6.1.7 CONTROLLER CHARGING AND DISCHARGING RELATED
PARAMETER SETTINGS
• All voltage values are to be set based on 12V system settings. For example, for a 24V system, if the over-discharge
voltage is to be set to 22.0V, as n=24/12=2, the value needed in line with 12V system settings is 22.0V/2=11.0V,
therefore the over-discharge voltage needs to be set to 11.0V.
• Tap , to select the item to be set; then tap
adjust the value, and tap
Parameter settings list)
• For parameters on the current menu, those highlighted are settable, while those underlined are not

6.1.8 LCD SCREEN BACKLIGHT TIME SETTING

CHARACTERS DISPLAYED
BackLight-T: ON
BackLight-T: 20S
Enter into the setting menu, tap
to modify the value within the setting range (ON indicates the screen will be constantly lit, and the range of backlight
time is
"1-600" S)
Tap to confirm the modification, or tap

6.1.9 CONTROLLER ABNORMALITY VOICE ALARM - ON/OFF SETTING

BUZZER STATE
No Alarm
Alarm sound: every 1 min
Alarm sound: every 15 sec
Alarm sound: Persistent
CHARACTER DISPLAYED
Voice alarm: ON
Voice alarm: OFF
Enter into the setting manual, tap
and again use , to switch between ON and OFF. Tap
modification.
Factory settings disable the voice alarm function by default (the aforementioned faults will not trigger alarms with the voice
alarm disabled.
OPERATION AND DISPLAY
, and the parameter or sign will flash; continue to tap
again to confirm the setting. (For the setting ranges of related parameters, refer to
DESCRIPTION
The LCD screen is lit constantly
The setting range of LCD screen backlight time is 1 to 600s
to move to BackLight-T: 20S, tap
,
to cancel the modification.
ALARM TYPE
System running well
Battery over-discharge, Load short circuit/overload, controller
or battery over-temperature
Battery under-voltage
Battery over-voltage,solar panel reverse connection,solar panel
over voltage
DESCRIPTION
Voice alarm enabled
Voice alarm enabled
to move to Voice Alarm: XXX, tap
,
to enter into the setting mode, and tap
to enter into the parameter setting mode,
to confirm the modification, or tap
, to
,
to cancel the
gpelectric.com | [page 21]
