Wisenet SCD-6083R - High Resolution Dome Camera Quick Guide

PARTS AND FEATURES

1. Dome Cover
2. Shield Case
3. Rotate Base: Control rotating angle of camera.
4. Vari-focal Lens Module: 2.8 ~ 12mm (F1.4).
5. Function Setup switch: Display the menu on the screen and move the cursor to four directions to confirm status or changing a selected item.
6. Pan Base: Control panning angle of camera.
7. Power input terminal: Connect the power as specified for each model here.
8. Ground Terminal
9. MD Output Terminal: Motion detection signals are output through this terminal.
10. Video Output Jack: Video signals are output through this port. Connect this port to the Video IN port of a AHD DVR.
11. IR LED: These infrared LED's are controlled by the illumination sensor.
12. IIIumination sensor: Detects incoming light to control the IR LED.

MAIN SETUP
