Installation and Operation Manual
INSPIRE 2000
(OB02042 Model)
US Environmental Protection
Agency phase II certified wood
stove compliant with 2020 cord
wood standard.
MOBILE
Safety tested according to
HOME
ULC S627, UL 1482 and
UL 737 standards by an
accredited laboratory.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN
LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD STOVE. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
45951A
Printed in Canada
2021-06-27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OB02042 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Osburn OB02042

Summary of Contents for Osburn OB02042

  • Page 1 Installation and Operation Manual INSPIRE 2000 (OB02042 Model) US Environmental Protection Agency phase II certified wood stove compliant with 2020 cord wood standard. MOBILE Safety tested according to HOME ULC S627, UL 1482 and UL 737 standards by an accredited laboratory.
  • Page 3 It is also highly recommended to register the warranty online at https://www.osburn-mfg.com/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit. Installation and Operation Manual - Inspire 2000...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PART A - OPERATION AND MAINTENANCE ................7 1. Safety Information ........................7 2. General Information ........................8 2.1 Performances ........................8 2.2 Specifications ........................9 2.3 Dimensions ........................10 2.4 EPA Certification Loading ....................14 2.5 Zone Heating and How to Make it Work for You ..............15 2.6 The Benefits of Low Emissions and High Efficiency ............15 2.7 The SBI Commitment to You and the Environment ............15 3.
  • Page 5 Appendix 5. Log retainers installation ..................56 Appendix 5. Optional Refractory Panels Installation .............. 57 Appendix 6. Air Tubes and Baffle Installation ................. 60 Appendix 7. Exploded Diagram and Parts List ............... 62 Osburn Limited Lifetime Warranty ..................... 66 Dealer: Installer: Phone Number:...
  • Page 6 CERTIFICATION PLATE Page 6 Installation and Operation Manual - Inspire 2000...

  • Page 7: Part A - Operation And Maintenance

    PART A - OPERATION AND MAINTENANCE 1. Safety Information • Operate only with the door fully closed. If the door is left partly open, gas and flame may be drawn out of the opening, creating risks from both fire and smoke. •...

  • Page 8: General Information

    2.1 Performances Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. Model Inspire 2000 (OB02042) Fuel Type Dry Cordwood Recommended heating area (sq. ft. 500 to 2,100 ft...

  • Page 9: Specifications

    2.2 Specifications Maximum log length 20 in (508 mm) east-west Flue outlet diameter 6 in (150 mm) Recommended connector pipe diameter 6 in (150 mm) Type of chimney ULC S629, UL 103 HT (2100 °F) Baffle material C-Cast Approved for alcove installation Approved for mobile home installation Shipping weight (without option) 435 lb (198 kg)

  • Page 10: Dimensions

    2.3 Dimensions 2.3.1 Stove Dimensions without a base 27 7/8" 708mm 14" 354mm 6 3/8" 163mm 6" Ø 150mm Figure 1: Top view 20 1/8" 511mm 9 1/2" 241mm 20 1/4" 514mm 27 3/8" 19 5/8" 695mm 498mm 24 1/4" 616mm Figure 2: Front view Figure 3: Side view...
  • Page 11 2.3.2 Stove dimensions with steel base 27 7/8" 708mm 14" 354mm 9 1/2" 241mm 20 1/4" 6 3/8" 514mm 163mm 6" Ø 150mm 12 1/4" 312mm 21 7/8" 554mm 27 3/8" 695mm Figure 4: Top view Figure 5: Front view 12 1/4"...
  • Page 12 2.3.3 Stove dimensions with soapstone base 27 7/8" 708mm 14" 354mm 6 3/8" 163mm 6" Ø 150mm 12 1/8" 309mm 22 1/2" 571mm 27 1/4" 691mm Figure 8: Top view Figure 9: Front view 12 1/8" 309mm 19 7/8" 17 5/8" 505mm 448mm Figure 10: Side view...
  • Page 13 2.3.4 Combustion Chamber Dimensions 8 1/4" 211mm 21" 20" 533mm 508mm Figure 12: Door opening Figure 13: Front view - Combustion chamber 3/16" 3/8" 10mm 16 3/4" 425mm 11 3/4" 299mm 13 1/2" 343mm Figure 14: Side view - Combustion chamber Installation and Operation Manual - Inspire 2000 Page 13...

