9.7 SYSTEM PARAMETER SETTINGS

MENU
PAGE ITEM TO SET
LEVEL
Battery system voltage
1
Battery type
Nominal battery capacity
Device address
Over-voltage threshold
Charging limit voltage
2
Equalizing charging voltage
Boost charging voltage
Floating charging voltage
Boost charging recovery
2nd-
voltage
Level
3
Menus
Over-discharge recovery
voltage
Under-voltage warning level
Over-discharge voltage
Over-discharge time delay
4
Equalizing charging time
Boost charging time
Equalizing charging interval
Temperature compensation
5
Light control time
Light control voltage
LCD screen backlight time
Fault voice alarm
6
Clear historical data
Reset to factory settings
DISPLAYED ITEM/ PARAMETER AND
PARAMETER SETTING RANGE
12V, 12V system
24V, 24V system
BatSysVol 36V, 36V system
48V, 48V system
AUTO, auto recognition
SLD, sealed lead-acid
battery
FLD, open lead-acid battery
BatType
GEL, gel battery
LI, lithium battery
USE, user defined
Capacity 0 to 9999
Address 1 to 60
OverVolDsc 9.0 to 17.0V
ChgLimtVol 9.0 to 17.0V
EquChgVol 9.0 to 17.0V
BstChgVol 9.0 to 17.0V
FltChgVol 9.0 to 17.0V
BstChgRev 9.0 to 17.0V
LowVolRev 9.0 to 17.0V
UndVolWrn 9.0 to 17.0V
LowVolDsc 9.0 to 17.0V
LVD Delay 0 to 60s
Equ-Time 0 to 300MIN
Bst-Time 0 to 300MIN
Equ-Inv 0 to 30D (days)
Temp-Com -(3 to 5) mV/ °C/ 2V
L-CON-T 0 to 60MIN
L-CON-V 5 to 11V
1 to 600s (ON indicates the
BackLight-T
screen is lit constantly)
ON, voice alarm enabled
Voice Alarm
OFF, voice alarm disabled
<ClrHistoryData> Select YES for execution
<FoctoryDefault> Select YES for execution
REMOTE
NOTES
±5
±1
*n, ±1
±1
*n, ±1
±1
