SNOWJOE SUNJOE GTS4002C Operator's Manual

SNOWJOE SUNJOE GTS4002C Operator's Manual

Cordless lawn + garden multi-tool system (24-volt max pole hedge trimmer, pole chain saw, pole grass trimmer)
Hide thumbs Also See for SUNJOE GTS4002C:

Advertisement

Quick Links

Download this manual
TM
OPERATOR'S MANUAL
A Division of Snow Joe, LLC
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may result
in serious bodily injury or death.
General Power Tool Safety Warnings
m
WARNING!
Read all safety warnings and all
instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
m
DANGER!
This indicates a hazardous situation, which,
if not followed, will result in serious injury or death.
m
WARNING!
This indicates a hazardous situation, which, if
not followed, could result in serious injury or death.
m
CAUTION!
This indicates a hazardous situation, which, if
not followed, could result in minor or moderate injury.
Work Area Safety
1. Keep work area clean and well lit – Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust – Power tools create sparks which may ignite the dust
or fumes.
3. Keep children and bystanders away while operating a
power tool – Distractions can cause you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators –
There is an increased risk of electric shock if your body is
earthed or grounded.
3. Do not expose power tools to rain or wet conditions –
Original instructions.
© 2023 Snow Joe, LLC. All rights reserved.
CORDLESS LAWN + GARDEN
R
MULTI-TOOL SYSTEM
24-VOLT MAX* | POLE HEDGE TRIMMER | POLE CHAIN SAW | POLE GRASS TRIMMER
Model GTS4002C
Water entering a power tool will increase the risk of electric
shock.
4. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
5. When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence
of drugs, alcohol or medication – A moment of inattention
while operating power tools may result in serious personal
injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the switch is in
the of f-position before connecting to power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch or energising
power tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on – A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
5. Do not overreach. Keep proper footing and balance at
all times – This enables better control of the power tool in
unexpected situations.
6. Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts – Loose clothes, jewelry or long hair can be caught in
moving parts.
8. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used – Use of dust collection can
reduce dust-related hazards.
7. Wear protective hair coverings to contain long hair.
Power Tool Use + Care
1. Do not force the power tool. Use the correct power tool
for your application – The correct power tool will do the
job better and safer at the rate for which it was designed.
*Initial no-load voltage, when fully charged, peaks at 24V;
1
Form No. SJ-GTS4002C-MAX-880E-MR8
nominal voltage under typical load is 21.6V.
SAVE THESE INSTRUCTIONS
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUNJOE GTS4002C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SNOWJOE SUNJOE GTS4002C