  • Page 14: Epa Certification Loading

    2.4 EPA Certification Loading For EPA Certification testing, wood logs were 16 ± 1 inches long and the specie used was hard maple. 2.4.1 Air Control The air control is located underneath the ash shelf. To open the air control, pull the air control handle completely (High).

  • Page 15: Zone Heating And How To Make It Work For You

    2.5 Zone Heating and How to Make it Work for You This stove is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature. This is called zone heating and it is an increasingly popular way to heat homes or spaces within homes.

  • Page 16: Fuel

    The paint coating on the stove is very thin. Its VOC content (Volatile Organic Compounds) is very low. VOCs can be responsible for smog, so all the paint used during the manufacturing process meets the latest air quality requirements regarding VOC reduction or elimination. The air tubes are stainless steel, which can also be recycled.

  • Page 17: How To Prepare Or Buy Good Firewood

    3.1 How to Prepare or Buy Good Firewood 3.1.1 What is Good Firewood? Good firewood has been cut to the correct length for the stove, split to a range of sizes and stacked in the open until its moisture content is down to 15% to 20%. 3.1.2 Tree Species The tree species the firewood is produced from is less important than its moisture content.
  • Page 18 Wood should be split to a range of sizes, from about 3" to 6" (75 mm to 150 mm) in cross section. Having a range of sizes makes starting and rekindling fires much easier. Often, the firewood purchased from commercial suppliers is not split small enough to fuel the fire. It is sometimes advisable to resplit the wood before stacking to air dry.

  • Page 19: Operating Your Stove

    3.1.7 Manufactured Logs Do not burn manufactured logs made of wax impregnated sawdust or logs with any chemical additives. Manufactured logs made of 100% compressed sawdust can be burned with caution in the number of these logs burned at once. Start with one manufactured log and see how the stove reacts.

  • Page 20: Cold Hand

    4.1 Cold Hand The cold hand is a handle, supplied with the stove, which allows to open the door and avoid burns. To open, insert the cold hand into the opening on the right side of the stove. Pull on the cold hand to open the door.

  • Page 21: Wood Storage In The Pedestal

    The blower has a rheostat that can be adjusted in three different positions; either from high (HI) to low (LO) or closed (OFF). Allow the stove to reach operating temperature (approximately one hour) before turning on the blower, since increased airflow from the blower will remove heat and affect the start up combustion efficiency.

  • Page 22: Lighting Fires

    As hotter and hotter fires are burnt, more of the painted surfaces reach the curing temperature of the paint. The smell of curing paint does not disappear until one or two very hot fires have been burnt. 5.2 Lighting Fires Each person heating with wood develops its own favourite way to light fires.

  • Page 23: Maintaining Wood Fires

    5.2.3 Two Parallel Logs Method Two spit logs are placed in the firebox with a few sheets of twisted newspapers in between the logs. Fine kindling is added across the two logs and some larger kindling across those, log cabin style.
  • Page 24 Ashes should be placed in a tightly covered metal container. The container must be placed on a non-combustible floor or on the ground well away from all combustible materials. Ashes can contain hot embers that can stay hot for several days. If the ashes are disposed of by burial in soil or otherwise locally dispersed, they should be kept in a closed metal container until they are completely cooled.

  • Page 25: Building Different Fires For Different Needs

    Therefore, each load of wood should burn completely so that the space begins to cool off a little before loading. Letting the space cool before loading is one of the secrets to clean burning and effective zone heating. 5.3.5 Controlling the Air Intake Once the firewood, firebox and chimney are hot, air intake can be reduced to achieve a steady burn.
  • Page 26 5.4.3 High Output Fires for Cold Weather When heating needs are high during cold weather, the fire should burn steadily and brightly. This is the time to use larger pieces of hardwood. Place the biggest pieces at the back of the firebox and place the rest of the pieces compactly.

