  • Page 1 PETROL LINE TRIMMER STRAIGHT SHAFT 4 STROKE 26CC MODEL NO. SXPG42602...

  • Page 2: Table Of Contents

    CONTENTS Section Page Section Page Contents Description & Components Suggested Applications Unpacking 2 Years Warranty / Serial Number Assembly 10 – 12 Specifications Operation 12 - 15 Introduction Maintenance 15 – 17 Express Warranty Statement Trouble Shooting Complete Warranty Statement Service Log Important Safety Instructions 6 - 8...

  • Page 3: Specifications

    4 STROKE PETROL LINE TRIMMER Your new petrol line trimmer has been engineered and manufactured to STANLEY’s high standard of dependability, ease of operation and operator safety. Properly cared for, it will give you years of rugged, trouble free performance. If you use your petrol line trimmer properly and only for what it is intended, you will enjoy years of safe, reliable service.

  • Page 4: Introduction

    INTRODUCTION Dear Customer, Thank you for purchasing this Line Trimmer which has passed through our extensive quality assurance processes. Every care has been taken to ensure that it reaches you in perfect condition. However, in the unlikely event that you should experience a problem, or if you require any assistance please do not hesitate to contact us.

  • Page 5: Complete Warranty Statement

    COMPLETE WARRANTY STATEMENT - LINE TRIMMER As soon as you have purchased the Line Trimmer, we costs associated with the service will be charged to the owner. recommend that you check to make sure it is intact and that you Blockages caused by spider webs, insects, dirt, accumulated read the operating instructions carefully before using it.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The purpose of safety rules is to attract your attention to SPECIFIC SAFETY INSTRUCTIONS possible dangers. The safety symbols and the explanations Read the instructions with due care. Familiarise yourself with with them, require your careful attention and understanding. the settings and proper operation of the machine.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS Never start or run the product inside a closed room or If the unit will not be used for a long time, clean the unit building. Fumes from the exhaust contain dangerous carbon completely, especially the fuel/oil tank, its surroundings, and monoxide.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS Be careful not to drop the unit or hit it against obstacles. RESIDUAL RISKS Before proceeding to adjust or repair the unit, be sure to stop Even when the unit is used as prescribed it is not possible to the engine and detach the spark plug.

  • Page 9: Description & Components

    DESCRIPTION DESCRI TION For information regarding spare parts, please refer to contact details on the front of this manual 1. Fuel tank cap 9. Cutting head shield 2. Primer button 10. Knob for drive shaft connection 3. Air filter with choke button 11.

  • Page 10: Unpacking

    UNPACKING CAUTION. If any parts are found to be missing, please contact customer service (details on page 2 & 4). Do not throw the packaging This packaging contains sharp objects. Take care when away, keep it safe throughout the warranty period, then recycle unpacking.
  • Page 11 ASSEMBLY INSTALLING THE CUTTING HEAD SHIELD WARNING. The line cut-off blade on the cutting head shield is sharp. Avoid connection with the blade. Failure to avoid contact can result in serious personal injury. Locate the bolt, nut and washer used to fix the cutting head shield.

  • Page 12: Operation

    ASSEMBLY INSTALLING THE HARNESS Connect the latch on the shoulder harness to the strap hanger, Fig 7. Adjust the strap to a comfortable position, Fig. 8. WARNING. Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury.
  • Page 13 OPERATION TO CHECK ENGINE LEVEL BEFORE EACH Separate the attachment from the power head. Set power head on a flat level surface with shaft parallel to surface. Unscrew the oil cap and remove. Lubricant level should fall within the top of oil fill hole (the top of screw thread).
  • Page 14 OPERATION TO RESTART A WARM ENGINE Ignition switch Throttle lever Do NOT push choke button in. Turn switch to “I” ON position. Ensure primer bulb has fuel inside. Rapidly pull starter/grip until engine starts. Squeeze throttle to provide fuel to engine and use for intended task.

  • Page 15: Maintenance

    OPERATION TIPS FOR TRIMMING Avoid hot surfaces by always keeping the tool away from your Use the tip of line to trim grass; do not force string head into body. uncut grass. Cut all grass from top to down. This will prevent grass from Avoid trees, flowers, stones, walls and other objects which can wrapping around the shaft housing and string head which could cause the line breakage.
  • Page 16 MAINTENANCE ENGINE OIL REPLACEMENT WARNING. Old engine oil is considered special waste and has to be disposed according to your local environment protection regulation. Do not pour the oil to garbage can, sewer, soil etc. The engine oil replacement is easier if engine is warm (NOT HOT!).
  • Page 17 MAINTENANCE REPLACING THE CUTTING LINE SPOOL Open the cutting line spool by pressing two release buttons on the side and take out the winding core (Fig.14 & 15). Divide a spare cutting line in 2 equal halves, fix it in the winding core and start to wind the cutting line in two separated rails (Fig.15).

  • Page 18: Trouble Shooting

    Problem Possible Cause Solution Check spark. Remove spark plug. Reattach the spark plug cap and lay spark plug on metal cylinder. Pull the starter rope No spark and watch for spark at spark plug tip. If there is no spark, repeat test with a new spark plug.

  • Page 19: Service Log

    This Service is to be complete within 20 hours or This Service is to be complete within 40 hours or 3 months of purchase, which ever comes first. 6 months of purchase, which ever comes first. Replace Replace Replace Replace Air filter Spark plug Air filter...
