Note
2) Before setting parameters, first refer to the User Manual of the corresponding controller. As some
parameters are not settable, operation of setting these parameters on the display unit will be deemed as
invalid or impossible by the controller.
• The Parameters Setting page will have a brief summary of the parameters already set in this menu:
• AUTO: the battery voltage is the automatic recognition system
• SLD: battery type is sealed lead acid battery;
• BST: charging voltage is 14.4V*n
• LVD: over-discharge voltage is 11.0V*n
• Tap to enter into the following submenus.
9.7.1 CONTROLLER CHARGING AND DISCHARGING RELATED
PARAMETER SETTINGS
• All voltage values are to be set based on 12V system settings. For example, for a 24V system, if the over-discharge
voltage is to be set to 22.0V, as n=24/12=2, the value needed in line with 12V system settings is 22.0V/2=11.0V,
therefore the over-discharge voltage needs to be set to 11.0V.
• Tap , to select the item to be set; then tap
adjust the value, and tap
Parameter settings list)
• For parameters on the current menu, those highlighted are settable, while those underlined are not
9.7.2 LCD SCREEN BACKLIGHT TIME SETTING
CHARACTERS DISPLAYED
BackLight-T: ON
BackLight-T: 20S
Enter into the setting menu, tap
to modify the value within the setting range (ON indicates the screen will be constantly lit, and the range of backlight
time is
"1-600" S)
Tap to confirm the modification, or tap
[page 32] | gpelectric.com
1) In this manual, "n" assigned with a value of 1, 2, 3 or 4 denotes a battery system of 12V, 24V,
36V or 48V accordingly.
Setting icon
again to confirm the setting. (For the setting ranges of related parameters, refer to
, to move to BackLight-T: 20S, tap
to cancel the modification.
System voltage indication
Battery type indication
Boost charging voltage 14.4V
Over-discharge voltage 11.0V
, and the parameter or sign will flash; continue to tap
DESCRIPTION
The LCD screen is lit constantly
The setting range of LCD screen backlight time is 1 to 600s
to enter into the setting mode, and tap
REMOTE
,
,
to