  • Page 27: Maintenance

    5.4.6 Carbon Monoxide When unburned logs remain in the firebox and the flame disappears, go outside and look at the chimney exit. If there is visible smoke, it means that there is still combustible to burn but that the fire lacks air to burn properly. In this situation, the CO rate will increase so it is important to react.
  • Page 28 Never try to clean the glass when the stove is hot. When the stove runs at lower temperatures, light brown stains may form, especially in the lower corners of the glass. This indicates that the fire has been smoky and some of the smoke has condensed on the glass.
  • Page 29 6.2.3 Gasket It is a good idea to replace the glass gasket when the door gasket is being replaced. The new gasket is flat, adhesive-backed and made of woven fibreglass. Remove the glass following the first three steps of the «6.2.2 Replacement»...

  • Page 30: Door

    6.3 Door In order for the stove to burn at its best efficiency, the door must provide a perfect seal with the firebox. The tightness of the door seal can be verified by closing and latching the door on a strip of paper.
  • Page 31 It is also possible to fix the handle angle by adjusting the door latch mechanism, located on the right hand side opening of the stove. 16. Unscrew the nuts (D) and lift the door latch mechanism (E) to increase the pressure on the door.

  • Page 32: Chimney Maintenance

    6.3.2 Gasket It is important to replace the gasket with another having the same diameter and density to maintain a good seal. 17. Remove the door and place it face-down on something soft like a cushion of rags or a piece of carpet.
  • Page 33 The most common equipment used are fibreglass rods with threaded fittings and stiff plastic brushes. The brush is forced up and down inside the chimney flue to scrub off the creosote. The chimney should be checked regularly for creosote build-up. Inspection and cleaning of the chimney can be facilitated by removing the baffle.

  • Page 34: Part B - Installation

    PART B - INSTALLATION 7. Safety Information and Standards • The information given on the certification label affixed to the appliance always overrides the information published, in any other media (owner’s manual, catalogues, flyers, magazines and web sites). • Mixing of appliance components from different sources or modifying components may result in hazardous conditions.

  • Page 35: Clearances To Combustible Material

    8. Clearances to Combustible Material The clearances shown in this section have been determined by tests according to procedures set out in safety standards ULC S627 (Canada), UL 1482 (U.S.A.) and UL 737 (U.S.A.). When the stove is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions.
  • Page 36 Figure 31: Clearances - Top Figure 32: Clearances - Side The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances above mentioned. Page 36 Installation and Operation Manual - Inspire 2000...
  • Page 37 Figure 33: Clearances - Corner The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances above mentioned. Installation and Operation Manual - Inspire 2000 Page 37...
  • Page 38 APPLIANCE CLEARANCES (INSTALLATION APPLIANCE CLEARANCES (INSTALLATION WITH SINGLE WALL PIPE CONNECTOR) WITH DOUBLE WALL PIPE CONNECTOR) Canada Canada 14 ½" (368 mm) 11" (279 mm) 6" (152 mm) 6" (152 mm) 17" (432 mm) 16" (406 mm) 17" (432 mm) 16"...
  • Page 39 8.2.2 Clearances With Lowered Ceiling APPLIANCE CLEARANCES (INSTALLATION APPLIANCE CLEARANCES (INSTALLATION WITH SINGLE WALL PIPE CONNECTOR) WITH DOUBLE WALL PIPE CONNECTOR) Canada Canada 14 ½" (368 mm) 11" (279 mm) 9" (229 mm) 9" (229 mm) 19" (483 mm) 18" (457 mm) 19"...
  • Page 40 8.2.4 Clearances Inside an Alcove APPLIANCE CLEARANCES (INSTALLATION DISTANCES FROM PIPE CONNECTOR WITH WITH DOUBLE WALL PIPE CONNECTOR) DOUBLE WALL PIPE CONNECTOR Canada Canada 9" (229 mm) 9" (229 mm) 12 ¼" (311 mm) 12 ¼" (311 mm) 19" (483 mm) 19"...

