- Page 1 Assembly and Operating Instructions max. 180 kg ~ 90 Min. 60 kg L 122 | W 61 | H 154 TFUB99TFT.01.01 Upright Bike UB9.9 Touch TF-UB99-TFT TF-UB99-T...
- Page 2 UB9.9 Touch...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Programmes 3.3.1 Quick Start 3.3.2 Target programmes 3.3.3 Pre-set programmes 3.3.4 User-defined programmes 3.3.5 Heart rate-oriented programmes Fitness Test Media Bluetooth and Fitness Apps... - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT UB9.9 Touch...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. UB9.9 Touch...
-
Page 7: General Information
GENERAL INFORMATION Technical Data TFT Display: Training duration in min. Speed in km/h Training distance in km Calories in kcal Resistance level Heart rate (using the hand pulse sensors or a chest strap) Watts Brake system: Electro-magnetic induction brake Resistance levels: Watt range: 20–300W Fylwheel mass:... -
Page 8: Personal Safety
Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. UB9.9 Touch... -
Page 9: Electrical Safety
Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Assembly
To prevent damage to the equipment and the floor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. UB9.9 Touch... -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠... -
Page 12: Assembly
These are not required for assembly. Lift the rear frame and mount the rear stabiliser (2) to the main frame (1) with four washers (16), four spring washers (9), two screws (7A), two screws (7) (see fig. 1-4) and hand-tighten the screws. UB9.9 Touch... - Page 13 M8x1.25x70L M8x1.25x110L D15.4xD8.2x2T D16xD8.5x1.2T 9 16 9 16 Step-1...
- Page 14 2-2). Pull the lock on the seat post (13) towards the saddle and insert the seat post (13) into the main If the seat position does not meet your requirements after assembly has been completed, the Step-2 UB9.9 Touch...
- Page 15 Step 3: Mounting the front post Slide the cover (75) on the front post (17) upwards (see fig. 3-1). Connect the two console cables (64 & 65) together (see fig. 3-2). ࣑ ATTENTION Make sure not to clamp the cables during the next step. Place the front post (17) on the main frame (1) and mount the front post (17) with four washers (16), four spring washers (9) and four screws (15).
- Page 16 Pass the remaining console cables from the console (76) through the front post opening (17) -tighten the screws. M5*12L UB9.9 Touch...
- Page 17 Step 5: Mounting the handles and bottle holder Connect the cables from the console (76) to the cables for the speed buttons (37L & 37R). Mount the handlebar (36) to the front post (17) using two curved washers (8) and two screws (41) and hand-tighten the screws.
- Page 18 Lift the equipment on the desired side and rotate the adjustable screws under the main frame. Rotate the screws clockwise in order to unscrew them, therefore raising the equipment. Rotate the screws counterclockwise in order to lower the equipment. Step-2 UB9.9 Touch...
- Page 19 Step 8: Connecting the equipment to the mains supply ࣑ ATTENTION The equipment must not be connected to a power board, otherwise it cannot be guaranteed that the equipment will be supplied with sufficient power. Technical errors can happen as a result. Connect the power cable (66) to the unit and then plug the power cable (66) into a socket which complies with the specifications in the chapter on electrical safety.
-
Page 20: Operating Instructions
Display of the training time in minutes Time Display range: 00:00–999:59 Display of the training distance in km Distance Display range: 0.0–99.9 Display of the calories in kcal Calories Display range: 0–9999 Display of current heart rate Puls Display range: 40–220 UB9.9 Touch... - Page 21 Display of the MET or Watt value Definition: MET or metabolic equivalent is used to measure the average metabolic rate for a person. MET describes the quantity of oxygen that an average person needs when in rest. 1 MET = 3.5 ml/kg/min (The body consumes 3.5 milliliters of oxygen per kilogram per minute) is the amount of oxygen that the body needs when Mets/Watt in rest.
-
Page 22: Button Functions
3.3.1 Quick Start When you are in the main menu, simply press START to start a training session via quick start. Alternatively you can also tap on „QUICK START“ in the main menu. UB9.9 Touch... -
Page 23: Target Programmes
3.3.2 Target programmes Tap on „GOAL“ in the main menu. Choose either time, distance or calories as your target unit. NOTICE You can only choose one unit. Set a value for your desired target unit. Press START to start the programme. The resistance level can be adjusted manually during your training. - Page 24 Setting time / 30 = time for each section Programme LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL UB9.9 Touch...
- Page 25 Setting time / 30 = time for each section Programme LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL...