Summary of Contents for SNOWJOE SUNJOE GTS4002C

  • Page 1 CORDLESS LAWN + GARDEN MULTI-TOOL SYSTEM 24-VOLT MAX* | POLE HEDGE TRIMMER | POLE CHAIN SAW | POLE GRASS TRIMMER OPERATOR'S MANUAL Model GTS4002C A Division of Snow Joe, LLC Form No. SJ-GTS4002C-MAX-880E-MR8 IMPORTANT! Water entering a power tool will increase the risk of electric shock.
  • Page 2 ® customer service center at intended for the particular type of power tool, taking 1-866-SNOWJOE (1-866-766-9563) for all maintenance or into account the working conditions and the work to be operations not foreseen in this manual. Any operation performed performed – Use of the power tool for operations different in an unauthorized service center or by unqualified personnel from those intended could result in a hazardous situation.
  • Page 3 4. Store the multi-tool system indoors, in a dry place that is 18. Always use two hands when operating the extended each pruner. Hold the pole chain saw with both hands to avoid inaccessible to children. Keep away from corrosive agents loss of control.
  • Page 4 5. Use the pole hedge trimmer and accessories in accordance poorly ventilated spaces or in the presence of flammable with these instructions, taking into account the working and/or explosive substances such as liquids, gases, and conditions the work to be performed. Use of the power tool powders.
  • Page 5 ® ® Do not use a battery pack or appliance that 1-866-SNOWJOE (1-866-766-9563) for assistance. is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk • Battery chemicals cause serious burns – Never let a of injury.
  • Page 6 ® ® (4.5°C – 40.5°C). Store your lithium-ion battery pack in a service center at 1-866-SNOWJOE (1-866-766-9563). cool, dry place at a temperature of 50°F – 68°F (10°F – 20°C). Protect the battery pack, charger and 3. Electrical plugs must match the outlet. Never modify cordless tool from humidity and direct sunlight.
  • Page 7 Safety Symbols The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions READ THE OPERATOR'S MANUAL(S) – Read, understand, SAFETY ALERT –...
  • Page 8 Know Your Cordless Lawn + Garden Multi-tool System Read the owner’s manual and safety instructions carefully before operating the cordless multi-tool system. Compare the illustration below to the cordless multi-tool system in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference.
  • Page 9 ® ® Spool Length ..............16.5 ft (5 m) 1-866-SNOWJOE (1-866-766-9563). Spool Advance ................ Auto-feed NOTE: Do not discard the shipping carton and packaging material until you are ready to use your new cordless multi- Line diameter ............0.055 inch (1.4 mm) tool system.
  • Page 10 Charging the Battery 1. Push the push lock button on the battery to pull the battery pack out from the battery compartment (Fig. 1). Lights Light Indicators Fig. 1 Charge level button The battery is at 30% capacity Push button and requires charging The battery is at 60% capacity and requires charging soon...
  • Page 11 IMPORTANT! Never allow the battery pack to become fully discharged as this will cause irreversible damage to Fig. 5 the battery. Pole Chain Saw Assembly Chain/sprocket DANGER! Never start the motor before installing the end cover guide bar, chain, and chain/sprocket end cover. Without all these parts in place, the clutch can fly off or explode, exposing the user to potentially serious injuries.
  • Page 12 NOTE: Make certain of the direction of the chain If the chain is mounted backwards, the saw will vibrate Fig. 11 abnormally and will not cut. Fig. 8 Chain/sprocket end cover Chain tensioner ring Connecting to the Telescoping Pole 1. Open the assembly lock on the telescoping pole, and push the chain saw head into the opening on the end of the pole (Fig.
  • Page 13 3. To remove the chain saw head, release the On/Off switch and remove the battery. Unlock the assembly lock. Fig. 16 Push the lock tabs on both sides, and pull the chain saw Pull Pull head out (Fig. 13). Operation Starting and Stopping 1.
  • Page 14 3. Re-assemble the auxiliary handle lock knob and the bolt on Back Side (Fig. 21). Fig. 19 Fig. 21 Rotating button Front Side Rotating button To Adjust the Position of the Auxiliary Handle 1. Disconnect the saw from the power supply by removing the battery from the compartment.
  • Page 15 To Adjust the Angle of the Auxiliary Handle CAUTION! The chain will continue to run for several 1. Stop the saw by releasing the On/Off switch. seconds after turning off the tool. 2. The auxiliary handle can be adjusted in -45°, 0°, 45°. Rotate Do not use the pole chain saw under wet conditions.
  • Page 16 • The most typical cutting application is to position the unit at • Do not put pressure on the saw at the end of the cut. an angle of 60° or less depending on the specific situation Pruning (Fig. 26). As the angle of the pole chain saw shaft to the ground increases, the difficulty of making the first cut Pruning is the process of trimming limbs from a live tree.
  • Page 17 ® dealer or call the Snow Joe + Sun Joe customer service ® ® center at 1-866-SNOWJOE (1-866-766-9563). Fig. 28 Properly Adjusted Warm Chain Sharpening is necessary when: • The sawdust looks like dust; • Cutting becomes more difficult; Flats are not visible here •...