  • Page 41: Floor Protector

    8.3 Floor Protector This stove is designed to prevent the floor from overheating. However, it must be placed on a nonflammable surface to protect the floor from hot embers that may fall during loading. The floor protection must be a continuous, non combustible material, such as steel with a minimum thickness of 0.015"...
  • Page 42 8.4.1 Shield Construction Rules − Adhesives used in shield construction must not ignite or lose adhesive qualities at temperatures likely to be encountered. − Mounting hardware which extends from the shield surface into combustibles may be used only at the edges of the shield. −...
  • Page 43 Figure 36: Heat shield clearances Figure 37: Heat shield clearances Figure 38: Heat shield clearances Installation and Operation Manual - Inspire 2000 Page 43...
  • Page 44 CLEARANCES MAY BE REDUCED BY THESE PERCENTAGES TYPE OF SHIELD SIDES AND REAR TOP (CEILING) CAN /USA CAN /USA MIN. MIN. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at least 25 mm (1 in)* by non-combustible spacers 12"...

  • Page 45: The Venting System

    9. The Venting System 9.1 General The venting system, made of the chimney and the connecting pipe between the stove and the chimney, acts as the engine that drives the wood heating system. Even the best stove will not function safely and efficiently if it is not connected to a suitable chimney. The heat in the flue gases that pass from the stove and chimney connector into the chimney is not waste heat.
  • Page 46 9.2.2 Factory-Built Metal Chimneys in Mobile Homes For use in a mobile home, this stove is to be connected to a 6" double wall factory built chimney pipe conforming to UCL-S629, standards for 650°C Factory-built chimney. The total length of the flue system should be at least 12 feet including elbows, from the top of the stove.

  • Page 47: Minimum Chimney Height

    9.3 Minimum Chimney Height The top of the chimney should be tall enough to be above the air turbulence caused when wind blows against the house and its roof. The chimney must extend at least 1 m (3 ft.) above the highest point of contact with the roof, and at least 60 cm (2 ft.) higher than any roof line or obstacle within a horizontal distance of 3 m (10 ft.).

  • Page 48: Supply Of Combustion Air

    9.4.2 Why the Chimney Should Penetrate the Highest Heated Space When it is cold outside, the warm air in the house is buoyant so it tends to rise. This creates a slight pressure difference in the house. Called ‘stack effect’, it produces a slightly negative pressure in the lower part of the house (compared to the outside) and a slightly positive pressure zone in the high part of the house.

  • Page 49: Installing The Chimney Connector

    Contrary to commonly expressed concerns, almost all tightly sealed new houses have enough natural leakage to provide a small amount of air needed by the stove. The only case in which the wood stove may not have adequate access to combustion air is if the operation of a powerful exhaust device (such as a kitchen range exhaust) causes the pressure in the house to become negative relative to outdoors.
  • Page 50 9.6.1 Installation of Single Wall Chimney Connector The chimney connector assembly has been called ‘the weak link’ in the safety of wood heating systems because failure to install the connector properly (which has been common in the past) can result in house fires. The best flue pipe assembly is one that rises straight up from the stove to the base of the chimney with no elbows.
  • Page 51 • Each joint in the assembly must be fastened with at least three screws. • The assembly must have allowance for expansion: elbows in assemblies allow for expansion; straight assemblies should include an inspection wrap with one end unfastened, or a telescopic section. •...

  • Page 52: Appendix 1. Base Installation

    APPENDIx 1. BASE INSTALLATION It is possible to install three different bases on the stove. See the installation manual of each base for more details. Figure 45: Minimalist base Figure 46: Steel base Figure 47: Soapstone base Page 52 Installation and Operation Manual - Inspire 2000...