-
Page 26: User-Defined Programmes
Press the STOP button to pause your training. The resistance level is set to 0. 6.1. Press STOP again to end your training and an overview of the collected training data will be displayed. 6.2. Press START to continue with your training. UB9.9 Touch... -
Page 27: Heart Rate-Oriented Programmes
3.3.5 Heart rate-oriented programmes WARNING ⚠ Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. There are three different heart rate-oriented programmes. -
Page 28: Fitness Test
In case the console does not receive a signal for 15 seconds the programme will be stopped. If your heart rate gets to high the console will display „OVER PULSE“. In this case, please interrupt your test immediately. Upon completion of the test an overview of the collected training data will be displayed. UB9.9 Touch... -
Page 29: Media
Media Here you will find many different apps like YouTube, Twitter, Facebook or Instagram. IMPORTANT NOTE To make sure the preinstalled apps are working correctly, you will have to update them from time to time. The apps that need to be updated will give you a message. To update the app, you need to have a google account. -
Page 30: Bluetooth And Fitness Apps
You will find the fitness apps in the app stores of Google or Apple. There you will find the apps “Kinomap” or “Zwift”. Please note that these apps are produced by an external manufacturer. Sport-Tiedje does not take any responsibility regarding the availability, functionality or contents of these programmes. Example: Kinomap UB9.9 Touch... -
Page 31: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 32: Troubleshooting, Care And Maintenance
Use a suitable chest strap (see RECOMMENDED ACCESSORIES) Wrong position of chest No pulse display Reposition chest strap and/or strap moisten electrodes Chest strap defective or Changing batteries battery empty Check if pulse display by hand pulse Pulse display defective possible UB9.9 Touch... -
Page 33: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Half-yearly Yearly Display console... -
Page 34: Recommended Accessories
Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap floor mat chest strap contact gel silicone spray towels UB9.9 Touch... - Page 35 Maximum weight/max. Benutzergewicht: Class/Klasse: Date/Datum: Sport-Tiedje GmbH, Flensburger Str. 55, 24837 Schleswig MADE IN Serial nº.: Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / recumbent bike Model Name: UB9.9 Touch Article Number: TF-UB99-TFT...
- Page 36 58006-6-1040-01 #6004-2RS(C0) waved washer 55120-5-2705-DA D27*D20.3*0.5T Screw 54203-2-0030-F0 M3*0.5*30L C ring 55519-1-2312-DA D22.5*D18.5*1.2T cross screw 54203-2-0012-F0 M3*0.5*12L crank axle 734S0-3-2903-00 pulley wheel 58008-6-1037-D0 D260*25*3T anti-loose nut 55206-1-2006-FA M6*1.0*6T Hex bolt 50106-5-0015-C0 M6x1.0x15L Multi-groove belt 58004-6-1113-00 440 PJ8 UB9.9 Touch...
- Page 37 Round Magnet 742G0-6-2574-00 Upper cable for quick button(2) 734S5-6-2539-00 400L Upper cable for quick button(1) 734S5-6-2542-00 400L Upper cover for handpulse 747S0-6-2517-B0 184.5*20.8*50 Lower cover for handpulse 747S0-6-2518-B0 184.5*35.2*50 Membrane button (-) 734S5-6-2534-00 D39,1505C Membrane button (+) 734S5-6-2533-00 D39, 1505C Handlebar 734S0-3-2400-J1 Lower cable for quick button(2)
- Page 38 55108-1-2830-NA D28*D8.5*3T Plastic cover 803K0-6-1082-00 D3*30L spring 58003-6-1024-N0 D2.2*D14*65L Fixing Plate For Idle Wheel 734S0-3-1600-00 Plastic Flat washer 55110-1-2404-BF D10*D24*0.4T Hex nut 55208-2-2006-NA M8*1.25*6T 55208-1-2008-FA M8*1.25*8T Adjustable rod 734S0-3-2225-N0 Bolt 51608-5-0016-F0 M8*1.25*16L spring 58003-6-1078-N0 D1.5*D14*50L Bolt 53205-2-0040-N0 M5*0.8*40L UB9.9 Touch...
- Page 39 Fixing bar 734S0-6-2210-N1 D6*49L Tighten gasket 734S0-6-4086-B0 D38*11T screw 54006-5-0045-F3 M6*1.0*45L Pull handle 734S0-6-2274-B0 152.5*53*32.2 End cap for adjustable handle 734S0-6-4085-B0 74*D37*3T bolt 50508-5-0050-D3 M8x1.25x50L buffer 55308-4-0020-G9 D10.5*20L block plate 734S0-6-4073-N0 31*31*6T moving wheel 26100-6-1087-B0 D65*24 Round head cross screw 51005-2-0012-F0 ST5*12L Inner hex fastening screw...
- Page 40 Exploded Drawing UB9.9 Touch...
- Page 41 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 42 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. UB9.9 Touch...
- Page 43 CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
- Page 44 The company employs numerous sports scientists, fitness trainers and competitive athletes. Visit us also on our social media platforms or our blog! UB9.9 Touch...
- Page 45 Notes...
- Page 46 Notes UB9.9 Touch...
- Page 48 Upright Bike UB9.9 Touch...
