Summary of Contents for Stanley STR-750

  • Page 1 Petrol grass trimmer Original instructions STR-750 Petrol grass trimmer...
  • Page 2 Manufactured under license by: MATRIX GmbH • Postauer Straße 26 • D-84109 Wörth/Isar • www.matrix-direct.net Stanley is a registered trademark of The Stanley Works or its affiliates and is used under license.
  • Page 4 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig.10 Fig.11 Fig.12...

  • Page 5: Table Of Contents

    Table of Contents 1. Symbols 1. Symbols ................5 2. Intended use..............6 Warning! 3. Safety instructions............6 4. Parts List...............8 5. Assembly...............9 Read the operating manual prior to 6. FueL................10 commissioning! 7. Operation instructions..........10 8. Maintenance and repairs ..........12 Wear goggles, a helmet and ear protection! 9.

  • Page 6: Intended Use

    2. Intended use 4. Dress properly! Do not wear loose clothing or jewellery, which can be caught in moving parts. Use of sturdy gloves, non-skid footwear and safety glasses is The intended purpose of the device is the trimming of recommended.
  • Page 7 Keep hands and feet away from the cutting means at all reach an open flame or spark. Always allow the machine times, especially when he motor are switched on) to cool down before storing. 7. Never allow children or people unfamiliar with the 3.

  • Page 8: Parts List

    Never fill the tank in enclosed spaces, such as you keep a suitable fire extinguisher within reach basements or sheds. in your work area! There is a risk of poisoning and explosion! 9. Avoid skin contact with petrol. VIBRATION AND NOISE REDUCTION 10.

  • Page 9: Assembly

    5. Assembly ASSEMBLY SHAFT 1. Align the lower shaft(19) with the clamp(16) so that the lock pin(18) is orientated to the centre hole in the WARNING! The machine must be fully clamp. assembled before operation! Do not use a machine that is only partly assembled or assembled with damaged parts.

  • Page 10: Fuel

    use the bigger trimming guard for cutting. Ask your local authorities. INSTALL CUTTING ATTACHMENT Install spool assembly 1. Make sure that the guard has been attached properly. 8. Unscrew and remove the fuel tank cap. 2. Attach the trimmer head onto the spindle. 9.
  • Page 11 4. Press throttle interlock and throttle trigger.   ADJUST CUTTING ANGLE 1. The angle of gear head can be adjusted in 3 positions according to the performed work. 5. Pull the recoil starter to start engine and the move choke lever to “WARM START” position. Now, your machine is under idle speed condition.

  • Page 12: Maintenance And Repairs

    5. Move the machine with slow and regular horizontal 2. Pay special attention when performing the work close movements from the right to the left and then lead it to trees and bushes. The cutting means can damage back to starting point before trimming the next row. sensitive bark, and damage fence posts.
  • Page 13 AIR FILTER 8. Replace with a new spark plug if you find damages 1. Inspect the air filter regularly. Clean it at least every like cracks or a splintered insulation. 25 hours or replace with a new one if necessary. 9.

  • Page 14: Technical Data

    5. To replace the line take out the spool and remove the Sound pressure level L 97,4 dB(A), k=3 dB(A) remaining cutting line. Sound power level L 110 dB(A), k=3 dB(A) 6. Cut a new 6m long cutting line with a diameter of Vibration a 8,712 m/s ;...

  • Page 15: Troubleshooting

    10. Troubleshooting Problem Possible cause Fault correction Engine does not start There is not enough fuel in Add fuel the fuel tank The primer has been not Press the primer and restart pressed at cold start The primer has been not Press the primer and restart pressed at warm start The spark plug is wet...
  • Page 16 Postauer Str. 26 D-84109 Wörth/Isar Germany Fax: +49 (0) 8702/45338 98 E-Mail: info@matrix-direct.net hereby declares the following conformity under the EU Directive and standards for the following article Petrol grass trimmer / STR-750 R&TTED 1999/5/EC 2006/42/EC 2000/14/EC_2005/88/EC 2006/95/EC 95/54/EC 2002/95/EC_2005/618/EC 97/68/EC_2012/46/EC 2014/30/EU EN ISO 11806-1;...
  • Page 17 GARANTIE Guarantee are excluded from the guarantee. This appliance is a quality product. It was designed in compliance with Damages caused by the manufacturer or by a material defect will be corrected at no current technical standards and made carefully using normal, good quality materials.
  • Page 18 Petrol grass trimmer / STR-750 WARRANTY Purchased at: in (city, street): Name of customer: Street address: Postal code, city: Telephone: Date, signature: Fault description:...