  • Page 53: Appendix 2. Decorative Panels Installation

    APPENDIx 2. DECORATIVE PANELS INSTALLATION To install the decorative panels, remove the screws (B) that hlods the front panel (A) in place. Install both decorative panels (C) and secure them in place with 4 screws (D). Installation and Operation Manual - Inspire 2000 Page 53...

  • Page 54: Appendix 3. Optional Fresh Air Intake Kit Installation

    APPENDIx 3. OPTIONAL FRESH AIR INTAKE KIT INSTALLATION This mobile home approved stove requires installation of a fresh air intake kit (A) and an insulated fresh air intake pipe (HVAC type, must meet ULC S110 or UL 181 class 0 or class 1) (B), sold separately.

  • Page 55: Appendix 4. Optional Blower And Thermodisc Installation

    APPENDIx 4. OPTIONAL BLOWER AND THERMODISC INSTALLATION A blower and a thermodisc, sold separately, can be installed on the stove. Thermodisc allows the blower to operate only when the stove is hot enough. See the instructions provided with the blower and the thermodisc for more details. Remove the backplate by cutting the knockouts with pliers.

  • Page 56: Appendix 5. Log Retainers Installation

    APPENDIx 5. LOG RETAINERS INSTALLATION Page 56 Installation and Operation Manual - Inspire 2000...

  • Page 57: Appendix 5. Optional Refractory Panels Installation

    APPENDIx 6. OPTIONAL REFRACTORY PANELS INSTALLATION Remove the center floor brick and then remove the 6 other floor bricks. Remove the brick holder and remove the three left side bricks. Redo for the right side. Installation and Operation Manual - Inspire 2000 Page 57...
  • Page 58 Remove the back bricks (4). Remove the brick retainers and install the back refractory slabs (2). The retainers can not be reused after being removed. Page 58 Installation and Operation Manual - Inspire 2000...
  • Page 59 Install the sides (2) and the floor refractory slabs. Install the refractory slabs retainer (2) on both sides and screw them in place . Installation and Operation Manual - Inspire 2000 Page 59...

  • Page 60: Appendix 6. Air Tubes And Baffle Installation

    APPENDIx 7. AIR TUBES AND BAFFLE INSTALLATION Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Align the notch in the left end of the tube with the key of the left air channel hole.
  • Page 61 Note that secondary air tubes (B) can be replaced without removing the baffle board (A) and that all tubes are identical. Installation and Operation Manual - Inspire 2000 Page 61...

  • Page 62: Appendix 7. Exploded Diagram And Parts List

    APPENDIx 8. ExPLODED DIAGRAM AND PARTS LIST DETAIL G DETAIL C DETAIL F DETAIL D DETAIL E 15 16 DETAIL A DETAIL B Page 62 Installation and Operation Manual - Inspire 2000...
  • Page 63 SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK 30060 THREAD-CUTTING SCREW 1/4-20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC PL65139 NARROW DECORATIVE PANEL 30977 OSBURN STICKER SE65138 DECORATIVE PANEL ASSEMBLY PL65935 HINGE 30094 HEX SCREW WASHER HEAD 1/4-20 X 3/4" F ZINC TYPE...
  • Page 64 Item Description 44085 RHEOSTAT KNOB 44087 RHEOSTAT NUT AC03095 BLOWER ASSEMBLY WITH VARIABLE SPEED CONTROL (UP TO 130 CFM) 44070 CROSSFLOW BLOWER SINGLE CAGE 115V-60Hz-56W AC02055 QUICK CONNECT THERMODISC KIT 44028 CERAMIC THERMODISC F110-20F 29020 4 1/2'' X 9'' X 1 1/4'' REFRACTORY BRICK HD PL36056 2"...

  • Page 66: Osburn Limited Lifetime Warranty

    Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your OSBURN dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
  • Page 68 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec) Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002 of information contained in any document obtained from https://www.osburn-mfg.com/en/ unauthorized sources. tech@sbi-international.com...

This manual is also suitable for:

Inspire 2000

Table of Contents
