2.2. Installation

2.2.1. Work Area

sure the work area you choose has a three-prong grounded outlet capable of
supplying the necessary input current to the power source. Be sure the outlet has
been tested for proper wiring before connecting the instrument to it.

2.2.2. Power Requirements

This instrument requires a power source of either 100-120 volts AC ± 10%, 50/60 Hz
single phase or 200-240 volts AC ±10%, 50/60 Hz single phase. The instrument will
automatically detect the input voltage being applied to it. See section 3.2.2. Rear
Panel Controls for an image of the rear panel.
____________________________________________________________________________
3145 Carton Contents
Locate a suitable testing area and be sure you have read all
safety instructions for the operation of the instrument and
suggestions on the test area setup in section 1.4. Safety. Make
The HYAMP III must be connected to a good ground. Be
certain that the power wiring is properly polarized and that the
proper low resistance bonding to ground is in place.
11
