- Page 1 Moxa IEEE 802.11a/b/g/n MiniPCI Module WAPN001 User’s Manual www.moxa.com First Edition, July 2010 © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.
- Page 2 WAPN001 User’s Manual The hardware and software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2009 Moxa Inc. All rights reserved.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction Overview Features Specification Chapter 2 Getting Started Module Layout Block Diagram Hardware Installation Software Installation... - Page 4 WAPN001 User’s Manual Introduction Introduction The following topics are covered in this chapter: D Overview D Features D Specifications...
- Page 5 WAPN001Mini-PCI Module is designed to provide wireless communication for all wireless device based systems. It communicates via the standard 802.11a/b/g/n protocols. The WAPN001 uses the AR9220 wireless chipset from Atheros. This module is connected to the PCI bus through a Mini-PCI connector and special circuitry to allow for compatibility with either 3.3V or 5V PCI signaling.
-
Page 6: Introduction
WAPN001 User’s Manual Introduction Specification Features WAPN001 Chipset Atheros AR9220 Baseband Processor ˙ DSS with DBPSK, DQPSK, CCK (BBP) ˙ OFDM with BPSK, QPSK, 16QAM, 64QAM ˙ 802.11b: CCK@11/5.5 Mbps, DQPSK@2 Mbps, DBPSK@11 Mbps ˙ 802.11a/g: 64QAM@54/48 Mbps, 16QAM@36/24 Mbps, QPSK@18/12 Mbps BPSK@9/6 Mbps ˙... -
Page 7: Getting Started
Getting Started This chapter covers the module layout, and block diagram, hardware installation of the WAPN001. Software installation is covered in the next chapter. The following topics are covered: D Module Layout D Block Diagram D Hardware Installation D Software Installation... -
Page 8: Module Layout
WAPN001 User’s Manual Getting Started Module Layout... -
Page 9: Block Diagram
WAPN001 User’s Manual Getting Started Block Diagram Below is a block diagram of the WAPN001. Primary board components are in bold, while external connections are italicized. - Page 10 WAPN001 User’s Manual Getting Started Connector Locations...
- Page 11 WAPN001 User’s Manual Getting Started MiniPCI Bus Connector PIN Assignments 3.3V_C ON AD 0 AD 0 3.3V AD 1 AD 1 3.3V-2 AD 2 AD 2 3.3V-3 AD 3 AD 3 3.3V-4 AD 4 AD 5 AD 4 3.3V-5 AD 5 3.3V-6...
-
Page 12: Hardware Installation
WAPN001 User’s Manual Getting Started Hardware Installation The WAPN001 can be installed into all Moxa wireless system board series. It can be located below the CPU. Step for Installation 1. Attach the WLAN antenna to connector J1. 2. If using 2nd WLAN antenna, attach it to connector J2. - Page 13 This transmitter module is authorized only for use in device where the antenna may be installed such that 20cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: "Contains FCC ID: SLE-WAPN001 ”...
