Ordering Codes

Codes Descriptions
DA-0xxN024PX Actuator AC/DC 24 V

Technical Specifications

Actuators
Drive torque
Damper area
Running time
Power supply
Frequency
Power consumption:
- operating 2.5 W
- at end stops 0.3 W
For wire sizing
Control signals
Position Signal U DC 0...10 V / R > 50 KΩ
Angle of rotation:
- Working range 90° (93° mech.)
- Limiting 5°...85° in 5° steps
Service life
Sound power level
Protection class
Degree of protection
Temperature: operating/store
Humidity
Weight
Maintenance
Compliance
IS_DA-016N024PX / DA-024N024PX_14-88360-03303_Rev. -_07 2017
DA-016N024PX
16 Nm
3.0 m
Indipendent of load, at nominal conditions and room temperature
AC 24 V ±20% / DC ±10%
50-60 Hz
6.0 VA / 3.6 A @ 2ms
Y1 DC 0...10 V / Ri > 250 KΩ
Y2 0...20 mA / Ri 388 Ω
60'000 cycles
45 dB (A)
II
IP 54 (with cable glands, cable downwards)
-20°...+50 °C / -30°...+60 °C
5...95% RH (not condensing)
1.1 kg
Maintenance-free
Distech Controls SAS, declares that these products are in compliance with the essential
requirements and other relevant provisions of the EMC Directive and Low Voltage
Directive.
2
80 s
This document is subject to change without notice
DA-024N024PX
24 Nm
4.5 m 2
125 s
