PCB Layout
5 PCB Layout
Figure 5-1
through
Figure 5-4
Figure 5-1. TPS715EVM-074 Top Layer Routing
Figure 5-3. TPS715EVM-074 Internal Layer 2
Routing
6
TPS715EVM-074 Evaluation Module
depict the layout of the TPS715EVM-074.
Copyright © 2022 Texas Instruments Incorporated
Figure 5-2. TPS715EVM-074 Internal Layer 1
Routing
Figure 5-4. TPS715EVM-074 Bottom Layer Routing
www.ti.com
SBVU077 – OCTOBER 2022
