Actuator 12 to 19 mm Diameter Round Shafts, or 10, 12, and 14 mm Square Shafts
- Optional M9220-600 Jackshaft Coupler Kit 19 to 27 mm Diameter Round Shafts, or 16, 18, and 19 mm Square Shafts
Aluminum Enclosure
Ambient Conditions
Dimensions
Shipping Weight
Compliance
- Australia and New Zealand C-Tick Mark, Australia / NZ Emissions Compliant
DA-020S024PX / DA-020S024P2
AC 24 V (19.2 to 30 V) at 50/60 Hz: Class 2 (North America) or SELV (Europe)
- Running 15.5 VA
- Holding Position 7.7 VA
DC 24 V (21.6 to 26.4 V): Class 2 (North America) or SELV (Europe)
- Running 6.7 W
- Holding Position 2.9 W
Factory Set DC 0 to 10 V, CW Rotation with Signal Increase
Selectable DC 0 to 10 V or 0 to 20 mA
With Field Furnished 500 ohm, 0.25 W minimum resistor
Start Point Programmable DC 0 to 10 V;
Span Programmable DC 2 to 10 V;
Switch Selectable Direct or Reverse Action with Signal Increase
Voltage Input: 100,000 ohms; Current Input: 500 ohms with Field Furnished 500 ohm Resistor
0 to 10 VDC for Desired Rotation Range up to 90°; 10 V @ 1 mA max
Two Single-Pole, Double-Throw (SPDT), Double-Insulated Switches with Gold Flash Contacts:
AC 24 V, 50 VA Pilot Duty;
AC 120 V, 5.8 A Resistive, 1/4 hp, 275 VA Pilot Duty;
AC 240 V, 5.0 A Resistive, 1/4 hp, 275 VA Pilot Duty
Direction is Selectable with Mounting Position of Actuator:
Side A, Actuator Face Away from Damper for CCW Spring Return;
Side B, Actuator Face Away from Damper for CW Spring Return
20 Nm for a Single Actuator;
40 Nm for Two Models Mounted in Tandem
60 Nm for Three models Mounted in Tandem
Adjustable from 30 to 90° CW or CCW with Optional M9220-603 Adjustable Stop Kit
Mechanically Limited to 90°
90 Seconds for 0 to 20 Nm in Calibration Mode or Override Mode
60,000 Full Stroke Cycles; 1,500,000 repositions
1.2 m Halogen-Free Cable with 18 AWG (0.75 mm
Integral Connectors for 10 mm Flexible Metal Conduit
NEMA 2 (IP54) for All Mounting Orientations
- Operating -40 to 55 °C; 90% RH Maximum, Noncondensing
- Storage -65 to 85 °C; 95% RH Maximum, Noncondensing
See Figure 1
2.9 kg
- United States UL Listed, CCN XAPX, File E27734; to UL 60730-1A: 2003-08, Ed. 3.1, Automatic Electrical Controls for Household and
Similar Use; and UL 60730-2-14: 2002-02, Ed. 1, Part 2, Particular Requirements for Electric Actuators.
- Canada UL Listed, CCN XAPX7, File E27734; to UL 60730-1:02-CAN/CSA: July 2002, 3rd Ed., Automatic Electrical Controls for
Household and Similar Use; and CSA C22.2 No. 24-93 Temperature Indicating and Regulating Equipment.
- Europe Distech Controls SAS, declares that these products are in compliance with the essential requirements and other relevant
provisions of the EMC Directive and Low Voltage Directive.
IS_DA-020S024PX / DA-020S024P2_14-88360-03354_Rev. -_09 2017
) Wire Leads
