Medical Restrictions
Personnel with heart ailments or devices such as pacemakers should be informed that
the voltages and currents generated by the instrument are very dangerous. If
contacted, the instrument may cause heart-related problems. Please have the test
operator consult a physician for recommendations.
1.5. Key Features and Benefits: HYAMP III
THE FIRST MANUAL
GROUND BOND
INSTRUMENT WITH AN
ENHANCED GRAPHIC LCD
SECURITY ACCESS
STORAGE OF UP TO 10
DIFFERENT TEST
PROGRAMS
INTERCONNECTION WITH
HYPOT III
FOUR WIRE MEASUREMENT
(KELVIN METHOD) AND
MILLIOHM OFFSET
CAPABILITY
PLC REMOTE INPUTS AND
OUTPUTS
WITHSTAND PROCESSING
INDICATOR
SOFTWARE CALIBRATION
CONTROL
NO LOAD SETUP OF
OUTPUT CURRENT
____________________________________________________________________________
Provides the operator with an easy-to-use
interface, eliminating the need to decipher cryptic
abbreviations. The graphic display makes testing
safer, easier and more reliable than ever before.
Limit user access so that only authorized
personnel with a security code can change test
parameters.
Store test parameters and quickly recall them for
each of the different products that need to be
tested. Memories can also be linked to run multi-
step tests.
Connect a HYAMP III and a Hypot III to form a
complete test system. The test system can be
configured to perform sequential Ground Bond
and Dielectric Withstand tests, or run both
simultaneously.
The Kelvin four wire measurement technique
eliminates test lead resistance. The milliohm
offset function allows for the use of longer test
leads without compromising the test results.
Two standard 9 pin interfaces provide inputs and
outputs for simple PLC relay control. Outputs
include: PASS, FAIL, RESET and TEST IN
PROCESS signals. Inputs include: TEST,
INTERLOCK, RESET and remote recall of
MEMORY 1, 2 and 3.
As a safety precaution, the enhanced graphic
LCD indicates when the high voltage from the
Hypot III is being applied to the device under test
HYAMP III can be completely calibrated without
removing any covers and exposing the technician
to hazardous voltages.
Set output current parameters without activating
the output.