  • Page 18 • Turn the bar over in the vise and repeat on all the other • bent guide bar cutting edges. • cracked or broken rails • Check that the depth limiter tooth does not stick out farther • spread rails than the inspection tool and file any projecting parts with a Turn the saw over, check the underside of the guide bar, and flat file, rounding off the edges (Fig.
  • Page 19 If you continue to experience problems or need repairs beyond these minor To help maintain your pole chain saw for optimum performance, adjustments, please call 1-866-SNOWJOE (1-866-766-9563) we recommend you complete this checklist prior to each work for assistance.
  • Page 20 Connecting to the Telescoping Pole Grass Trimmer + Edger 1. Open the assembly lock on the telescoping pole, and push the grass trimmer + edger head into the opening on the end of the pole (Fig. 34). Assembly Grass trimmer Fig.
  • Page 21 Operation 3. Lock the pole in position by closing the telescoping lock (Fig. 39), and ensure that the pole is secured. Starting and Stopping Fig. 39 1. Slide the battery into the battery compartment until it clicks to lock into position (Fig. 36). Fig.
  • Page 22 Adjusting the Multi-Angle Head NOTE: It's recommended to not remove the auxiliary handle when operating the grass trimmer + edger for better The grass trimmer + edger head can be rotated for 5 different maneuverability and easier operation. cutting angles for 0°, 15°, 30°, 45° and 60°. Follow the below To Adjust the Position of the Auxiliary Handle instructions to adjust angles.
  • Page 23 Operation Tips To convert the unit, follow the instruction below: 1. To convert the grass trimmer to an edger, slide the • Wear non-slip gloves for maximum grip and protection. converting switch on the trimmer head up, meanwhile turn • For the best cutting action against walls, fences, and in high the lower part of the trimmer head to the side until the grass, move the grass trimmer slowly so grass is cut with the trimmer head is locked into position (Fig.
  • Page 24 CAUTION! Always wear eye protection. Fig. 52 1. Hold the trimmer at an angle of approximately 10 – 30 degrees to the work area (Fig. 49). Fig. 49 Edging wheel Advancing Lines 10° – 30° NOTE: Your trimmer uses 0.055 in. (1.4 mm) diameter nylon line to cut grass and weed quickly and easily.
  • Page 25 + Sun Joe ® dealer or call the Snow Joe ® Fig. 55 + Sun Joe ® customer service center at 1-866-SNOWJOE (1-866-766-9563) for assistance. Replacing the Spool + Clearing Jams and Spool Tangled Lines Slot WARNING! Remove the battery from the unit before changing the trimmer line.
  • Page 26 2. To remove the spool from the trimmer hub, follow steps 1 CAUTION! Catapulted pieces of nylon line may and 2 from the section "Replacing the Spool + Clearing cause injury. Jams and Tangled Lines" beginning on page 25. NOTE: The maximum recommended length of line is 3.
  • Page 27 Operation Pole Hedge Trimmer Starting and Stopping 1. Slide the battery into the battery compartment until it clicks Assembly to lock into position (Fig. 62). Connecting to the Telescoping Pole Fig. 62 The hedge trimmer head comes fully assembled. To use the machine as a pole hedge trimmer, connect the hedge trimmer head with the telescoping pole as indicated below.
  • Page 28 3. Lock the pole in position by closing the telescoping lock To Adjust the Position of the Auxiliary Handle (Fig. 65), and ensure that the pole is secured. 1. Disconnect the hedge trimmer from the power supply by removing the battery from the compartment. Fig.
  • Page 29 Adjusting the Multi-Angle Head Cutting Tips The hedge trimmer head can be rotated for 10 different cutting WARNING! Always hold the pole hedge trimmer with both angles for -45º, -30º, -15º, 0º, 15º, 30º, 45º, 60º, 75º, and 90º. hands. Never hold shrubs with one hand and operate the pole Follow the below instructions to adjust angles.
  • Page 30 Care + Maintenance Fig. 71 WARNING! Blades are sharp. When handling the blade assembly, wear non-slip, heavy-duty protective gloves. Do not place your hand or fingers between blades or in any position where they could get pinched or cut. NEVER touch the blades or service the unit with the battery inserted.
  • Page 31 • Reorient or relocate the receiving antenna. 1-866-SNOWJOE (1-866-766-9563) for assistance. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different Model + Serial Number from that to which the receiver is connected.
  • Page 32 NOTE: Accessories are subject to change without any obligation on the part of Snow Joe ® + Sun Joe ® to provide notice of such changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe ® + Sun Joe ® customer service center at 1-866-SNOWJOE (1-866-766-9563).
  • Page 33 PRODUCT REGISTRATION: Snow Joe strongly encourages you to register your Product. You can register online at snowjoe.com/register, or by printing and mailing in a registration card available online from our website, or by calling our Customer Service Department at 1-866-SNOWJOE (1-866-766-9563), or by e-mailing us at help@snowjoe.com.
  • Page 34 sunjoe.com...
