Warning: Danger, Electric shock hazards! We strongly recommend connect a fuse or circuit
breaker to the PV array and battery terminals to prevent electric shock hazards during wiring
or error operation, and make sure that fuse or circuit breaker is disconnected before wiring.
PV maximum input
Models
GP-MPPT-PRO-30
GP-MPPT-PRO-40
GP-MPPT-PRO-50
GP-MPPT-PRO-60
For installation safety, we recommend a wiring sequence as follows; however, wiring in other sequence instead of this one
will not damage the controller.
1) Note that the battery fuse shall be installed as close as possible to the battery terminal. The
Note
recommended distance is not more than 150mm.
2) The battery temperature is 25°C (fixed value) when the controller is not collected to a remote temperature
sensor.
Max. wire diameter
at PV end
current
(mm²/AWG)
30
8/8
40
10/7
50
12/6
60
INSTALLATION
Battery wire diameter
Rated charge current
30A
40A
50A
60A
(mm²/AWG)
8/8
10/
12/6
gpelectric.com | [page 13]
