Technical Data

Battery Voltage* .......................... 24 V D.C.
Battery Capacity ......................... 2.0 Ah
Charging Time Max ....................1 hr 20 min
Telescoping Pole Length ............ 3.7 ft to 5.3 ft
....................................................(1.1 m to 1.6 m)
Auxiliary Handle Angles .............. -45° | 0° | 45°
Charger Input.............................. 100 – 240 V 50/60HZ
Charger Output ........................... 26 V DC 1.5 A
Pole Chain Saw
Motor ..........................................350 W
Bar/Chain Length ....................... 8 inch (20.3 cm)
Cutting Thickness .......................
....................................................
Oil Tank Capacity .......................
Overhead Reach Max .................13 ft (4 m)
Head Angles ............................... 0° to 30°
Battery Run Time Max ................40 mins
Weight (with Battery Installed) .... 7.7 lbs (3.5 kg)
Pole Hedge Trimmer
Motor ..........................................250 W
Blade Length .............................. 17.7 inch (45 cm)
Cutting Diameter ........................ 0.6 inch (1.5 cm)
Head Angles ............................... -45° to 90°
Battery Run Time Max ................55 mins
Weight (with Battery Installed) .... 7.7 lbs (3.5 kg)
Grass Trimmer + Edger
Motor ..........................................200 W
Cutting Diameter ........................ 10 inch (25 cm)
Spool Length .............................. 16.5 ft (5 m)
Spool Advance ........................... Auto-feed
Line diameter .............................. 0.055 inch (1.4 mm)
Head Angles ............................... 0° to 60°
Battery Run Time Max ................50 mins
Weight (with Battery Installed) .... 6.2 lbs (2.8 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Recommended: 6.5 in. (16.5 cm)
Unpacking
Carton Contents
Chain saw head with chain and bar pre-mounted
Hex key wrench
Hedge trimmer head with blade
Hedge trimmer blade sheath
Grass trimmer + edger head
Grass trimmer + edger safety guard
Manuals with registration card
1. Carefully remove the multi-tool system and check to see
that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
missing parts, DO NOT return the unit to the store.
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
multi-tool system. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT!
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
Battery + Charger

Battery Pack Operation

pack is completely sealed and maintenance free.
Battery Charge Level Indicator
is high.
decreasing. Stop work as soon as possible.
IMMEDIATELY and charge the battery. Otherwise the
battery's service life will be greatly shortened.
9
auxiliary handle
