- Page 1 Sideboard Version:06/23/2022 1/22...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 58 B x 58 C x 40 D x 96 E x 24 7 x 35 mm 15 x 9 mm 4 x 35 mm...
- Page 4 4/22...
- Page 5 A x 6 D x 24 CL x 4 CR x 4 7 x 35 mm 3.5 x 12 mm Cam Bolt (A) to plate 3 and 4 with across screwdriver, as shown. Lock the slide rail (CL) to plate 3 with screw (D), as shown.
- Page 6 A x 4 D x 24 CL x 4 CR x 4 7 x 35 mm 3.5 x 12 mm Cam Bolt (A) to plate 5 Left and 5 Right with across screwdriver, as shown. Lock the slide rail (CL) to plate 5 Right with screw (D), as shown.
- Page 7 B x 6 15 x 9 mm Insert cam locks (B) into plates 6 and 7, as shown Attach plates 3 and 5 to plates 6 and 7. Tum cam locks clockwise to tighten. 180° 7/22...
- Page 8 B x 6 15 x 9 mm Insert cam locks (B) into plates 6 and 7, as shown Attach plates 4 and 5 to plates 6 and 7. Tum cam locks clockwise to tighten. 180° 8/22...
- Page 9 Slide part 9 into available slot of parts 3,5,4 and 7, as shown. 9/22...
- Page 10 G x 9 4 x 40 mm Attach part 2 into assembled unit using screws (G), as shown. 10/22...
- Page 11 E x 20 P x 5 4 x 14 mm Attach iron foot (P) to plate 2 with screw (E) using across screwdriver, as shown. 11/22...
- Page 12 F x 6 8 x 40 mm Insert wooden dowels (F) into assembled unit, as shown. Slide part 8 into available slot of parts 3,5,4 and 7, as shown. 12/22...
- Page 13 A x 6 E x 4 K x 2 7 x 35 mm 4 x 14 mm Attach angle iron (K) to plate 1 with screw (E) using across screwdriver, as shown. Cam Bolt (A) to plate 1 with across screwdriver, as shown.
- Page 14 B x 6 15 x 9 mm Insert cam locks (B) into assembled unit as shown and attach part 1 to assembled unit. Turn cam locks clockwise to tighten. 180° 14/22...
- Page 15 L x 16 N x 16 3 x 14 mm 15/22...
- Page 16 A x 40 H x 8 M x 8 7 x 35 mm 4 x 18 mm Insert quickfit screws (A) to parts 10 and 11, as shown. Fix handle (M) to parts 10 and 11 using bolts (H), as shown. 16/22...
- Page 17 C x 40 4 x 35 mm Attach parts 13,15 and 16 to part 12 using screws (C), as shown. Slide part 14 into available slot of parts 13,12 and 15, as shown. 17/22...
- Page 18 B x 40 15 x 9 mm Insert cam locks (B) to parts 13,15 and 16 and attach part 10 and 11,as shown. Turn cam locks clockwise to tighten. 180° 18/22...
- Page 19 D x 12 DL x 2 DR x 2 3.5 x 12 mm Fix right inner drawer runner (DR) and left inner drawer runner (DL) to assembled unit using screws (D),as shown. 19/22...
- Page 20 G x 2 J x 2 4 x 40 mm 6 x 30 mm For extra stability, it is WALL WALL WALL recommended that you fix your drawer to the wall using drilling hole Ø6x30mm the additional hardwares (G, J, K), as shown. Should you choose not to affix the product to the wall,serious...
- Page 21 Insert drawers to assembled unit, as shown. WALL Note : Please put No10 on the left and No11 on the right 21/22...
- Page 22 WALL Wrong installation WALL 22/22...
- Page 23 WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
- Page 24 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please consult our FAQ section at feedbackstation@163.com as there may be a simple solution to the issue.
